Studio Equipment

Notes: Bitbox micro provides Eurorack sampling for smaller racks and smaller budgets. In only 18 HP of rack space you can get a touch screen based sampler with support for 8 stereo sample pads. Now you can record samples directly into the module or load them from the microSD card. Trigger your samples via CV or MIDI, then apply effects and mix the outputs. Save your configurations to multiple presets for later reuse.

Sample Playback

Play up to 24 stereo polyphonic notes when your samples fit in the 64 MB of internal memory or up to 8 larger stereo samples streaming directly from the microSD card
Configure 8 stereo sample pads per preset as single or multi-samples, clips, slicers, granular or new recordings
Stream long samples from the microSD card with a max sample size of 4 GB, which can be many hours of audio
Trigger samples with the touch screen, CV gate inputs, or MIDI input
Control how samples start and stop by choosing from one-shot, toggle, and gate launch modes
Tweak playback through a variety of sample parameters, including start position, length, pitch, gain, filter, loop mode, launch quantization, ADSR, Exclusive Grouping, clip synchronization, slice placement and sequencing, grain size, grain spread, grain count, and MIDI note and channel mapping

Sample Recording

Record Eurorack level audio straight into the module:

Record samples from a stereo audio input pair
Configure each pad for stereo or mono recording with the option to synchronize the start and stop times to clock inputs
Trigger recording via audio level threshold
Create perfectly sized loops by setting the recording length
Enable immediate playback after recording for live looping capabilities
Make recordings up to 4 hours in length
Resample the master output without patching
Automate recording of a multi-sample bank via MIDI and CV
Store recorded samples as WAV files on the micro SD card then remove the card to transfer them to your computer

Sample Modes
Find creative ways of using your samples with our 5 sample playback modes:

Trigger one shots or launch loops using sample mode
Load a folder of samples into a sample mode pad to improve the quality of the pitch shifting when playing a sample chromatically or to trigger different samples with each note
Play time-synchronized loops with constant pitch time shifting in clip mode
Skip between slices of a WAV using slicer mode
Create rich textures and other worldly sounds with granular mode

Inputs and Outputs
Use the 8 inputs the way you want: assignments include a stereo audio input, up to 8 gate inputs, up to 8 CV inputs and 1 clock input.
Route the audio from each pad out to one of 3 stereo audio outputs or one of 6 mono audio outputs
Listen to all of the pad outputs combined on the master stereo output

External Control and Synchronization
Playback can be immediate or synchronized to internal clock, TRS clock in, or MIDI clock in and out
Confidently connect with both TRS MIDI Type A and Type B, no adapter needed
Play a single or multi-sample pad pitch shifted using MIDI notes or CV
Trigger different sample slices using MIDI notes or CV
Modulate a wide variety of sample parameters through the MIDI input and up to 8 CV signals
Quickly set up MIDI modulation using Learn mode - no need to look up CC numbers
Module Features
Use the 2? diagonal touch screen to intuitively explore the features of the module
Get more creative with double the processing power of the original bitbox
Refine your sound with reverb and delay
Import or export WAV files with your Mac or PC using a microSD card
Save and recall multiple presets
Increase your capacity with larger microSD cards
Inputs and outputs are DC coupled so you can record and play out CV signals

Notes: Bitbox mk2 delivers powerful sampling and mangling for Eurorack. With this module you can add recording, sample playback, clip launching, slicing, granular sounds and musically intelligent looping capabilities to your Eurorack rig. With a 3.5 inch touchscreen, bitbox mk2 makes easy work of selecting, editing, and tweaking your samples. You can stream large samples of up to 4 GB file size straight from the microSD card. Interact with other musical components via CV and MIDI. Tweak your configurations to get them just right, then save them to multiple presets for future reuse. With the new bitbox mk2 hardware, you can now do more with the new more powerful processor.

Sample Playback
Play up to 24 polyphonic notes when your samples fit in the 64 MB of internal memory or up to 8 larger samples streaming directly from the microSD card
Configure 16 sample pads per preset as single or multi-samples, clips, slicers, granular or new recordings
Stream long samples from the microSD card with a max sample size of 4 GB, which can be many hours of audio
Trigger samples with the touch screen, CV gate inputs, or MIDI input
Use MIDI for polyphonic playback of samples or slices
Control how samples start and stop by choosing from one-shot, toggle, and gate launch modes
Tweak playback through a variety of sample parameters, including start position, length, pitch, gain, filter, loop mode, launch quantization, ADSR, Exclusive Grouping, clip synchronization, slice placement and sequencing, grain size, grain spread, grain count, and MIDI note and channel mapping

Record Eurorack level audio straight into the module:

Record samples from a stereo audio input pair
Configure each pad for stereo or mono recording with the option to synchronize the start and stop times to clock inputs
Trigger recording via audio level threshold
Create perfectly sized loops by setting the recording length
Enable immediate playback after recording for live looping capabilities
Make recordings up to 4 hours in length
Store recorded samples as WAV files on the micro SD card then remove the card to transfer them to your computer
Sample Modes
Find creative ways of using your samples with our 5 sample playback modes:

Trigger one shots or launch loops using sample mode
Load a folder of samples into a sample mode pad to improve the quality of the pitch shifting when playing a sample chromatically or to trigger different samples with each note
Play time-synchronized loops with constant pitch time shifting in clip mode
Skip between slices of a WAV using slicer mode
Create rich textures and other worldly sounds with granular mode
Inputs and Outputs
Connect up to 8 CV modulators to control numerous sample parameters
Trigger each of the 16 pads with a dedicated gate input
Record through the dedicated stereo audio input pair
Use CV to keep time through the dedicated clock input
Confidently connect with both TRS MIDI Type A and Type B, no adapter needed
Route the audio from each pad out to one of 2 stereo audio output pairs or any of the corresponding single channels
Inputs and outputs are DC coupled so you can record and play out CV signals

External Control and Synchronization
Playback can be immediate or synchronized to internal clock, TRS clock in, or MIDI clock in and out
Trigger each pad independently through a dedicated gate input
Use MIDI to trigger pads via a note per pad
Play a single or multi-sample pad pitch shifted using MIDI notes or CV
Trigger different sample slices using MIDI notes or CV
Modulate a wide variety of sample parameters through the MIDI input and up to 8 CV signals
Quickly set up MIDI modulation using Learn mode- no need to look up CC numbers
Module Features
Use the 3.5? diagonal touch screen to intuitively explore the features of the module
Get more creative with double the processing power of the original bitbox
Fill out your sound with reverb and delay
Import or export WAV files with your Mac or PC using a microSD card
Save and recall multiple presets
Increase your capacity with larger microSD cards
Select Flipped UI mode to mount the unit with the screen on the bottom and use the screen, knobs, buttons, and CV jacks as you normally would

Notes: The ACL Pan Mix module mixes up to four different mono sources into a stereo output with panorama and gain control. It also includes an stereo aux input, which will be added unity gain to the sum for cascading purposes.

Notes: The ACL SUM SUM consists of two rows of six inputs that are summed into one output each.

It can be used as a stereo signal summer or two mono signal summers, either audio or CV.

The internal gain of each row can be switched between Unity gain, a gain of 0.5 (-6dB) or 0.33 (-9.5dB) using convenient dip switches on the back of the module.

Notes: Genuine EMS synthi filter, with redesigned faceplate!

This legendary filter can be switched between pre1974 and post 1974 filter type and response. For the first time response can be voltage controlled which was designed on the circuit board but not available on the matrix. This module is made under license from EMS. The only officially licensed remake of the EMS diode lowpass filter used in the VCS3 and AKS synths. It´s a faithful recreation of the original circuit, featuring some modifications that are also done on vintage EMS equipment, like a switchable faster CV response option for very quick modulations. Another switch determines if the filter has 18dB/oct slope as used by EMS pre-1974 or 24dB. The cutoff frequency and also the resonance are voltage controllable. Signal inputs and outputs have level controls.

Notes: The RS-95N oscillator is a premium, british sounding VCO with waveshaping possiblities. It has a new front panel design with elongated holes.

It is based on the RS-90 but has more features, predominantly a very special sine wave.

The RS-95N presented here is technically identical but instead a normal frequency control it features a gorgeous, lockable potentiometer with ten turns. This allows precise fine tune control and adds the look of an EMS synthesiser to the VCO.

The module has three audio outputs: pulse, triangle and sine.

The upper shape control affects the pulse width. The lower shape control not only morphs from a falling sawtooth over triangle to a rising saw (or ramp) but simultaneously alters the sine wave and produces a kind of smoothed, softer sawtooth. Additionally the saw/sine output is a CV-INPUT for the symmetry of the sine. Very extraordinary feature that all are voltage controllable.

The oscillator sync is "soft" and not only reacts to square waves but works with all waveforms.

The frequency control has three switchable modes:

STD (standard) with a range of two octaves.
2 is two octaves lower than STD.
WIDE mode gives a range from 0.3 Hz - 17kHz and thus allows use of the RS-95 as VC-LFO with waveshaping options!
The "vary" control not only attenuates but also can amplify the pitch CV. It controls linearly from 0V over 1V/oct to 0.4 V/oct.

Notes: The Audio Anatomy Vinyl Record Clamp is an indispensable accessory for any vinyl lover, who is looking for the best possible sound reproduction. The easy to use clamp makes sure, that the record maintains an ideal position when turning and that disturbances from vibrations are avoided. The universal size fits all turntables.

diameter: 88mm - height: 23mm - weight: 85g, Black

Notes: The Audio Anatomy Vinyl Record Stabilizer is an indispensable accessory for any vinyl lover, who is looking for the best possible sound reproduction. The 416 grams of aluminium make sure, that the vinyl record maintains an ideal position when turning and that disturbances from vibrations are avoided. The universal size fits all turntables and the stylish colour combinations make all of the stabilizers an eye-catcher.

diameter: 80mm - height: 40mm - weight: 416g, Black

Notes: The Audio Anatomy Vinyl Record Stabilizer is an indispensable accessory for any vinyl lover, who is looking for the best possible sound reproduction. The 416 grams of aluminium make sure, that the vinyl record maintains an ideal position when turning and that disturbances from vibrations are avoided. The universal size fits all turntables and the stylish colour combinations make all of the stabilizers an eye-catcher.

diameter: 80mm - height: 40mm - weight: 416g, Gold

Notes: The Audio Anatomy Vinyl Record Stabilizer is an indispensable accessory for any vinyl lover, who is looking for the best possible sound reproduction. The 416 grams of aluminium make sure, that the vinyl record maintains an ideal position when turning and that disturbances from vibrations are avoided. The universal size fits all turntables and the stylish colour combinations make all of the stabilizers an eye-catcher.

diameter: 80mm - height: 40mm - weight: 416g, Silver

Notes: The Audio Anatomy Vinyl Record Stabilizer is an indispensable accessory for any vinyl lover, who is looking for the best possible sound reproduction. The 416 grams of aluminium make sure, that the vinyl record maintains an ideal position when turning and that disturbances from vibrations are avoided. The universal size fits all turntables and the stylish colour combinations make all of the stabilizers an eye-catcher.

diameter: 80mm - height: 40mm - weight: 416g, Red

Notes: From trickling hi-hats to thunderous kicks. The Befaco Percall 4-Channel VCA/Delay Envelope Module is designed to take care of all percussive aspects of your Eurorack rig. You'll be able to create a whole host of percussion thanks to the 4 VCAs, volume control and decay options. By using the trigger you'll be free to open the VCA whilst the volume knob helps determine the level of the percussive sound you've sculpted. Take your tones to the next level thanks to the inclusion of an output on the envelope. You can apply this to the pitch of the oscillator to achieve a fat kick drum which offers excellent low frequency energy. The Percall 4-channel module is the ultimate addition to your Eurorack.

Notes: This is the Behringer SYSTEM 100 130 DUAL VCA. An authentic reproduction of the original System 100M circuitry from the 80's that can fit in a standard Eurorack case- at a very affordable price. Mix the 130 DUAL VCA in with your existing rig or start your modular synth journey from here.

Each VCA in the 130 DUAL VCA comes equipped with three Sig In signal input jacks with their own gain controls. These inputs can accept audio signals via a 3.5 mm jack. The VCA's in the 130 also have a manual gain control, a low and high output as well as signal and clip indicators to keep an eye on your signal's levels. The low output can be connected to guitar amplifiers or mixers while the high output can connect to line level inputs in mixers or powered speakers. The outputs can be further modified to be linear or exponential via a switch located next to the gain knob.

The 130 DUAL VCA can also accept signals from other modules via the 3.5 mm Mod In jacks to shape the waveforms of the Sig In signals. These inputs have also have their own Mod In Knobs that control the amount of signal that goes through the Mod In jacks.

Installing the 130 DUAL VCA is designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and screw in the module using the included screws. This allows for the 130 to be mixed with other synth modules for a truly unique set up.

Notes: Enter the Behringer 902 VOLTAGE CONTROLLED AMPLIFIER. An authentic reproduction of the circuitry from the Modular 55, 35 and 15 series attenuators used by the world's most famous pop, rock and jazz musicians. Now you can build your very own, unique synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match with specific modules to customize your synth and complement the genre of music you play or go all out and have a room filled from floor to ceiling with modules that'll fulfill any synth geek's wildest dreams.

The 902 module features two signal inputs and two signal outputs that can be used to amplify two sources, either audio or control voltage, at the same time via a 3.5 mm connector. A rocker switch allows you to toggle between linear and logarithmic response modes while you can manually set the control voltage with the Fixed Control Voltage knob. Control inputs at the bottom of the module can accept control voltage signals from other modules to be change the amplification level.

Installing the 902 is simple as it was designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and screw in the module using the included screws. This allows for the 902 to be mixed with other synth modules for a truly unique set up.

Notes: Enter the Behringer 904A VOLTAGE CONTROLLED LOW PASS FILTER Module. A vintage-sounding authentic reproduction of the circuitry from the Modular 55, 35 & 15 Series from the 70s used by the world's most famous pop, rock and jazz musicians for their shows. Now, musicians can build their very own, unique, synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match specific modules to create your personal, unique synth to complement the music you play or go all out and fill a room, from floor to ceiling, with modules that'll fulfill any synth geek's wildest dream.

FILTER Module. A vintage-sounding authentic reproduction of the circuitry from the Modular 55, 35 & 15 Series from the 70s used by the world's most famous pop, rock and jazz musicians for their shows. Now, musicians can build their very own, unique, synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match specific modules to create your personal, unique synth to complement the music you play or go all out and fill a room, from floor to ceiling, with modules that'll fulfill any synth geek's wildest dream.

The 904A VOLTAGE CONTROLLED LOW PASS FILTER features a cutoff frequency knob that lets you decide which frequencies to attenuate. The resulting frequency is determined by this knob giving you the ability to change your sound with one turn.

Three Control Inputs plus audio ins and outs are available to send the processed signal to other modules and to connect voltage signals from other modules to affect the cutoff frequency.

The 904A VOLTAGE CONTROLLED LOW PASS FILTER provides you control of the resulting frequency and internal feedback with the Fixed Control Voltage and the Regeneration knob. A switch also allows you to command the frequency range by letting you decide which frequency band you want to operate in. This gives you real-time access to all important parameters with one module.

Notes: Enter the Behringer 911 Analog Envelope Generator. An authentic reproduction of the circuitry from the Modular 55, 35 and 15 series envelope generators used by the world's most famous pop, rock and jazz musicians. Now musicians can build their very own, unique, synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match with specific modules to customize your synth to complement the genre of music you play or go all out and have a room filled from floor to ceiling with modules that'll fulfill any synth geek's wildest dreams.

The 911 Module allows you to create a deeply contoured signal with its 4 independent controls for Attack (T1), Decay (T2), Release (T3) and Sustain levels from 0 to +5 Volts. Create snappy and percussive sounds or long evolving drones perfect for a funky groove or a brooding soundtrack to your latest cyberpunk epic.

For a more flexible setup, the 911 features a trigger input where you can connect an external trigger system like a keyboard via a 3.5mm TS cable as well as an output to send the envelope to another module

Installing the 911 is simple as it was designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and screw in the module using the included screws. This allows for the 911 to be mixed with other synth modules for a truly unique set up.

Notes: Enter the Behringer 911A DUAL TRIGGER DELAY. An authentic reproduction of the circuitry from the Modular 55 series used by the world's most famous pop, rock and jazz musicians. Now you can build your very own, unique synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match with specific modules to customize your synth and complement the genre of music you play or go all out and have a room filled from floor to ceiling with modules that'll fulfill any synth geek's wildest dreams.

The 911A comes with two delay triggers with their own delay time controls ranging from 2 ms up to 10 seconds and their own 3.5 mm S-Trig ins and outs. Connect the 911A to the Behringer 911 ENVELOPE GENERATOR module and turn your Attack/Decay/Sustain/Release (ADSR) module into a Delay/Attack/Decay/Sustain/Release (DADSR) module. Rather than just playing the note when the signal is triggered, the 911A creates a nice volume swell effect, rising from 0 until the peak volume then going through the rest of the phases set in the envelope generator.

The delays in the 911A can be coupled in three different ways. In the Off setting, the delays are triggered separately via the trigger inputs. In Parallel mode, the trigger connected to the input at the top section will activate both delays at the same time. Switching the knob to Series will trigger the top section first then the lower section after.

Installing the 911A is simple as it was designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and screw in the module using the included screws. This allows for the 911A to be mixed with other synth modules for a truly unique set up.

Notes: Enter the Behringer 921A OSCILLATOR DRIVER. An authentic reproduction of the circuitry from the Modular 55 and 35 series oscillator drivers used by the world's most famous pop, rock and jazz musicians. Now you can build your very own, unique synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match with specific modules to customize your synth and complement the genre of music you play or go all out and have a room filled from floor to ceiling with modules that'll fulfill any synth geek's wildest dreams.

The 921A OSCILLATOR DRIVER module features a frequency knob that can adjust between either octave or semitone frequencies. The included rocker switch can be used to select between the two frequency types. The width of the rectangular wave is adjusted via a control knob that goes from 10% up to 90%. You can also connect any incoming control voltage or modulation signal into either of the 3.5 mm Frequency or Width inputs.

The 921A not only controls just one 921B Oscillator, but 12 of them- providing you with more flexibility and more nuanced waveforms.

Installing the 921A is simple as it was designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and screw in the module using the included screws. This allows for the 921A to be mixed with other synth modules for a truly unique set up.

Notes: Enter the Behringer 962 SEQUENTIAL SWITCH Module. An authentic reproduction of the discrete circuitry from the Modular 55 Series used by the world's most famous pop, rock and jazz musicians for their shows. Now, musicians can build their very own, unique, synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match specific modules to create your personal, unique synth to complement the music you play or go all out and fill a room, from floor to ceiling, with modules that'll fulfill any synth geek's wildest dream.

The 962 is used as a latch, shifter and signal selector. Depending on the number of input jacks plugged into the module, the 962 can alternate between two or three signal inputs. It can also be used to expand the Behringer 960 SEQUENTIAL CONTROLLER from an 8-step sequencer up to a 24-step sequencer.

The 962 SEQUENTIAL SWITCH features 3-channel V-Trig inputs for selecting CV input channels and separate V-Trig outputs per channel. Triggers from other modules can be connected via 3.5 mm cables and can be manually selected with the Trigger buttons.

The SIG IN jacks are what allow the 962 to alternate between inputs. Connect an input signal to input 1 or 2 and the 962 will alternate between these two inputs. If all three inputs are used, then the module will automatically alternate between the three stages.

Installing the 962 SEQUENTIAL SWITCH is simple as it was designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and screw in the module using the included screws. This allows for the 962 SEQUENTIAL SWITCH to be mixed with other synth modules for a truly unique set up.

Notes: Enter the Behringer 992 CONTROL VOLTAGES Module. An authentic reproduction of the circuitry from the Modular 55 & 35 Series used by the world's most famous pop, rock and jazz musicians. Now, musicians can build their very own, unique, synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match specific modules to create your personal, unique synth to complement the music you play or go all out and fill a room, from floor to ceiling, with modules that'll fulfill any synth geek's wildest dream.

The 992 CONTROL VOLTAGES features 4 channels for CV signals routing to the 904A LPF module. This allows your sound to be freely connected/disconnected with a flip of a switch. Putting the switch in its up position means that you are allowing your signals to connect to other modules and vice versa.

An external input is available If you have an additional input you want to connect to the 992 CONTROL VOLTAGES module. And with the inverting Attenuator knob, you can adjust the CV level of this signal by turning it clockwise to adjust the CV level from 0 to 10 or counterclockwise to change it from 0 to -10.

3 switched and summed CV inputs are present for the frequency control of VCF modules which can be connected via 3.5 mm TS cables. The 992 CONTROL VOLTAGES allows you to send out the combined voltage from all 4 inputs via 3 parallel CV outputs; which can drive multiple 904A LPF and 904B HPF modules for an unlimited number of sonic combinations.

Installing the 992 CONTROL VOLTAGES is simple as it was designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and mount the module using the included screws. This allows for the 992 CONTROL VOLTAGES to be mixed with other synth modules for a truly unique set up.

Notes: The Behringer BA 19A is designed for use with kick drums, as well as other traditional low-frequency applications including piano. Featuring an updated microphone capsule and XLR connection, BA 19A offers a strong low-frequency response and is specifically tailored for bass frequency applications. The BA 19A combines superior attack and punch for studio-quality sound, even at extremely high sound pressure level.

The BA 19A features a switchable presence filter which allows you to tailor the sound characteristics to different sound requirements and styles. The filter is adjusted via a slide switch on the microphone with different positions to boosts the presence and to boost the joy.

Place your Behringer BA 19A inside the kick drum and point towards the beater and you will capture the attack as you want it. You also can position the mic just inside the drum at the air hole, you will capture more weight and less attack.

Notes: The Octave Cat isn't the best known synth that Behringer have turned their attention to, but it's well worth a look. Similar in approach to the Odyssey but with an even broader sonic range, going from warm and fat to tough and edgy.

Supllier notes:
Great care has been taken in engineering the CAT, including the true to the original analog circuitry, legendary VCO, VCF and VCA designs that come together to recreate classic tones that are evocative of classic electronic music. This highly-focused attention to detail is what gives the CAT its ultra-flexible sound shaping capability. It gives you the ability to cover a lot of amazing tones from super-fat bass, tasty leads - and all the way to full on dreamy ambience from the far reaches of your imagination.

The synthesizer tracks laid down in the 1970s and 80s in progressive rock, wave and synth-pop have become classics and have inspired many other artists.

The CAT has the ability to accept any keyboard controller via MIDI. The signals generated can be tweaked via the Pitch Bend slider which can bend a note up or down one octave. Bump this up to two octaves by flipping the Octave Shift switch up or down. Use the Glide slider to change how fast a note transitions to another; up is faster, down is slower. Combine that with the LFO Freq slider to control the LFO and ADSR repeat tempo and you can create some amazing pulsating portamentos.

The very heart of the CAT's sound is its two VCOs. The Duophonic/Paraphonic nature of the CAT allows both oscillators to be controlled independently. Use the Fine and Coarse Frequency controls to tune VCO1 to VCO2. Keyboard control on the CAT can be set to either Mono or Poly. Poly mode lets VCO1 generate the highest note played on the keyboard while VCO2 handles the lowest allowing two notes to be played simultaneously. Setting the switch to Mono mode makes VCO1 generate the lowest note depressed on the keyboard.

Waveform switches on both VCOs allow different waveforms to be patched in from the LFO. Choose between Sine, Square, Sample and Hold and even pitch modulation through each VCO. Turning the Modulation Depth knobs in either direction controls the intensity of the effect. VCO2 also comes with a Sync switch that locks VCO1 with it and has them act as one huge oscillator to produce more complex waveforms and dramatic results. Mix VCO1 into VCO2 or vice versa and the CAT can produce some really tasty tones that make themselves at home in your next synth jam.

Each VCO on the CAT comes equipped with their own waveform sliders where you can adjust the volume of each type of VCO wave form. Pump up the Sub Octave, Sawtooth, Square, Triangle or Pulse waves or mix them all together and create some truly unique tones.

The CAT comes with another set of claws in the form of a VCF filter section. Here you can get more complex and robust tones by incorporating VCO1 into the mix. Introduce more waveforms and manipulate the Q slider to emphasize harmonics and Filter Cutoff slider which acts as a low-pass filter. Turn the CAT into a really funky bass machine or an out-of-this-world synth that creates some searing lead tones. You can even create some amazing drum sounds by manipulating the VCOs, VCF and ADSR.

The CAT features a whole slew of Inputs and Outputs that expand its capabilities beyond what you can see out of the box. You can route external control voltages to VCO1 or 2, the VCF and even pump in some external line-level audio into the CAT. You can even connect the CAT to other external synthesizers through the Gate, ADSR, AR or Keyboard Outputs. The CAT's 16-note Poly Chain function lets you combine multiple synthesizers for up to 16-voice polyphony - and it provides vastly improved reliability and stability over its 1970s and '80s predecessors.

To give the signal even more character, you can use the CAT's Transient Generator to create a detailed voltage transient every time a key is depressed. Adjust the Attack, Decay, Sustain and Release via the matching sliders and to shape your signal. The AR transient generator works similarly to the ADSR but with less detailed control over the envelope. You can also set the ADSR to automatically repeat or only when a key is held down. The Sample and Hold switch can be set so the VCO1 setting is sampled or, when set to Noise mode, produce a random output pattern. Slide the LFO Delay control up or down to determine when the LFO will reach its maximum output after a key is depressed.

The CAT has 47 controls, all laid out in a highly-intuitive format that puts the joy back into your music creation.

Notes: Enter the Behringer CP1A Module. A high-performance, ultra-low noise power supply. Easy activation of this module is facilitated by a toggle switch. There are 3 LED Indicators available for each power rail as well as a DC Input. Its narrow design helps it seamlessly fit in your modular synth.

Installing the CP1A is simple as it was designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and screw in the module using the included screws. This allows for the CP1A to be mixed with other synth modules for a truly unique set up.

Notes: Enter the Behringer CP35 ATTENUATORS Module. An authentic reproduction of the circuitry from the Modular 55, 35 and 15 Series used by the world's most famous pop, rock and jazz musicians. Now, musicians can build their very own, unique, synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match specific modules to create your personal, unique synth to complement the music you play or go all out and fill a room, from floor to ceiling, with modules that'll fulfill any synth geek's wildest dream.

The CP35 features 4 passive attenuators with linked inputs and 4 separate outputs. Each attenuator knob can be used to adjust the level of the input signal passively from - 8 to unity gain. Connecting a single signal to the first input will allow it to pass to all 4 outputs to have up to 4 variations of a single signal source. Introducing a signal into the subsequent outputs will break the chain from the previous input. For example, if you have a signal in input 2, then this will feed into input 3 and 4 leaving input 1 to feed out of output 1. Having multiple inputs allows you to attenuate 4 separate signals and be more flexible with your tone.

Along with the standard outputs, the CP35 also features 6-volt outputs. These outputs give a reference voltage of -6 Volts out of one pair and +6 Volts out the other. Also included are two banks of 4-point multiple circuits for you to be able to route multiple copies of input signals to other modules. The CP35 can be a powerful addition to your synthesizer rig by allowing you to have multiple sources output to multiple modules so you can shape and sculpt sounds that are sure to blow everyone away!

Installing the CP35 is simple as it was designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and screw in the module using the included screws. This allows for the CP35 to be mixed with other synth modules for a truly unique set up.

Notes: Enter the Behringer CP3A-O OSCILLATOR CONTROLLER module. An authentic reproduction of the circuitry from the Modular 55 and 35 series mixers used by the world's most famous pop, rock and jazz musicians. Now musicians can build their very own, unique, synthesizer that can fit in a standard Eurorack case for a very affordable price. Mix and match with specific modules to customize your synth and complement the genre of music you play or go all out and have a room filled from floor to ceiling with modules that'll fulfill any synth geek's wildest dreams.

The CP3A-O Module features 4 routing switches that enable you to send Control Voltages to one or more oscillators. Switches 1 to 3 are connected to Control Inputs 1, 2 and 3; switch 4 can be used to route an external Control Voltage signal via a 3.5 mm TS plug and can be controlled by an attenuator knob.

You can route up to three external control voltage signals to any of the three summed Control Inputs. Signals from these inputs can be combined by flipping any of the matching routing switches on. The parallel jacks at the bottom will route the final combined voltage signal to any module they're connected to. A great way to utilize the CP3A-O is to have it drive multiple 921A or B oscillator modules which can allow you to create more intricate patches and hours and hours of fun.

Installing the CP3A-O is simple as it was designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and mount the module using the included screws. This allows for the CP3A-O to be mixed with other synth modules for a truly unique set up.

Notes: The EURORACK 104 was engineered specifically to protect your favorite synthesizer modules and similar 3U electronics. With 104 HP of useable mounting space, the rugged aluminum chassis with wooden end panels features 52 sliding nuts for ultra-easy positioning of your precious gear, and the oversized rubber feet ensure rock-solid stability for a wide range of surfaces. In the studio or on the road, the EURORACK 104 is the ideal way to protect your rig, wherever the gig takes you.

Notes: Channelling the Korg MS20, Behringer serve up a desktop module with attitude. Semi-modular design plays nicely with Eurorack gear to add a dose of the aggro MS sound to your rig.

Supplier notes:
An ultra-affordable homage to that iconic synthesizer with all the features of the original and then some, the K-2 lets you conjure up virtually any sound with incredible finesse and ease. With its pure analog signal path, dual authentic VCOs with 4 selectable waveforms each, plus extremely flexible VCF and VCA filters, the K-2 is sure to become your favorite keyboard. Owning the K-2 is like having your own personal time machine, enabling you to embrace the past - or make your imprint on the future!

Your K-2 comes ready to rock, thanks to its default signal routing that doesn't require lifting a single patch cable to instantly create amazing sounds. The semi-modular architecture lets you easily tap into the inspired sounds of 1980s and '90s progressive rock, wave, EDM and synth-pop music synthesizer tracks that made rock and roll history - or to design incredibly fat and original sounds that will make you a legend in your own right!

The very heart of K-2's sound is its versatile 6 dB High/12 dB Low filter, which lets you freely experiment with the High and Low-Pass Cutoff Frequencies and their respective peak (resonance) settings to dial in the perfect sound. The high-pass filter sets the level of signals below the cutoff frequency, effectively reducing the fundamental and lower-order harmonics levels. The low-pass filter controls the level of signals above the cutoff, which reduces higher-order harmonic content. K-2's VCF Peak controls provide emphasis to the signals at the crossover frequency.

K-2's authentic Voltage Controlled Oscillators (VCOs) provides an incredible range of 4 variable oscillator shapes with variable pulse widths and ring modulation for the ultimate in sound creation. VCO 1 waveform choices include triangle, reverse-sawtooth, noise and pulse, where the pulse width can be adjusted from square wave to narrow across a 4-octave range (32', 16', 8', or 4'). VCO 2's waveform can be selected from reverse-sawtooth, square, narrow pulse and ring, where both oscillators are operating. VCO 2's pitch can also be varied independently across a 4-octave range (16', 8', 4' and 2'). The VCO Mixer allows you to adjust the levels of VCO 1 and VCO 2 to create an overall mix and a wide range of amazing effects.

K-2's Low Frequency Oscillator (LFO), the Modulation Generator, features a selectable Waveform (reverse sawtooth, triangle, sawtooth) with a sweepable frequency range from 0.1 to 22 Hz - and 2 separate Envelope generators to help you craft incredible sounds! Envelope Generator 1 affects the frequency modulation via controls for Delay, Attack and Release Time, while generator 2 adjusts the cutoff frequency modulation, as well as amplitude modulation of the Voltage Control Amplifier (VCA). Dials for this generator include Hold, Decay, Attack, Sustain, and Release for unparalleled envelope-shaping control.

While it is a monophonic instrument (one note at a time), K-2's 16-note Poly Chain function lets you combine multiple synthesizers for up to 16-voice polyphony - plus provides vastly improved reliability and stability over its 1970s and '80s predecessors.

Designed to handle the rigors of life on the road or in the studio, your K-2 can easily be transferred into a standard Eurorack case for the perfect integration into your existing system.

For those who want the numbers, K-2 has 36 controls, all laid out in a highly-intuitive format that puts the joy back into your music creation. And you can expand K-2's tone-sculpting capabilities beyond your wildest dreams by utilizing the multi-I/O patchbay to connect external devices at virtually any point in the signal path!

Notes: An ultra-affordable homage to that iconic synthesizer with all the features of the original and then some, such as a 32-step sequencer, arpeggiator and live performance kit, the MS-1-BK lets you conjure up virtually any sound with incredible finesse and ease. With its 32 semi-weighted full-size keys, pure analog signal path, authentic 3340 VCO with 4 simultaneously-mixable waveforms, plus extremely flexible VCF and VCA filters, the MS-1-BK is sure to become your favorite keyboard. Owning the MS-1-BK is like having your own personal time machine, enabling you to embrace the past - or make your imprint on the future!

Great care has been taken in engineering the MS-1-BK, including the true to the original analog circuitry, legendary VCO, VCF and VCA designs, all of which combine to make it easy to recreate the classic sound performance. This highly-focused attention to detail is what gives the MS-1-BK its ultra-flexible sound shaping capability, which covers everything from super-fat bass and lead tones to stunning effects - and all the way out to the otherworldly sounds of your imagination.

The inspired synthesizer tracks laid down in the 1980s and '90s are etched in the annals of progressive rock, wave, EDM and synth-pop music forever, making them truly classic in every sense of the word. The MS-1-BK lets you recreate all of that magic - or design incredibly fat and original sounds.

MS-1-BK's authentic 3340 Voltage Controlled Oscillator (VCO) provides an incredible range of 4 simultaneously-mixable waveforms for sculpting the perfect sound. Options include: saw, triangle, square/pwm and octave-divided square sub-oscillator. Additionally, the VCO can be adjusted across a wide, 4-octave range (16', 8', 4', and 2'). This amazing flexibility gives you the tools needed to be your creative best.

The very heart of MS-1-BK's sound is its highly-flexible Voltage Control Filter (VCF), which includes faders for: cutoff Frequency (10 Hz to 20 kHz); Resonance (0 to self-oscillation); Envelope and Modulation depth, and Keyboard follow (0 to 100%) to dial in the perfect sound. MS-1-BK's VCF can be modulated via the ADSR, keyboard tracking and Bender controller. The Frequency Modulation (FM) Amount knob sets the depth, while the FM Source selector lets you further modify the signal by choosing from: pulse; sawtooth; sub oscillator 1 octave down; 2 octaves down; narrow 2 octaves down, and Noise.

MS-1-BK's Envelope generator features 4 ADSR (Attack, Decay, Sustain and Release) faders that help you craft incredible sounds, and utilizes a 3-position switch for Gate, Gate + Trigger and LFO. When applied to the Voltage Control Amplifier (VCA), the ADSR envelope is used to control the level of the note being played over time. When applied to the VCF, the ADSR envelope is used to control the cut-off frequency of the filter for each note played over time. In addition, the ADSR envelope can also be used to affect the VCO pulse width modulation.

MS-1-BK's sequencer allows you to program up to 32 steps of notes and rests and save them as a pattern. You can record, save and recall up to 64 patterns, all of which can be stored in the 8 banks, each holding up to 8 patterns. Your sequences can be played either in Keyboard mode, where you create and store the pattern, or Step mode, which allows you to interact while composing a pattern. The onboard Arpeggiator features 8 patterns (you can use just by playing a chord, which the arpeggiator then sequences through your selected pattern. Both the sequencer and arpeggiator in the MS-1-BK are fun, mesmerizing and totally addictive.

When you're ready to strut your stuff and get a little centerstage time, the MS-1-BK has that covered too! Just attach the included guitar strap and handgrip (with pitch bend wheel and a pitch modulation trigger), and take your performance to the next level.

In addition to the great sound-sculpting features already mentioned, the MS-1-BK has still more to offer. The noise generator can also be used as modulation source to create distortion-like effects, which will send your solo soaring into the stratosphere. Glide (portamento) lets you sweep seamlessly over time from one note to the next, creating smooth-as-silk transitions that few other instruments can emulate. MS-1-BK's Bender is also assignable to the VCO, VCF and pitch mod wheel on attachable handgrip. You can even modulate the pulse wave via the LFO, envelope or manually - for sounds ranging from mild to wild!

For those who want the numbers, MS-1-BK has 57 knobs, faders and switches, all laid out in a highly-intuitive format that puts the joy back into your music creation. Input and output connections include: MIDI I/O and Thru over USB/MIDI DIN; Velocity Out; CV; Gate; External Clock In; VCF CV In; Hold; External Audio; Phones; and main Output.

Notes: An ultra-affordable homage to that iconic synthesizer with all the features of the original and then some, such as a 32-step sequencer, arpeggiator and live performance kit, the MS-1-BU lets you conjure up virtually any sound with incredible finesse and ease. With its 32 semi-weighted full-size keys, pure analog signal path, authentic 3340 VCO with 4 simultaneously-mixable waveforms, plus extremely flexible VCF and VCA filters, the MS-1-BU is sure to become your favorite keyboard. Owning the MS-1-BU is like having your own personal time machine, enabling you to embrace the past - or make your imprint on the future!

Great care has been taken in engineering the MS-1-BU, including the true to the original analog circuitry, legendary VCO, VCF and VCA designs, all of which combine to make it easy to recreate the classic sound performance. This highly-focused attention to detail is what gives the MS-1-BU its ultra-flexible sound shaping capability, which covers everything from super-fat bass and lead tones to stunning effects - and all the way out to the otherworldly sounds of your imagination.

The inspired synthesizer tracks laid down in the 1980s and '90s are etched in the annals of progressive rock, wave, EDM and synth-pop music forever, making them truly classic in every sense of the word. The MS-1-BU lets you recreate all of that magic - or design incredibly fat and original sounds that will make you a legend in your own right!

MS-1-BU's authentic 3340 Voltage Controlled Oscillator (VCO) provides an incredible range of 4 simultaneously-mixable waveforms for sculpting the perfect sound. Options include: saw, triangle, square/pwm and octave-divided square sub-oscillator. Additionally, the VCO can be adjusted across a wide, 4-octave range (16', 8', 4', and 2'). This amazing flexibility gives you the tools needed to be your creative best.

The very heart of MS-1-BU's sound is its highly-flexible Voltage Control Filter (VCF), which includes faders for: cutoff Frequency (10 Hz to 20 kHz); Resonance (0 to self-oscillation); Envelope and Modulation depth, and Keyboard follow (0 to 100%) to dial in the perfect sound. MS-1-BU's VCF can be modulated via the ADSR, keyboard tracking and Bender controller. The Frequency Modulation (FM) Amount knob sets the depth, while the FM Source selector lets you further modify the signal by choosing from: pulse; sawtooth; sub oscillator 1 octave down; 2 octaves down; narrow 2 octaves down, and Noise.

MS-1-BU's sequencer allows you to program up to 32 steps of notes and rests and save them as a pattern. You can record, save and recall up to 64 patterns, all of which can be stored in the 8 banks, each holding up to 8 patterns. Your sequences can be played either in Keyboard mode, where you create and store the pattern, or Step mode, which allows you to interact while composing a pattern. The onboard Arpeggiator features 8 patterns (you can use just by playing a chord, which the arpeggiator then sequences through your selected pattern. Both the sequencer and arpeggiator in the MS-1-BU are fun, mesmerizing and totally addictive.

When you're ready to strut your stuff and get a little centerstage time, the MS-1-BU has that covered too! Just attach the included guitar strap and handgrip (with pitch bend wheel and a pitch modulation trigger), and take your performance to the next level.

In addition to the great sound-sculpting features already mentioned, the MS-1-BU has still more to offer. The noise generator can also be used as modulation source to create distortion-like effects, which will send your solo soaring into the stratosphere. Glide (portamento) lets you sweep seamlessly over time from one note to the next, creating smooth-as-silk transitions that few other instruments can emulate. MS-1-BU's Bender is also assignable to the VCO, VCF and pitch mod wheel on attachable handgrip. You can even modulate the pulse wave via the LFO, envelope or manually - for sounds ranging from mild to wild!

For those who want the numbers, MS-1-BU has 57 knobs, faders and switches, all laid out in a highly-intuitive format that puts the joy back into your music creation. Input and output connections include: MIDI I/O and Thru over USB/MIDI DIN; Velocity Out; CV; Gate; External Clock In; VCF CV In; Hold; External Audio; Phones; and main Output.

Notes: Behringer's tribute to the ARP Odyssey is a pleasingly retro instrument. Fully analogue duophonic goodness with that classic tough ARP sound, great for bass and leads.

Supplier notes:
An ultra-affordable homage to the legendary ARP* synthesizer of the '70s and beyond with all the features of the original and then some including: dual VCOs; 32-step sequencer with onboard storage; arpeggiator and world-class Klark Teknik FX that boast reverb, chorus, flanger, delay, pitch shifter and multi-effects, the ODYSSEY lets you conjure up virtually any sound with incredible finesse and ease. With its 37 semi-weighted full-size keys, pure analog signal path based on authentic VCO, VCF and VCA designs from the '70s, the ODYSSEY is sure to become your favorite keyboard. Owning the ODYSSEY is like having your own personal time machine, enabling you to embrace the past - or make your imprint on the future!

Great care has been taken in engineering the ODYSSEY, including the true to the original analog circuitry, legendary VCO, VCF and VCA designs, all of which combine to make it easy to recreate the classic sound performance. This highly-focused attention to detail is what gives the ODYSSEY its ultra-flexible sound shaping capability, which covers everything from super-fat bass and lead tones to stunning effects - and all the way out to the otherworldly sounds of your imagination.

The inspired synthesizer tracks laid down in the 1970s are etched in the annals of progressive rock, disco and synth-pop music forever, making them truly classic in every sense of the word. The ODYSSEY lets you recreate all of that magic - or design incredibly fat and original sounds that will make you a legend in your own right!

ODYSSEY's 2 voices are the product of dual analog Voltage Controlled Oscillators (VCOs), which each provide your choice of: sawtooth, square/pulse with pulse-width modulation, or sine/square wave LFO for sculpting the perfect sound. This amazing flexibility gives you the tools needed to be your creative best.

The very heart of ODYSSEY's sound is its highly-flexible Voltage Control Filter (VCF), which includes faders for: Frequency; Resonance (0 to self-oscillation); and High Pass Filter (HPF) Cutoff Frequency. A feature missing from the original is a new 3-position switch, which lets you choose the VCF filter you prefer from all 3 iterations of the famous synth: 2-pole MKI (4023); 4-pole MKII (4035); and 4-pole MKIII (4075), plus a Drive switch to add a touch of edge to your sound.

ODYSSEY features two easy-to-use Envelope Generators, AR (Attack and Release) and ADSR (Attack, Decay, Sustain and Release) with 2 and 4 faders, respectively to help you craft incredible sounds. Switches are provided for ADSR Gate/LFO Repeat, AR Gate/LFO Repeat or thirdly, Keyboard Repeat/Auto Repeat - which provides a wide range of performance options.

ODYSSEY's sequencer allows you to program up to 32 steps of notes and rests and save them as a pattern. You can record, save and recall up to 64 patterns, all of which can be stored in the 8 banks, each holding up to 8 patterns. Your sequences can be played either in Keyboard mode, where you create and store the pattern, or in Step mode, which allows you to interact while composing the pattern. The onboard Arpeggiator features 8 patterns (you can use just by playing a chord, which the arpeggiator then sequences through your selected pattern. Both the sequencer and arpeggiator in the ODYSSEY are fun, mesmerizing and totally addictive.

For those who want the numbers, ODYSSEY has 35 sliders, 25 switches and 3 pressure-sensitive buttons, all laid out in a highly-intuitive format that puts the joy back into your music creation. Input and output connections include: MIDI In and Out over USB/MIDI DIN; Pedal; Portamento Footswitch; Low and High Outputs; External Audio In; CV In and Out; Gate In and Out, and Phones with a dedication Volume control.

In addition to the great sound-sculpting features already mentioned, ODYSSEY has still more to offer. There's the pink/white noise generator with sample & hold plus lag processor; Portamento, which lets you sweep seamlessly over time from one note to the next, creating smooth-as-silk transitions that few other instruments can emulate; and the 3 pressure-sensitive buttons for pitch and modulation control that provide a total hands-on performance. ODYSSEY is the ideal tone-making machine for creating sounds that run the gamut - from mild to wild!

Notes: A heavy duty microphone stand with adjustable boom, ergonomic height grip and foldable tripod base. Suitable for all live performance and recording situations.

Notes: Straight microphone stands with cast iron base. Stackable in sixes.

Notes: Compact format audio mixer with 2, 4 or 6 mono input channels and a stereo line input. Each mono channel has a combo XLR/jack input with individually switchable mic/instrument impedance and +48V phantom power for the XLR. Input channels have High/Low EQ and Pan controls. The B/T pairing button enables wireless connection to a smart phone or tablet for playback. All CSD mixers feature a 16 program DSP effects section with digital reverbs, delays and modulation effects for vocals and instruments. Output is delivered on a pair of balanced XLR connectors and offers very low noise operation for high quality studio or live performances.

The box for this item contains :

CSD series compact mixer
5Vdc power adaptor

Notes: Ultra-compact 8-channel mixer with two-band EQs, 24-bit digital effects and Bluetooth streaming for convenience. One of the smallest 8-channel mixers on the market.

Supplier notes:
Compact format audio mixer with 2, 4 or 6 mono input channels and a stereo line input. Each mono channel has a combo XLR/jack input with individually switchable mic/instrument impedance and +48V phantom power for the XLR. Input channels have High/Low EQ and Pan controls. The B/T pairing button enables wireless connection to a smart phone or tablet for playback. All CSD mixers feature a 16 program DSP effects section with digital reverbs, delays and modulation effects for vocals and instruments. Output is delivered on a pair of balanced XLR connectors and offers very low noise operation for high quality studio or live performances.

The box for this item contains :

CSD series compact mixer
5Vdc power adaptor

Notes: Fully featured live mixing console with 14 mono mic/line inputs on XLR/jack and 2 stereo line jack inputs. All channels have gain, 3-band EQ, switchable pre/post aux output, FX send, pan, PFL switch and 60mm channel faders. Phantom power is switchable to all XLR inputs for condenser microphones and active DI boxes. Internal effects take the form of a 16-program 24-bit DSP engine with independent level fader and AFL switch for monitoring. An inbuilt media player can accept a USB memory stick for playback of stored audio tracks and can also record the mix output for documenting rehearsals or performances. B/T wireless compatibility enables pairing with a smart phone or tablet for remote playback. Global EQ is handled by a 7-band graphic EQ and the overall mix is fed from master faders to left & right balanced XLR outputs. A 2-track RCA line input has a level control for mixing in a playback source. 2-track RCA output can be connected on to recording equipment or as an additional output feed if required. Low noise and clean audio path with enough features and routing options for live performances, conferences and theatre productions.

The box for this item contains :

CSX-18 mixing console
IEC power lead

Notes: The distillation of Dynaudio's extensive speaker knowledge in a compact two-way nearfield design. Bass response as low as 45Hz thanks to DSP bass extension.

Supplier notes:
This monitor uses sophisticated DSP to extend or its curtail low-frequency response by 10Hz, while Position and Sound Balance controls let you fine-tune for total neutrality in your environment. Its larger 7in woofer helps extend bass, while the low-mass aluminium voice-coil, vented ferrite magnet and MSP driver take care of precision.

Notes: This project is a reprise of the Sound Lab Mini-Synth with the addition of a Sample and Hold and several circuit and component value changes to improve performance. Even if you already have a Sound Lab, this is thoroughly recommended as a completely new project.New design and a new MIDI INTERFACE onboard.

You can play your SLMS+ with a midi keyboard or midi controller.

Type: Analog Synthesis: Subtractive

Oscillators: 2 Waveforms: Pulse, Pulse Variable, Saw Down, Square Osc Modulation: Envelope, Input, Knob, LFO, Sync Hard

Envelope: 1 Evelope

Paramerters: Attack, Decay, Looping

Filters: 1 Types: 12dB Slope (2-pole), Low Pass, Resonance Filter Modulation: Envelope, Knob, LFO, S&H

Lfo: 1 LFO Parameters: Saw Up, Saw Down, Square, Triangle

Sample & Hold Addon: variable sample rate - output voltage glide - switch to select source to be modulate

Midi cannel: 1 (not exchangeable) Midi port: MIDI IN, MIDI THRU Control change: pitch bend, modulation , portamento (CC 5) 1V/Oct: 5 octaves

IMPORTANT: POWER ON SOUNDLAB WHEN YOUR MIDI SEQUENCER IS IN STOP MODE! MICROCONTROLLER CAN GENERATE MIDI SIGNAL ERROR IF YOUR SEQUENCER IS IN PLAY MODE.

Polyphony: 1 Timbrality

1 Tuning: Standard Modes: Mono

Desktop Controls: Knobs, Switches, Buttons Display Type: LED Dimension: 27 x 16 x 7 (cm) Material: Plexiglass Front panel: Aluminum (1mm thick)

Connections: Audio Output Connections: 1/4" Phone Jack, Mono Out

Power: 9V power supply 300 mA (euro) Audio Output Count: 1 Control voltage: 2 - 1V/Oct (1/4" Phone Jack/3,5 mini jack) Gate in: 1 (1/4" Phone Jack/3,5 mini jack) IMPORTANT NOTE: TO USE GATE/MIDI

Notes: The Erica Black CV Expander is the satellite module to our HADSR envelope generator, it allows each envelope parameter to be controlled via external control voltage CV.

With this module you get unpredictable, complex envelopes that are ideal for random drones. It is internally patched to the Black Envelope generator via a ribbon cable, supplied with the module.

Erica Black series are high-end modules with unique functionality. Only the highest quality components are used and all inputs and outputs are protected against undesired overvoltage. When designing the Black Series, design and usability were the hghest priority. Big knobs are assigned to functions that make difference in sound. Together the Erica Black series are a range of modules that make an entire synthesizer.

Technical specifications:

CV Input signal level; -10V - +10V
Power consumption: +15mA, -15mA
Module width: 8HP
Module depth: 25mm

Notes: Erica Synths Black Dual VCF is a dual multimode filter with CV control over cutoff and resonance for serious modular patches.

At the core of this VCF is a highly stable, custom multimode VCF chip AS3320 (produced in Riga, btw). This module can be used as two independent VCFs with simultaneous HP, BP and LP outputs, controls can be linked to stereo application and both VCFs can be chained in series or parallel to the summing output for ultimate modulations. Bonus feature - the 16 band spectrum analyser gives you visual feedback on what happens on summing output.

Technical specifications:

Audio output amplitude: 10 Vptp
CV input (full sweep): 10 Vptp
Panel width: 18HP
Module depth: 35mm
Power consumption: 40mA@+12V, 36mA@-12V

Notes: Erica Synths Black Pre-fade Listen Expander is a satellite module for Erica Synths Black Stereo Mixer.

Since modular performances are often about uncertainty, unpredictability and sudden filter resonance screams that can kill loudspeakers, it's good to know what is it that you are about to fade into your modular mix and this is where the Black PFL Expander comes in! You can monitor each of four Black Stereo Mixer inputs or any combination of them before mixer level knob takes effect.

NB: Black PFL Expander is designed to work with both Erica Synths Black Stereo Mixer V2 and V3. The module doesn't have a PSU connector therefore it can not be used on it's own.

Technical specifications:

Power consumption:+15mA, -7mA
Module width: 12HP
Module depth: 25mm

Notes: Erica Syths Black VC EG Expander takes the Black VC EG to the next level - it outputs gates or CVs for each active stage of the envelope so you can design some really advanced patches. Inverted and bipolar envelope outputs are also available.

Erica Black series are high-end modules with unique functionality. Only the highest quality components are used and all inputs and outputs are protected against undesired overvoltage. When designing the Black Series, we did not economise on the module width, we put design and usability first. Big knobs are assigned to functions that make difference in sound. Together the Erica Black series are a range of modules that make an entire synthesizer.

NB: This expander module can be connected only to the Black VC EG. It will not work as a standalone eurorack module.

Notes: The QSlider is an analog CV source with four 60 mm faders.

The control range of the four sliders can be set with two min/max controls.

The Min control sets the output voltage at zero position of the slider and the Max control sets the output voltage at the end position of the slider. The slider now controls between these two voltages. This allows you to limit the control range and still have the full control range of the slider available.

At a second output socket the inverted voltage is available (Min and Max are reversed). So the slider can also be used as a crossmix fader.

Two common channels can be operated uni- or bipolar. The voltage ranges are 0..+10V or +/- 5V.

The output sockets are located on an extra 4HP panel for mounting at any place (with approx. 40cm long connection cable). This way several modules can be mounted seamlessly next to each other.

HP : 18

Notes: Guitar & bass pedalboards are all about exploring new tones & textures, creating a wide range of sound for your instrument. Z-TONE Buffer Boost takes your live rig to a new level, letting you shape the sound of your instrument with the input circuits from our award-winning
AXE I/O interface.

Change the tone & feel of your guitar or bass, buffer your tone to survive even the biggest pedalboard, kick in the boost and supercharge all your existing gear with a powerful new front-end.

Z-TONE Buffer Boost offers a high-quality instrument preamp with exceptionally low noise and wide frequency response, and multiple circuit topologies to adapt to any type of guitar, pick-up and style.

Guitar pickups can dramatically change their character depending on impedance - many amps offer a load of 1 MOhms, while pedals can run much lower. That's why the tone and responsiveness of your guitar can change when plugging into different gear.

Z-TONE Buffer Boost gives you the same variable impedance control as our groundbreaking
AXE I/O audio interface, from 1 MOhm to 2.2 kOhms. At the maximum impedance, you'll find your sound tighter, sharper and more precise. Increase the load and the sound becomes thicker and more bold.

You can use this control to coax a wider range of sounds from a single guitar, experiment with how the rest of your rig reacts to these changes, or dial in exactly the right vibe regardless of what comes next in your chain.

Long cable runs, low-impedance stomps and complex routing can degrade your guitar's signal, causing muffled, bassy or lifeless tone. To ensure your signal always stays crystal-clear, Z-TONE Buffer Boost offers a transparent output buffer so you always sound your best.

And Z-TONE Buffer Boost offers a true bypass circuit, so it's completely transparent when not in use.

In addition to the "Link" amp & pedal output, Z-TONE Buffer Boost offers a balanced XLR output to connect to mixers & PAs. Skip the amp and perform direct, or mix clean and processed signals to create even more tonal options.

A switchable ground lift eliminates noise and hum caused by ground loops, and an unbalanced 14" output offers additional flexibility. Now you're ready to connect in any situation.

And Z-TONE Buffer Boost runs on a standard 9V battery, +48v phantom power from your mixer or 9V pedal power supply, so it's easy to drop onto your existing pedalboard.

Want to add killer Z-TONE tone shaping to all your gear? Check out Z-TONE DI offering the same killer features in a convenient direct box for studio and stage use.

Or check out AXE I/O and AXE I/O SOLO, IK's range of premium audio interfaces offering the same great tone-shaping features, and find out just how easy creating best-in-class guitar recordings can be.

Notes: Adjustable for both height and angle with a large span tripod base with rubber feet for stability. The boom arm section is fully adjustable with a bar type locking ring. This stand is suitable for almost every miking application due to its versatility and height adjustment. Black finish with microphone clip and cable clip.

Notes: Building your own custom effects pedal from scratch is now possible with the OD-S Overdrive kit. Experience the fun of DIY by easily building and customizing your own overdrive pedal; no soldering required! Furthermore, the OD-S is equipped with a powerful Nu:tube fully analog triode vacuum tube for a warm sound and rich harmonic response that will delight all guitarists. Build your own FX pedal Creating your own pedal can seem like a daunting task and the results aren't guaranteed. The OD-S offers a solderless, easy-to-build kit that is also customizable to help you shape the overdrive tone that's as individual as you. Authentic tube sound Nutube is a new and revolutionary fully analog triode vacuum tube developed by KORG INC. and Noritake Itron Corporation. The same as a conventional vacuum tube, Nutube is constructed with an anode, grid and filament, and operates as a complete triode tube, effectively generates the same performance response and rich harmonic characteristics of conventional vacuum tubes in a more compact, stable and energy-efficient way. Plenty of sonic possibilities The OD-S has 2 GAIN knobs. In addition to adjusting the input level to the vacuum tube (GAIN), the anode load of the vacuum tube amplification circuit can be changed using the TUBE GAIN. This allows you to accurately adjust the sound from the vacuum tube to your liking. The OD-S also incorporates a switch that lets you choose between 2 different overdrive types (with different Low - High ranges) along with True Bypass; making it an ideal pedal for live performances. For advanced users who want to customize their tone further, the modification-friendly layout allows you to change out discrete components to create your own unique pedal to match your desired tone and performance. The possibilities are endless.

Specifications:
Vacuum Tube: Nutube 6P1
Connections: INPUT/OUTPUT (monaural stereo jack), DC 9V stereo minijack
Power: Single 9V alkaline battery(6LF22/6LR61) (sold separately) or a DC9V AV adapter (sold separately) KA181(DC9V)
Battery life: Approx. 10 hours
Power Consumption: 46mADimension
(W x D x H):122.×.96.×.55mm.
Weight: 340g (without batteries)
Options: KORG AC adapter KA181 (DV9V)

Notes: The perfect upgrade for your desktop speakers, CR Series monitors deliver the performance you expect from a Mackie studio monitor. Ideal for home studios, multimedia content creation, AV post-production, gaming, broadcast and more, CR Series monitors offer studio-quality sound in a compact, well-designed package that's equally at home in a high-end project room or your bookshelf.

Designed for premium sound that won't break the bank, CR Multimedia Monitors deliver the performance you expect from a Mackie studio monitor in designs ideal for home studios, multimedia creation, AV post-production and broadcast. Plus, with user-friendly front panel features and two models featuring Bluetooth for music streaming, they are great for any desktop in any situation.

CR monitors deliver a combination of high-quality components and professional build quality typically only found on more expensive studio monitors. But, they are affordable and ultra-compact. Switch from video editing to music listening in no time flat. Edit a video, then watch a video. You are a multi-tasker who appreciates great sound. Whether you are looking for great studio speakers or want to upgrade your gaming audio, CR helps you in all aspects of your multimedia creation and enjoyment.

Notes: Affordable entry-level multimedia speakers designed as a first step into studio-style monitoring. Clean sound and good bass response from a small design.

Supplier notes:
The perfect upgrade for your desktop speakers, CR Series monitors deliver the performance you expect from a Mackie studio monitor. Ideal for home studios, multimedia content creation, AV post-production, gaming, broadcast and more, CR Series monitors offer studio-quality sound in a compact, well-designed package that's equally at home in a high-end project room or your bookshelf.

Designed for premium sound that won't break the bank, CR Multimedia Monitors deliver the performance you expect from a Mackie studio monitor in designs ideal for home studios, multimedia creation, AV post-production and broadcast. Plus, with user-friendly front panel features and two models featuring Bluetoothr for music streaming, they are great for any desktop in any situation.

CR monitors deliver a combination of high-quality components and professional build quality typically only found on more expensive studio monitors. But, they are affordable and ultra-compact. Switch from video editing to music listening in no time flat. Edit a video, then watch a video. You are a multi-tasker who appreciates great sound. Whether you are looking for great studio speakers or want to upgrade your gaming audio, CR helps you in all aspects of your multimedia creation and enjoyment.

Notes: The perfect upgrade for your desktop speakers, CR Series monitors deliver the performance you expect from a Mackie studio monitor. Ideal for home studios, multimedia content creation, AV post-production, gaming, broadcast and more, CR Series monitors offer studio-quality sound in a compact, well-designed package that's equally at home in a high-end project room or your bookshelf.

Designed for premium sound that won't break the bank, CR Multimedia Monitors deliver the performance you expect from a Mackie studio monitor in designs ideal for home studios, multimedia creation, AV post-production and broadcast. Plus, with user-friendly front panel features and two models featuring Bluetoothr for music streaming, they are great for any desktop in any situation.

CR monitors deliver a combination of high-quality components and professional build quality typically only found on more expensive studio monitors. But, they are affordable and ultra-compact. Switch from video editing to music listening in no time flat. Edit a video, then watch a video. You are a multi-tasker who appreciates great sound. Whether you are looking for great studio speakers or want to upgrade your gaming audio, CR helps you in all aspects of your multimedia creation and enjoyment.

Notes: The perfect upgrade for your desktop speakers, CR Series monitors deliver the performance you expect from a Mackie studio monitor. Ideal for home studios, multimedia content creation, AV post-production, gaming, broadcast and more, CR Series monitors offer studio-quality sound in a compact, well-designed package that's equally at home in a high-end project room or your bookshelf.

Notes: Pretty much a complete recording studio in a box. Monitors, controller, interface, headphones, mics and software offer everything you need to get started recording music.

Supplier notes:
Mackie's new Studio Bundle includes all the tools you need to create and mix professional recordings and gives you room to grow. The central hub of the Studio Bundle is Mackie's Big Knob Studio Monitor Controller | Interface, which lets you select between three audio sources and two pairs of monitor speakers, while providing 2-in, 2-out, 24-bit/192 kHz USB recording and playback. The Big Knob features two boutique-quality Mackie Onyx mic preamps for professional-quality recording and provides phantom power for condenser microphones.

Other professional features include mono, mute, and dim functions; dual headphone outs with independent level control; and a built-in talkback mic for easy communication with artists. A wealth of inputs and outputs, including an 1/8-inch input for media players and smartphones, makes it easy to expand your rig. The Big Knob is compatible with all major DAWs for macOS and Windows. It comes with a full suite of recording and production software, including Pro Tools | First and Waveform OEM recording software, the Musician Collection for Pro Tools, and the DAW Essentials Bundle for Waveform OEM.

The Mackie Studio Bundle enables you to monitor with either a pair of CR3-X multimedia monitors or MC-100 professional headphones. You can capture virtually any sound with the EM-91C large diaphragm condenser microphone and EM-89D dynamic vocal microphone.
