Artículos del 1 al 50 de 119 en la página 1 de 3
1  2  3  »
Intellijel Quad VCA Voltage Controlled Amplifier & Cascaded Mixer Module
Cat: 643379 Rel: 13 Sep 17

Quad voltage controlled amplifier & cascaded mixer - 12HP wide
Notes: The Quad VCA is a compact and feature packed module that is sure to find its way it almost all of your patches. In addition to being used for standard VCA duties it can also be used as a mixer and signal booster.

Features:

- Manual LEVEL control per VCA which is convenient when using the module as a mixer or for biasing when CV modulating the VCA with a bipolar LFO.
- Dedicated CV attenuators with dual colour LEDs for monitoring bipolar CV signals.
- Continuously adjustable response from linear to exponential per VCA.
- Each CV input is normalled to the adjacent one for cascaded control.
- Each output is normalled to the mix input of the adjacent one which allows you to use adjacent sets as submixes or the fourth output can be used as a master mix output when none of the other outputs are patched.
- Each VCA has a boost switch that increases the output level by approximately +6dB (double).
Read more
 More than 10 in stock $180.83
Intellijel Quadratt 1U Quad Attenuator Attenuverter Mixer & DC Voltage Source Module
Cat: 602205 Rel: 04 Apr 16

Quad attenuator, attenuverter, mixer and DC voltage source - 28HP wide
Notes: The shorter and wider brother to the popular Triatt module!

The four handy knobs can act as active attenuators (unipolar) or attenuverters (bipolar) depending on the setting of the two-position switches above each one.

Each input is normalled to a precision +5V DC voltage source. With nothing plugged into the jacks, each knob controls a voltage range of 0 to +5 v or -5 to +5 v depending on the position of the mode switch.

- 2 modes for each channel
- 5v normalled to each input
- With external signals it acts as active/buffered attenuator/attenuverter/mixer
- Each output normalled to mix into the adjacent channel on the right making it possible to do sub mixes in groups of 2, 3 or all four channels.
Read more
 7 in stock $87.18
Click for better price!
or call +44 20 7424 1960
quote 602205
ALM Tangle Quartet Quad Linear VCA & Mixer Module
ALM Tangle Quartet Quad Linear VCA & Mixer Module (quad/VCA/mixer/attenuator synth module)
Cat: 584259 Rel: 15 Apr 16

High quality quad linear voltage controlled amplifier (VCA) synthesiser module - 8HP wide
Notes: 'Tangle Quartet' is a high quality quad linear voltage controlled amplifier (VCA) providing individual level control of 4 signal inputs with both individual outputs and a combined 'mix' output (for non patched outputs) . Control signal inputs and associated attenuation controls allow for voltage control of signal levels. Control inputs are normalised to 5v thus providing manual mix control in the absence of control signals.

Technical Specifications:

Supply: +/-12V (Reverse voltage protection)
Current Draw: ~80ma
Size: 8 HP
Depth: 32mm (including power header)
Read more
 5 in stock $184.05
Click for better price!
or call +44 20 7424 1960
quote 584259
Doepfer A-138n Narrow Mixer Module (silver, slim line)
Cat: 731947 Rel: 10 Jun 19

4-channel mixer - 4HP
Notes: Module A-138n is a simple four channel mixer, which can be used with either control voltages or audio signals. Each of the four inputs has an attenuator available. The output is twice available (two sockets, hard-wired like a multiple).

The module is the slim version of module A-138a and offers nearly the same features. But the distances between the controls are smaller and rubberized small-sized knobs are used. In return the front panel has 4 HP only which is half the width of the A-138a. The module is primarily planned for applications where only limited space is available. The only functional difference compared to the A-138a is the missing attenuator for the (dual) output.

Width: 4HP / 20.0 mm
Depth: 30 mm (measured from the rear side of the front panel)
Current: +10mA (+12V) / -10mA (-12V)
Read more
 1 in stock $64.57
Click for better price!
or call +44 20 7424 1960
quote 731947
Befaco STMix 4-Channel Stereo Mixer Module
Befaco STMix 4-Channel Stereo Mixer Module (dual/stereo/mixer synth module)
Cat: 716763 Rel: 14 Feb 19

Stereo mixer - 6HP
Notes: Stmix is a compact 4 channel stereo mixer with an Auxilliar input. This input will allow us to chain a few of them or to insert an extra fifth input.

This module is compatible with Befaco's Hexmix system, and can be internally connected to hexmix module to add the output of STMIX to your main mix.

Specs

Current needs: +12V: 8mA, -12V: 10mA
Width: 6 HP
Depth: 20mm (including power connector)
Aluminiun, heat-treated front panel
Designed, kits prepared and completed modules assembled in Barcelona
Read more
 1 in stock $144.23
Click for better price!
or call +44 20 7424 1960
quote 716763
Intellijel Planar 2 Recordable Joystick & Vector Mixer/Router Module
Intellijel Planar 2 Recordable Joystick & Vector Mixer/Router Module (controller/CV modulation/mixer/panning/envelope generator synth module)
Cat: 677564 Rel: 24 Aug 18

Joystick/vector mixer for CV or Audio - 14HP
Notes: The most complex modulator is you. The Planar 2 puts macro control over six outputs - including a quad panning mixer - into your hands with a buttery smooth joystick. Record up to 30 seconds of your own movements, stretch it or mangle it with scan mode, use a trigger for playback, or just loop it - synced or not. Add yourself to your patch.

With its smoothly responsive precision joystick, Planar 2 facilitates hands-on vector control of two entirely independent sets of outputs (quadrants A-D, and axis X/Y), plus the ability to capture and playback your gestures. Recording your joystick movements enables the creation of organic and complex envelopes, wild and wobbly LFOs, or extended sonic evolutions. It mixes, morphs, routes and pans audio inputs; triggers gates; outputs control voltages and is itself, CV-controllable. Planar 2 puts the 'joy' back in 'joystick,' and the 'fun' back in 'function generator.' Its multitasking and tactile interface makes it a flexible and unique control device, no matter what your musical genre.
Read more
 3 in stock $357.36
Click for better price!
or call +44 20 7424 1960
quote 677564
Doepfer A-138sv Mini Stereo Mixer Vintage Edition Module (black)
Doepfer A-138sv Mini Stereo Mixer Vintage Edition Module (black) (dual/stereo/mixer/panning/quad synth module)
Cat: 684443 Rel: 30 Apr 18

Four-channel stereo mixer - 8HP
Notes: A-138s is a simple but useful 4-in-2 mixing tool. It has four inputs available. Each input is equipped with an attenuator (Level) and a panning control that is used to distribute the signal to the left and right output. Beyond stereo mixing it is equally suited to create variable parallel routings. For example: Any of the four inputs may be routed in variable intensity to feed two filters.

You may regard the A-138s as a smaller version of the A-138m Matrix Mixer.

Inputs and outputs are DC coupled, i.e. the module can be used for the mixing of control signals too.

- 3U Eurorack module, 8 HP wide, 30 mm in depth
- Power consumption: 10 mA at +12 V and 10 mA at -12 V
Read more
MRP:$95.80 SAVE 10%
 3 in stock $86.10
2hp Mix 4-Channel Mixer Module (silver)
2hp Mix 4-Channel Mixer Module (silver) (attenuator/mixer synth module)
Cat: 635860 Rel: 30 Dec 16

4 channel mixer module
Notes: Mix is a 4 channel mixer that is great for audio or control voltage signals. Up to four inputs can be combined to a single output each with its own level control.
Read more
MRP:$115.18 SAVE 12%
 1 in stock $101.18
Click for better price!
or call +44 20 7424 1960
quote 635860
Doepfer A-135-2 Quad VCA & Voltage Controller Mixer Module (silver)
Cat: 714704 Rel: 22 Jan 19

Compact voltage-controlled four-channel audio mixer - 8HP
Notes: A-135-2 is a miniature version of the A-135-1. Behind a front panel with 8 HP only four linear VCAs (voltage controlled amplifiers) and a voltage controlled mixer based on the VCAs are available.

Controls, In/Outputs and Functions of each VCA:

- Level (manual control of the VCA amplification), small rubberized knob (L1...L4)
- Control voltage input with associated attenuator (CV1...CV4), for the full VCA control range about 0...+5V control voltage are required (attenuator fully clockwise), for higher control voltages the attenuator is used, the attenuators are without knobs, just plastic shafts with white marker
- Signal Input
- Signal Output
- All inputs and outputs are DC coupled. Consequently the VCAs can be used to process both audio and control voltages (e.g. to control the level of LFOs or envelopes)
- The signal input is not equipped with an attenuator. But the VCAs can process all signals up to 15Vpp / -7.5...+7.5V without clipping. In case of higher levels an external attenuator is required (e.g. A-183-1).
- The available amplification range is 0...1, the maximal amplification is 1 (i.e. it "clips" and remains at 1 even if the control voltage goes beyond the value that corresponds to amplification 1)

Functions of the voltage controlled mixers:

- Two outputs ("Selected" and "All")
- Selected output: the ouput if a VCA is removed from this sum signal when a plug is inserted into the corresponding VCA output.
- All output: sum of all VCA outputs, regardless of inserted plugs into the VCA outputs
- The maximal amplification is about 0.6 to avoid clipping at the mixer outputs (otherwise the outputs may distort with 15Vpp signals at each signal input and full amplifications)

Special functions of the voltage controlled mixers (selectable by internal jumpers):

- Dual Stereo VCA: In this case the control unit of VCA1 (L1 + CV1) affects also VCA3 and the control unit of VCA2 (L2 + CV2) affects also VCA4, the control units of VCA2 and VCA4 are out of operation
- Quad VCA: In this case the control unit of VCA1 (L1 + CV1) affects all four VCAs. The control units of VCA2, VCA3 and VCA4 are out of operation. In this mode the module has the same function as module A-132-2. That's why module A-132-2 will be discontinued.
- Normalling of the signal inputs: by means of internal jumpers signal input 1 can be normalled to signal input 2, signal input 2 to signal input 3 and signal input 3 to signal input In 4. That way the same input signal can be distributed to four different channels by means of control voltages (e.g. quadrophonic distribution of audio signals). Suitable control voltage sources are e.g. A-144 (Morphing Controller) or A-143-9 (Quadrature LFO).
Read more
 1 in stock $128.08
Click for better price!
or call +44 20 7424 1960
quote 714704
2hp Mix 4-Channel Mixer Module (black)
2hp Mix 4-Channel Mixer Module (black) (mixer/attenuator synth module)
Cat: 686027 Rel: 04 May 18

4 channel mixer module
Notes: Mix is a 4 channel mixer that is great for audio or control voltage signals. Up to four inputs can be combined to a single output each with its own level control.
Read more
 1 in stock $107.64
Click for better price!
or call +44 20 7424 1960
quote 686027
Frap Tools 321 Scale/Flip/Shift/Combine Module
Frap Tools 321 Scale/Flip/Shift/Combine Module (attenuator/CV modulation/mixer/polarizer/utility synth module)
Cat: 673008 Rel: 13 Dec 17

Compact three channel utility module for every patch - 6HP
Notes: The 321 includes the most useful functions we always need in every patch, to edit and combine dynamically the signals in use.

It is composed of three identical sections, the red, yellow and green, where each of those is capable of scaling any signal, from 0 up to 2 times (+6dB), flip its phase, and apply a DC offset, allowing to shift your audio or CV up or down.

In case no signals are connected to the section input, the offset may act as a CV source too.

The three sections are then summed together into two independent summing stages: the top right jack outputs the sum of all three sections, while the top left outputs the sum of the unconnected sections only (semi-normalled).

The 321 is entirely DC coupled, allowing the process of control voltages as well as audio signals.

In case CV's or audio signals are particularly hot, the two 6dB attenuators, one per each summing section might be helpful to reduce exactly by 50% the incoming signals.
Read more
 1 in stock $104.41
Click for better price!
or call +44 20 7424 1960
quote 673008
Doepfer A-138m 4x4 Matrix Mixer Module
Doepfer A-138m 4x4 Matrix Mixer Module (attenuator/mixer/quad module)
Cat: 716959 Rel: 29 Jan 19

4x4 matrix mixer module - 20HP
Notes: Module A-138m is a 4 x 4 matrix mixer with switches for unipolar/bipolar mode for each column. Unipolar means that the controls work as attenuators. Bipolar means that the controls work as polarizers. In this mode the amplification is zero in the middle position of the corresponding control. Turning the knob counterclockwise from the center position the signal is subtracted from the output sum with increasing amount (i.e. negative). Turning the knob clockwise from the center position the signal is added to the output sum with increasing amount. The module is DC-coupled and can be used for both audio and control voltage mixing.

By means of an internal jumper one can select if the four upper controls work as DC offset generators - provided that no patch cord is plugged into the upper input socket. If this feature is not required it can be deactivated by removing the jumper on top left of the pc board. The function is identical to the A-138a/b.

Dimensions
20 HP
20 mm deep

Current Draw
30 mA +12V
30 mA -12V
Read more
MRP:$149.62 SAVE 11%
 1 in stock $133.47
Doepfer A-130-8 Octal Linear VCA/Voltage Controlled Mixers Slim Line Series Module (silver)
Cat: 765896 Rel: 28 Jul 20

linear VCA module
Notes: Lots of functionality in a compact format thanks to Doepfer's typically smart approach. Eight linear VCAs with three mixers built in for good measure. Can be used for both audio and CV signals. Versatile.

Supplier notes:
Module A-130-8 contains eight linear voltage controlled amplifiers (VCAs). Each VCA features a control voltage input (CV), a signal input (In) and a signal output (Out). In addition three mixers are included: the socket labelled "1-4" outputs the sum of the VCAs 1-4, the socket labelled "5-8" outputs the sum of the VCAs 5-8, the socket labelled "1-8" outputs the sum of all eight VCAs.

The signal inputs are able to process levels up to 10Vpp without clipping. Each CV input is equipped with a trimming potentiometer that is used to adjust the sensitivity of the CV input in question. In the factory the module is adjusted for the CV range 1...+5V but can be re-adjusted by the user for other control voltage ranges (e.g. 0...+10V).

The amplification range for each single VCA is 0...1. The signals of the sum outputs have a lower amplification to avoid distortion.

The VCAs and mixers are fully DC coupled, i.e. the module can be used for the processing of both audio and control voltage signals. The control voltage and signal inputs can be normalled by means of small solder pads (e.g. 1 > 2 > 3 > 4 and so on, or 1 > 5, 2 > 6, 3 > 7, 4 > 8 for the stereo application mentioned below).

Typical applications:
any kind of VCA application (e.g. voltage controlled attenuation of audio or control voltage signals)
two voltage controlled mixers with four channels each
voltage controlled stereo mixer with four channels each, for this the control voltage inputs have to be correspondingly patched or internally normalled: CV1=CV5 /CV 2=CV6 / CV3=CV7 / CV4=CV8
voltage controlled mixer with eight channels
add-on for the planned Joystick module A-174-4

HP : 6
Read more
MRP:$119.48 SAVE 17%
 1 in stock $98.76
Frap Tools 333 Pro Audio Sum & Distribution Module
Frap Tools 333 Pro Audio Sum & Distribution Module (attenuator/mixer/multiple/utility synth module)
Cat: 673007 Rel: 22 Dec 17

Mixer/buffered signal distributor module - 6HP
Notes: The 333 is a summing and distribution module for Eurorack modular systems.

It is composed of three identical sections, the red, yellow and green, each of those featuring three inputs summing amplifier with three independently buffered outputs.

Derived directly from the CGM creative mixer series, the sum section is DC coupled, allowing the sum of control voltages as well as audio signals.

With an extremely low tolerance in both sum and output sections, it is suitable also for summing quantized voltages like the ones coming out from the quantized outputs of the SAPEL.

In case CVs or audio signals are particularly hot, the 6dB attenuator might be helpful to reduce exactly by 50% the incoming signals.

Red and yellow output are also normalled to the 1st jack socket of the yellow and green input: in this way this module can also work as a 1 to 9 buffered multiple.
Read more
 1 in stock $104.41
Click for better price!
or call +44 20 7424 1960
quote 673007
Befaco Hexmix 6-Channel Performance Mixer Module
Befaco Hexmix 6-Channel Performance Mixer Module (equaliser/mixer/panning/utility/dual & Stereo/external module)
Cat: 670606 Rel: 11 Jan 18

6-channel performance mixer module with EQs mutes and Pan - 28HP
Notes: Hexmix System is a six channel performance mixer specially designed for Eurorack.

The system has two separate modules, the core of the mixer: Hexmix that has six channels with three band EQ, mute, pan and EQ section on the master, and Hexpander that add three auxiliar sends per channel, PFL, individual outs and balanced output.

mixers, providing sharp EQ's for enhanced performance, auxilliar send for effects and individual outputs to record your performance per channel.

The system is designed to be placed in 6U, instead of the traditional 3U paradigm in Eurorack. So the module will have every feature for each channel vertically as a conventional tabletop mixing deck.

Six channel mixer with three band EQ, vactrol mutes, pan and volume control per channel.

Inputs for every channel are located at left side of Hexmix. Each jack is normalized to a VCA Expander connection in the back, so if you have a Hexmix VCA , you will have the output of each VCA to every input. connecting a jack in any input will disconnect whatever is coming from VCA.

Gain is set to unity, so it will act as an attenuator of the input signal. Mutes are clickless, as they are vactrol based. This circuit provide some decay on the mutes, rather than a sharp cut. Switches have latch position and momentary ones to unmute the channel, providing some really nice performative capabilities.

EQs are quite sharp (12dB) inspired in classic dj mixers to aggresively cut selected frequencies.

Master section has its own EQ and volume control for the mix of all channels. Master EQ is softer than individual channel's (6dB) and it's meant to provide control over the final mix.

It's possible to change output level from line to synth with a switch located in the back. This will be pretty useful when used in combination with hexpander, that provides a balanced out at line level. Like this its possible to have a mix at synth level to re-route the master signal while having an output to PA

Specs:
Current needs: +12V: 106mA, -12V: 88mA
Width: 28 HP
Depth: 28 mm (including power connector)
Alluminium, heat-treated front panel.
Read more
 1 in stock $445.62
Click for better price!
or call +44 20 7424 1960
quote 670606
Intellijel Triplatt 3U Attenuator/Inverter/Attenuverter/Multiplier/Adder/Mixer & DC Voltage Source Module
Intellijel Triplatt 3U Attenuator/Inverter/Attenuverter/Multiplier/Adder/Mixer & DC Voltage Source Module (attenuator/controller/dual/stereo/mixer/polarizer/switch/utility synth module)
Cat: 739050 Rel: 19 Jul 19

Three-channel active/buffered attenuverter & summing mixer
Notes: Triplatt is a three-channel active/buffered attenuverter and summing mixer. Each channel has a knob, which can function as a unipolar attenuator or a bipolar attenuverter, depending on the setting of its corresponding two-position polarity switch.

Each input is normalled to a built-in precision +5V DC voltage source. With nothing plugged into the jacks, each knob controls a voltage range of 0 to +5 V or -5 to +5 V depending on the position of the channel polarity switch. Outputs A and B are also capable of a range of 0-10 / -10 to +10 when using the special function switches.

Each output is normalled to mix into the output of the channel below, making it possible to do sub mixes in groups of two or three.

In addition, each channel has a "special function" switch to alter its input voltage in a specific way. Channel A has a 2x voltage multiplier switch, allowing you to double the voltage sent into Channel A. Channel B has a +5V switch, allowing you to add 5V to whatever voltage is sent into Channel B. Channel C has a mute switch, allowing you to completely turn off the signal being sent into Channel C.
Read more
 1 in stock $116.24
Click for better price!
or call +44 20 7424 1960
quote 739050
Xaoc Devices Praga 1967 Voltage Controlled Mixing Console Module (silver)
Xaoc Devices Praga 1967 Voltage Controlled Mixing Console Module (silver) (mixer/panning/VCA/dual/stereo/quad synth module)
Cat: 655355 Rel: 29 Jun 17

Voltage controlled four channel stereo mixer module
Notes: The module is built around high quality VCA chips from THAT Corp, as well as low noise opamps. It offers clickless muting and equal loudness panning. The distinct feature is that voltage control is dynamically compressed should it yield clipping when pushed too hard. Also, in both modes the attenuators offer full closing of the corresponding channel, regardless of being controlled by the CV, or not. The VCAs fully open (0dB gain) at CV=8V in Env mode and CV=5V in LFO mode. All the input and output signal levels are Eurorack levels.

Multiple Praga units can be chained thanks to dedicated headers on the back. The mixed stereo sum of each unit in the chain is added to the mixing bus of all units downstream.

A dedicated Hrad expander will offer master volume control, gate inputs for channels muting/unmuting, headphone amplifier, and voltage control over aux sends.
Read more
MRP:$433.80 SAVE 10%
 1 in stock $390.73
Happy Nerding 3x MIA 6-Channel Attenuverting Mixer/Offset/Scale/Polarizer Module (silver)
Cat: 777880 Rel: 22 Jul 20

6-channel attenuverting mixer, offset, scale & polarizer module - 6HP
Notes: 3xMIA is a 6-channel attenuverting mixer/offset/scale/polarizer

3 blocks of 2-channel attenuverting mixers, using dual concentric pots. Each channel can be switched to mix with the subsequent channel, allowing for 2-2-2, 4-2, 6 mix configurations.

With nothing plugged into an input, an offset is normalled to that channel. The inner knobs control the A inputs, while the outer knobs control the B inputs.

DC coupled, so it can be used for audio, CV, or both at the same time.

80 mA +12V
80 mA -12V
35 mm Depth
6 HP wide
Read more
 2 in stock $96.86
Click for better price!
or call +44 20 7424 1960
quote 777880
Erica Synths Pico Mixer 3-Channel DC Coupled Mixer Module
Cat: 738520 Rel: 22 Jul 19

3-channel DC coupled mixer module - 3HP
Notes: Pico Mixer is simple 3 channel DC coupled mixer intended to mix audio signals and CV signals in order to obtain complex modulations. Also it may serve as CV and audio attenuator.

Features:
3 inputs
Diode protection against overvoltage

Technical specification:
Mixer gain: 1
Power consumption +4mA, -4mA
Module width: 3HP
Module depth: 35mm
Read more
 1 in stock $57.86
Click for better price!
or call +44 20 7424 1960
quote 738520
Befaco Percall VC Quad Decay & 4-Channel Mixer Module
Befaco Percall VC Quad Decay & 4-Channel Mixer Module (envelope generator/mixer/VCA/quad synth module)
Cat: 739916 Rel: 02 Jun 20

VC quad decay & four channel mixer - 12HP
Notes: From trickling hi-hats to thunderous kicks. The Befaco Percall 4-Channel VCA/Delay Envelope Module is designed to take care of all percussive aspects of your Eurorack rig. You'll be able to create a whole host of percussion thanks to the 4 VCAs, volume control and decay options. By using the trigger you'll be free to open the VCA whilst the volume knob helps determine the level of the percussive sound you've sculpted. Take your tones to the next level thanks to the inclusion of an output on the envelope. You can apply this to the pitch of the oscillator to achieve a fat kick drum which offers excellent low frequency energy. The Percall 4-channel module is the ultimate addition to your Eurorack.
Read more
MRP:$257.26 SAVE 17%
 2 in stock $214.20
Erica Synths Black Stereo Mixer V3 4-Input Stereo Mixer Module
Cat: 716534 Rel: 24 Jan 19

4-input stereo wixer module - 10HP
Notes: Black Stereo Mixer is just what you need, if your setup has several nowadays gaining popularity modules with stereo inputs or outputs, like Black Hole DSP, Erica Fusion Delay, MI Clouds or some other. In order to save rack space, we designed compact mixer with lot of cool, performance oriented features.

In order to save rack space, we designed a compact mixer with a lot of cool, performance oriented features.

Check out also the Black Pre-fade Listen Expander that is a satellite module to Erica Synths Black Stereo Mixer!

Erica Black series are high-end modules with unique functionality. Only the highest quality components are used and all inputs and outputs are protected against undesired overvoltage. When designing the Black Series, we did not economise on the module width, we put design and usability first. Big knobs are assigned to functions that make difference in sound. Together the Erica Black series are a range of modules that make an entire synthesizer.
Read more
 1 in stock $147.20
Click for better price!
or call +44 20 7424 1960
quote 716534
Doepfer A-138nv Narrow Mini Mixer Vintage Edition Module (black)
Cat: 760211 Rel: 06 Mar 20

Narrow mini mixer module - 4HP.
Notes: Compact and simple four-input mixer module from Uncle Dieter. Linear pots make it suited to mixing CV signals but it can also handle audio. Mixed signal hard-wired to two sockets.

Supplier notes:
Module A-138n is a simple four channel mixer, which can be used with either control voltages or audio signals. Each of the four inputs has an attenuator available. The output is twice available (two sockets, hard-wired like a multiple).

HP : 4
Read more
 1 in stock $72.12
ALM Jumble Henge 16-Input Stereo Spectral Mixer Module
ALM Jumble Henge 16-Input Stereo Spectral Mixer Module (dual & stereo/equaliser/mixer/panning synth module)
Cat: 812641 Rel: 05 Feb 21

A 16 input stereo spectral mixer with a unique patch-based mixing interface in a compact space.
Notes: The Jumble Henge is a 16 input stereo spectral mixer with a unique patch-based mixing interface in a compact space. Each input has a carefully tuned resonant analog filter and a unique fixed pan value, providing each sound its own space within the mix. There is a Mix control to adjust the depth of the filtering and a clean external stereo input for chaining with another mixer or extra sound source. Jumble Henge is a space efficient solution for creating rich stereo mixes from a number of both mono and stereo sources.

INPUTS
Vertical and horizontal patch position determines a source's spectral and stereo placement in the mix respectively.

Aside from centred inputs, every input sits in its own unique pan position, helping to keep a separation between sounds but building a complete stereo image when combined.

The centre right inputs of the top two rows are normalised to the centre left inputs. - i.e if just a left input is patched it will be effectively panned center.

Towards the highs the panning becomes wider - as the human ear better pinpoints direction at higher frequencies, whereas the lows remain more centred for a tighter, more focused sound.

MIX CONTROL
Mix control for the overall depth of the filters applied to the inputs. Note: a slight volume increase occurs near the centre of the dial.

EXTERNAL INPUT
An additional clean stereo input pair for chaining with another mixer or additional source. Right input normalised to left input to accomodate mono sources.

OUTPUTS
Stereo mix output, the sum of all 16 inputs.

Jumble Henge was designed in collaboration with Worng Electronics and is based on the 'SoundStage'.

Technical Specifications

Supply: +12V 70mA / -12V 70mA

Size: 8HP

Depth: 38mm
Read more
 3 in stock $245.41
Intellijel uVCA II Dual Linear To Exponential VCA Module
Intellijel uVCA II Dual Linear To Exponential VCA Module (attenuator/dual/stereo/VCA/mixer synth module)
Cat: 563713 Rel: 10 Mar 15

Voltage controlled amplifier Eurorack synth module with continuously adjustable curve response (from linear to exponential)
Notes: This is the version II of the original uVCA.

This module was adapted from a design by David G. Dixon
Read more
MRP:$166.84 SAVE 14%
 2 in stock $144.23
Click for better price!
or call +44 20 7424 1960
quote 563713
Make Noise X-Pan 5-Channel Voltage Controlled Stereo Mixer Module
Cat: 731192 Rel: 19 Jun 19

CV-controlled 5-channel stereo mixer - 10HP
Notes: X-PAN is a compact and powerful 5 channel Voltage Controlled Stereo Mixer with Low Noise and High Headroom allowing for creation of complex panoramic audio imagery in just 10hp.

X-PAN is highly responsive to control signals allowing for exploration of the fluctuating stereo sidebands possible with Audio Rate Crossfading and Panning. X-PAN is Direct coupled for use as a CV Processing and Routing toolbox.

X-PAN consists of two full featured Channels and one simpler Channel. The top two Channels each have voltage controlled cross-fading and panning while the third Channel is a stereo aux input with stereo VCA. All three Channels are combined together at the stereo SUM outputs.
Read more
 1 in stock $257.27
Xaoc Devices Samara II 1962 Utility Waveform Processor Module
Xaoc Devices Samara II 1962 Utility Waveform Processor Module (attenuator/mixer/multiple/polarizer/sample&hold/switch/utility synth module)
Cat: 633371 Rel: 14 Feb 17

A flexible mixer and a multifunction utility module that may be used for processing audio signals, control voltages and modulation waveforms.
Notes: Samara is a "Swiss Army Knife" type of module, intended to serve the most common voltage and audio signal processing purposes such as attenuation, offsetting, mixing, inverting, and even basic waveshaping. Samara features four channels, each with two inputs and an attenuator, additional switchable offset generators, four voltage level and polarity indicators, two adders with switchable scale, and a precision four-channel processor that selects minimum and maximum voltage.
Read more
! low stock $179.75
Doepfer A-138b 4-Channel Mixer Logarithmic Module (silver)
Cat: 577776 Rel: 29 Nov 17

Four channel mixer module - 8HP
Notes: Module A-138 is a four channel mixer, which can be used with either control voltages or audio signals. Each of the four inputs has an attenuator, and there's a master attenuator, so that the mixer can be used at the end of the audio chain, i.e. it can be used to interface directly with an external mixer, amplifier, etc.

The A-138b has potentiometers with logarithmic response, so is especially suitable for audio signal mixing.
Read more
 1 in stock $57.86
Happy Nerding 4xSTEREO MIX Quad Stereo Mixer Module (silver)
Cat: 819288 Rel: 08 Apr 21

Quad stereo mixer module - 4HP.
Notes: Mix up to four stereo channels in just 4hp, or chain multiple modules together to add channels. Inputs are normalled for mono operation. Simple, compact and high quality at a reasonable price.

Supplier's Notes:
4xSt.Mixer is 4 HP quad stereo mixer.

Right inputs are normalled to Left inputs for easy mono operation

Several 4xSt.Mixers can be chained together or with other HN stereo modules via sockets on the back side

65 mA +12V
50 mA -12V
35 mm deep
Read more
 1 in stock $128.08
Click for better price!
or call +44 20 7424 1960
quote 819288
Make Noise XOH Stereo Mixer/Headphone Amplifier/Output Interfacing Module
Cat: 732818 Rel: 04 Nov 19

synth module
Notes: The XOH (miX Out Headphone) music synthesizer module is a stereo mixer, headphone amplifier and output interfacing module for your modular synthesizer. It consists of two stereo input channels with independent level controls, and two stereo outputs: one pair of independent line level left and right outputs at unity gain; and one TRS headphone or line level output with dedicated level control.
Read more
 1 in stock $125.94
Click for better price!
or call +44 20 7424 1960
quote 732818
Tesseract Modular Tex Mix Master Section Expandable Mixer Module
Cat: 797281 Rel: 07 Dec 20

Synth module
Notes: This is the main module of the mixer and the only indispensable one, the only one that needs the eurorack power cable. It provides power to all the other modules and contains the summing circuit for all channels in every audio bus.

32 mA +12V
32 mA -12V
Read more
 1 in stock $85.85
Click for better price!
or call +44 20 7424 1960
quote 797281
Doepfer A-138i Interrupting Mixer Slim Line Series Module (silver)
Cat: 731945 Rel: 10 Jun 19

Multi-featured mixer - 6HP
Notes: Module A-138i is a four channel mixer with an additional mute switch for each input. On top of that it is equipped with two types of single outputs and a dual mix output. All inputs and outputs are DC coupled. Consequently the VCAs can be used to mix both audio and control voltages.

Each input is - apart from the mute switch - equipped with the usual attenuator.

The single outputs offer the attenuated and possibly muted signal of the channel in question. Two version of single outputs are available:

Single Output A: If a plug is inserted into the single output "A" socket the channel in question is removed from the sum signal.

Single Output B: If a plug is inserted into the single output "B" socket the channel in question is not removed from the sum signal. This type of single outputs is available only for the channels 1 and 2.

The output is twice available (two sockets, hard-wired like a multiple).

The distances between the controls and sockets are smaller as for the standard A-100 modules and rubberized small-sized knobs are used. In return the front panel has 6 HP width only. The module is primarily planned for applications where only limited space is available.
Read more
 1 in stock $82.88
Click for better price!
or call +44 20 7424 1960
quote 731945
Joranalogue Add 2 Precision Adder & Averager Module
Cat: 757115 Rel: 07 Jan 20

Precision adder/averager in an ultra-narrow 2HP
Notes: To any new modular system owner, the need to easily combine different voltage sources quickly becomes apparent. While a mixer is the obvious solution, these modules are not suitable for adding precise pitch control voltages (CVs) since the channel gains cannot be set exactly to unity.

Add 2 provides a compact solution to this problem, precisely summing the input signals down to 1 or 2 outputs. Alternatively, each section can be configured as an averager using the jumpers on the rear. This way, LFO waveforms or audio sources can be combined while maintaining the average signal level and avoiding clipping. The high-end components provide exceptional performance, making Add 2 suitable for audio, control voltages and gates/triggers.

With the bottom section's first input not in use, the top output is injected into the bottom. This allows 5 signals to be combined into 2 outputs, adding flexibility to your patching.
Read more
 1 in stock $78.57
Click for better price!
or call +44 20 7424 1960
quote 757115
4ms Listen Four 4-Channel Stereo Mixer Module
4ms Listen Four 4-Channel Stereo Mixer Module (dual/stereo/mixer/panning/utility/preamp synth module)
Cat: 717580 Rel: 06 Feb 19

Four channel stereo mixer with line-level, modular-level & headphone outs
Notes: The Listen Four is a four channel stereo mixer with line, modular, and headphone outputs. Two mono channels with Pan knobs and two stereo channels with dual inputs provide optimal compatibility with both stereo and mono signals. The Listen Four can be daisy-chained to other Listen modules to create a larger mixer with sub-mix outputs.
Read more
MRP:$186.22 SAVE 14%
 2 in stock $159.31
Tesseract Modular Tex Mix 4 Mono Channels Expandable Mixer Module
Cat: 797284 Rel: 07 Dec 20

Synth module
Notes: This is a 4 mono channels expansion. Several of these modules can be added to provide more channels. Every channel features:
- Mono input
- Vactrol Gate (plug a CV into the GATE IN to modulate the volume of a channel, just like a classic VCA. When nothing is plugged in the GATE IN, the gate is normalled to fully open)
-SEND A control (switchable PRE/POST, in PRE mode the signal is present regardless to the channel volume control but only if the channel switch is in ON position)
-SEND B control (post-fader)
-PAN control (only affects the master bus)
-VOLUME control (affects the master, cue and POST sends, does not affect PRE-fader send)
-ON/OFF/CUE switch: ON - channel is routed to the master bus
OFF - channel is muted
CUE - channel is routed to the cue bus

13 mA +12V
8 mA -12V
Read more
 1 in stock $98.49
Click for better price!
or call +44 20 7424 1960
quote 797284
Doepfer A-135-2v Quad VCA & VC Mixer Vintage Edition Module (black)
Cat: 790453 Rel: 30 Oct 20

Quad voltage controlled amplifier & mixer module - 8HP
Notes: A-135-2 is a miniature version of the A-135-1. Behind a front panel with 8 HP only four linear VCAs (voltage controlled amplifiers) and a voltage controlled mixer based on the VCAs are available.

Controls, In/Outputs and Functions of each VCA:

Level (manual control of the VCA amplification), small rubberized knob (L1...L4)

Control voltage input with associated attenuator (CV1...CV4), for the full VCA control range about 0...+5V control voltage are required (attenuator fully clockwise), for higher control voltages the attenuator is used, the attenuators are without knobs, just plastic shafts with white marker

Signal Input

Signal Output

All inputs and outputs are DC coupled. Consequently the VCAs can be used to process both audio and control voltages (e.g. to control the level of LFOs or envelopes)

The signal input is not equipped with an attenuator. But the VCAs can process all signals up to 15Vpp / -7.5...+7.5V without clipping. In case of higher levels an external attenuator is required (e.g. A-183-1).

The available amplification range is 0...1, the maximal amplification is 1 (i.e. it "clips" and remains at 1 even if the control voltage goes beyond the value that corresponds to amplification 1)

Functions of the voltage controlled mixers:

two outputs ("Selected" and "All")

Selected output: the ouput if a VCA is removed from this sum signal when a plug is inserted into the corresponding VCA output.

All output: sum of all VCA outputs, regardless of inserted plugs into the VCA outputs

The maximal amplification is about 0.6 to avoid clipping at the mixer outputs (otherwise the outputs may distort with 15Vpp signals at each signal input and full amplifications)

Special functions of the voltage controlled mixer (selectable by internal jumpers)

Dual Stereo VCA: In this case the control unit of VCA1 (L1 + CV1) affects also VCA3 and the control unit of VCA2 (L2 + CV2) affects also VCA4. The control units of VCA3 (L3 + CV3) and VCA4 (L4 +CV4) are out of operation.

Quad VCA: In this case the control unit of VCA1 (L1 + CV1) affects all four VCAs. The control units of VCA2, VCA3 and VCA4 are out of operation. In this mode the module has the same function as module A-132-2. That's why module A-132-2 will be discontinued.

Normalling of the signal inputs: by means of internal jumpers signal input 1 can be normalled to signal input 2, signal input 2 to signal input 3 and signal input 3 to signal input In 4. That way the same input signal can be distributed to four different channels by means of control voltages (e.g. quadrophonic distribution of audio signals). Suitable control voltage sources are e.g. A-144 (Morphing Controller) or A-143-9 (Quadrature LFO).

Additional technical specification for each VCA (based on the specifications of the VCA circuits CEM3360/AS3360 used in the module):

Crosstalk between VCAs: typ. - 80dB

Signal attenuation at 0V CV: typ. -70dB

Total harmonic distortion: typ. 1%

Control voltage feedthrough: max. 15mV

Width: 8 HP / 40.3 mm
Depth: 45 mm (measured from the rear side of the front panel)
Current: +40mA (+12V) / -40mA (-12V)
Read more
 1 in stock $138.84
Click for better price!
or call +44 20 7424 1960
quote 790453
4ms Listen Four Quarters 4-Channel Stereo Mixer Module
4ms Listen Four Quarters 4-Channel Stereo Mixer Module (dual/stereo/mixer/panning/utility/preamp synth module)
Cat: 717581 Rel: 06 Feb 19

Four channel stereo mixer with balanced 1/4-inch & headphone out - 12HP
Notes: The Listen Four Quarters is a four channel stereo mixer with 1/4" (6.35mm) TRS balanced outputs and 1/8" (3.5mm) headphones output. Two mono channels with Pan knobs and two stereo channels with dual inputs provide optimal compatibility with both stereo and mono signals. The Listen Four Quarters can be daisy-chained to other Listen modules to create a larger mixer with sub-mix outputs.
Read more
 2 in stock $191.60
Click for better price!
or call +44 20 7424 1960
quote 717581
ALM Mega-Tang 4-Channel Linear VCA & Stereo Mixer Module
Cat: 914301 Rel: 05 Dec 22

A 4-channel linear VCA and stereo mixer providing per input control over level, effect send, pan and muting.
Notes: The 'MEGA-TANG' is a 4-channel linear VCA and stereo mixer providing per input control over level, effect send, pan and muting. Designed for live use in mind with a simple & compact layout, the 'MEGA-TANG' builds on the clean and transparent sounding Tangle Quartet VCA by adding a stereo mix output, effect sends (mono send with a stereo return) which pair great with the MFX, manual panning, soft mute buttons with LED indicators and an expansion port for future expandability.

Individual VCA outputs are available which remove the channel from the main mix (useful for cueing and monitoring). All signals are Euro level and bar the effects return, DC coupled for CV use as well as audio.

Technical Specifications

Power: +12V 125ma -12V 125ma
Size: 16HP
Depth: 32mm
Attenuation: approx -70db
Read more
 3 in stock $256.18
Buchla & TipTop Audio Mixer & Preamplifier Model 207t Module
Cat: 950885 Rel: 26 Jan 24

Mixer & preamplifier module - 28HP.
Notes: A characteristically unique take on mixing from Buchla, with six mono inputs and a built-in mic/guitar pre-amp. Each channel can be cued to a monitor mix, while the first and last channels also include voltage-controlled panning.

Supplier's Notes:
The Tiptop 207t is a modern reimagining of the classic Don Buchla 207 Mixer/Preamplifier from the 1970s 200 Series. This stereo mixer comes with a built-in preamp that allows you to boost external instruments and microphones, making it a versatile tool for any modular setup. The 207t also features a six-channel mixer with a variety of signal routing options, including the ability to route channels to the monitor and L&R signal outputs, with per-channel control over loudness and panning.

Each channel has a Mon switch that sends the channel's signal to the monitor outputs, which are always full-volume and summed to mono, making it useful for basic monitoring applications or rudimentary mixing. The Prog switch sends the signal to the L&R signal outputs, with loudness controlled by the Level Adjustment slider and panning determined by the Channel Assignment knobs. The first and sixth channels offer voltage control of panning; these channels are hard-panned when no CV is applied.

The preamp section features a 1/4" input and multiple gain settings, making it suitable for use with external line level instruments, electric guitars, or dynamic microphones. The continuous amplification control provides added flexibility for your audio needs. Finally, the Expansion In is a stereo input that sums to the left and right main outputs, which is great for chaining multiple 207t modules or adding another stereo source at the final output.

While the 207t's functionality may be simple, it is an essential part of any 200t system, serving as the glue that holds everything together. The Tiptop 207t is a fantastic mixer/preamp option that delivers quality sound and reliable performance.

Buchla 207t Features

Mixer/preamp module based on Don Buchla's original 207 design
Six-channel mixer with per-channel level control and panning
Voltage-controllable panning on channels 1 and 6
Manual panning on channels 2-4
Program switches can act as channel mutes for main outputs
Mon switches route signal (in mono) to Monitor output
Expansion input useful for stereo chaining and more
Re-designed preamp for high audio fidelity
Preamp suitable for use with external instruments, electric guitars, dynamic microphones, and more

Eurorack module
28hp wide
Read more
MRP:$252.96 SAVE 15%
 7 in stock $215.27
1010 Music Bluebox Digital Mixer & Recorder Module With Effects
Cat: 970244 Rel: 23 Oct 23

Mixer module with effects and multi-channel recording/playback - 30HP.
Notes: Eurorack version of 1010's superb Bluebox. Vast power in 30 HP, with the ability to mix, record and play back in mono and stereo, hook up to a computer over USB for stereo I/O and run effects, all with CV control.

Supplier's Notes:
The bluebox Eurorack edition is the new Eurorack mixer with effects and multichannel recording/playback based on the award-winning bluebox desktop mixer. With the Eurorack edition's USB-C EXT port, you can send 2 channels of audio to and from your computer. Plus, you can control up to 6 mix settings with the 6 CV inputs. Whether recording your Eurorack jams, using it to play stems as backing tracks, or a combination of both - bluebox Eurorack edition will rock your rack!

Connect your eurorack, sampler, drum machine, and synthesizer outputs to 12 mono, 3.5 mm inputs and map them to 12 mono tracks or 6 stereo tracks - all with independent control for recording and playback. Connect your computer to the USB C port to send and receive two channels of audio.

The bluebox Eurorack edition is the ultimate in compact mixing, effects, recording, and playback for Eurorack. Smack it in your rack and hit the road with a self-contained, electronic music powerhouse!

When you purchase a bluebox Eurorack edition, you will receive:

a bluebox Eurorack edition 30 HP Eurorack module
A microSD card with bluebox firmware and pre-loaded project files
two Eurorack power cables
a bluebox Eurorack edition Quick Start guide
two MIDI Adapters

Technical Specs

Dimensions & Power
30 HP
Module dimensions including knobs: 6" x 5"x 1.6"
Depth behind front panel with ribbon cable: 1.0"
Requires the +5V rail which may not be present
on some older racks.
Uses 500-850mA at +5V (depending
on screen brightness), 320 mA at +12V, and 82mA at -12V
Requires two power connections
Capabilities
12 mono tracks, 6 stereo tracks or something in between
Connect to TRS or USB C MIDI for beat syncing effects
Lots of headroom with support for Eurorack levels up to +/-5V inputs and outputs
3 effects: reverb, delay and compressor
Records and plays back 48k, 24-bit audio WAV files
4 band EQ per track
Durable aluminum faceplate
Stream 2 channels of audio in and out over USB C

Inputs and Outputs
12 mono 3.5 mm TS inputs
2 independently controlled 3.5 mm TS output pairs that can be used as 4 mono outputs
1 stereo 3.5 mm headphone output
6 CV Inputs
1 USB C MIDI Device port
1 TRS MIDI Input
1 TRS MIDI Output
1 USB C Ext jack for streaming audio
3.5" touch screen, 4 knobs, 8 navigation buttons and 3 transport buttons
Read more
 2 in stock $686.75
Click for better price!
or call +44 20 7424 1960
quote 970244
Neuzeit Instruments Quasar Binaural 3D Audio Mixer Module
Neuzeit Instruments Quasar Binaural 3D Audio Mixer Module (dual/stereo/effect/mixer/panning synth module)
Cat: 847881 Rel: 15 Feb 22

A 3D audio mixer with two audio inputs that uses binaural audio algorithms.
Notes: Quasar brings 3D spatial audio to the Eurorack world. It is a two-channel audio mixer that uses binaural algorithms. You can seamlessly move sounds around your head, dynamically change the angle, height and distance in real time.

** Includes 3mm screws, 16-Pin to 10-Pin eurorack power cable, USB cable for firmware updates **

Main functions
2 mono inputs
Stereo output (two single jacks + headphone stereo jack)
2 CV inputs
24Bit 48kHz inputs and outputs, 32Bit internal signal processing
Dynamic 3D positioning in three dimensions (height, angle, distance)
Room reverb can be applied for better localization
Internal LFOs with flexible routing
External CVs can be flexibly routed to all parameters, multiple destinations per CV, individual intensity
Different 3D transfer functions to choose from
Two large endless encoders with aluminum knobs, RGB LED rings for setting and displaying parameters
OLED display for navigation and to show which parameter the encoders are currently controlling
Flat menu structure, no deep dives neccessary
" User presets can be flexibly created and recalled
" Potentiometers for volume control of the three positions Quasar 1, Quasar 2 and Center

Quasar creates a 3D sound image by binaural audio processing. Two positions named Quasar 1 and Quasar 2 are available, which you can virtually place and move at any angle, height and distance around your head. Room reverb can be added as a further aid to distance perception. The audio signals at input 1 and input 2 can be flexibly routed to either or both positions via an internal matrix mixer. The coordinates of the positions can be set manually or be modulated by internal LFOs or external CVs. For example, you can have sounds orbiting around you, coming from above or below, front or back, and moving toward or away from you. Likewise, a centre position is available as a routing destination that leaves the signal without sonic processing to create a dry/wet mix.

Quasar features two CV inputs which can be flexibly routed to any target inside the module. In fact, each CV can have up to four different targets, which enables a very flexible design of auditory 3D-scenes.

Internal LFOs can be used to add dynamic movement and to create spectacular three-dimensional scenes. There are a variety of standard and advanced waveforms that can be routed to the position coordinates. LFOs can also be triggered and reset by external CVs.

Quasar can add some reverb to the signal. While not being a reverberation module in the first place, Quasar's reverb can improve distance estimation, but also be used to create impressing ambient stereo soundscapes.

All inputs also have digital high and low pass filters, so you can decide which frequency bands go to which position. However, in addition to Quasar 1 or Quasar 2, you can also route the audio to the center position. The center position takes the input signal and distributes it equally to the left and right ears without further processing. For example, you can route the low frequencies to the center position and have the higher frequencies distributed to the outer positions Quasar 1 and Quasar 2. That way, the bass stays centered and mono-compatibility is preserved.

As soon as a three-dimensional virtual scene has been created, it can be saved to the module's preset list. That way, scenes can be recalled at any time. Quasar also features some factory presets as a starting point and to show off the module's capabilities.

The module works best with headphones, as the algorithm basically mimics the shape of the head and the pinnae, which are responsible for our directional hearing. But even if you play the sound through speakers, you will hear a significant difference from classic panning.

As spatial hearing is a psychoacoustic effect that everybody perceives in a slightly different way, Quasar offers several transfer functions for different ear types to choose from. This way, the intensity of the 3D effect can be adjusted to personal needs and fits with the processed audio signal.
With its large aluminum knobs, LED rings, rubber potentiometers and mechanically solid components, Quasar is fun to use and invites creative work.
Read more
MRP:$468.24 SAVE 13%
 1 in stock $407.96
Tesseract Modular Tex Mix 4 Stereo Channels Expandable Mixer Module
Cat: 797287 Rel: 07 Dec 20

Synth module
Notes: This is a 4 stereo channels expansion. Several of this modules can be added to get more stereo channels. Every channel features:
Stereo input (L works as mono in)
SEND A control (switchable PRE/POST, in PRE mode the signal is present regardless to the ON/OFF/CUE switch position and channel volume control)
SEND B control (post-fader)
PAN control (only affects the master bus)
VOLUME control (affects the master, cue and POST sends)
ON/OFF/CUE switch: ON- channel is routed to the master bus
OFF- channel is muted
CUE- channel is routed to the cue bus

15 mA +12V
15 mA -12V
Read more
 1 in stock $97.15
Click for better price!
or call +44 20 7424 1960
quote 797287
Cosmotronic Cosmix Pro Aural Enhancing Stereo Mixer Module
Cat: 905831 Rel: 03 Feb 23

Stereo mixer module with a completely new design, with a lot of attention to sound quality, with a clean, low noise signal path, and lots of headroom.
Notes: Fully redesigned from the original Cosmix, the Cosmix Pro is an eight-channel mixer intended to work nicely for performance as well as production. Suitable for line-level stereo signals as well as Eurorack levels.

Supplier's Notes:
A completely new design, with a lot of attention to sound quality, with a clean, low noise signal path, and lots of headroom.

It features the same amount of channels as the previous Cosmix, 4x mono in, and 2x stereo in.

There's one mono aux bus, and an additional true stereo AUX for all channels, with a dedicated mono and stereo return.

Each channel has a pan pot, a big push button for clickless muting, and a dedicated LED level meter to visualize channel output level.

The mono channels come with a handy low cut switch. (-3dB @80Hz / -6dB @ 45Hz)

The stereo channels have an optional +18dB gain, allowing you to easily mix in line level external gear.

The two stereo channels also have a CV input for voltage controlled panning.

There are connectors on the back for daisy chaining, or for connecting to future expanders/other mixer units.

High quality aluminium panels, available in black or silver.

The older model Cosmix is discontinued until further notice, since the parts for the drive circuit are unobtainium.

That's also the reason there is no dedicated drive circuitry in the new model.

Technical specs
22HP, 20mm deep.
+12v: 170mA, -12v 170mA
Read more
 6 in stock $369.21
Click for better price!
or call +44 20 7424 1960
quote 905831
Endorphin.es Cockpit 2 Four Stereo Channels Performance Mixer Module (black)
Cat: 799787 Rel: 13 Nov 20

4-channel performance mixer module
Notes: Endorphin.es Cockpit² is a 4-channel stereo mixer with side-chain ducking.

Key facts:

Increased headroom
Improved sound quality
The LEDs are blue/red instead of red/green (Daltonic friendly)
No TRRS jacks anymore
New aluminium knobs on the black module version

Power consumption:
240 mA +12V
75 mA -12V
0 mA 5V

Dimensions:
6 HP
38 mm deep
Read more
 2 in stock $186.21
Click for better price!
or call +44 20 7424 1960
quote 799787
Joranalogue Mix 3 3+1 Channel Voltage Controlled Audio Mixer Module
Cat: 757108 Rel: 06 Jan 20

Analogue audio signal mixer with three high-end DC-coupled voltage controlled channels
Notes: By combining a mixer and four VCAs in a single module, Mix 3 manages to provide a unique combination of compact size and functionality in just 6 HP. High-end signal paths ensure extremely low noise and distortion, wide headroom and precise gain control, despite the small form factor.

Each of the three main channels has an exponential response, which is more natural for audio than linear, as it matches the human hearing. However, all signal paths are DC-coupled, so control voltage (CV) signals can be processed as well.

What truly sets Mix 3 apart from other compact mixing modules are the three CV inputs, providing voltage control over the signal levels. This even allows you to go beyond unity gain and reach up to +20 dB of amplification. Once a CV input is used, the corresponding channel knob becomes a CV attenuator.

When clipping, Mix 3 does so in a clean, symmetrical way. This yields a very pure overdriven sound, only containing odd harmonics, and allows the module to be used as a triple voltage controlled distortion.

Additional features include audio indicator LEDs, a fourth auxiliary input, voltage control over the output level and a line output jumper setting.
Read more
$138.86 SAVE 20%
 4 in stock $111.09
Doepfer A-130-8v Octal Linear VCA Vintage Edition Module (black)
Cat: 852796 Rel: 16 Dec 21

Octal Linear VCA / Voltage Controlled Mixers (Slim Line Series)
Notes: Module A-130-8 contains eight linear voltage controlled amplifiers (VCAs). Each VCA features a control voltage input (CV), a signal input (In) and a signal output (Out). In addition three mixers are included: the socket labelled "1-4" outputs the sum of the VCAs 1-4, the socket labelled "5-8" outputs the sum of the VCAs 5-8, the socket labelled "1-8" outputs the sum of all eight VCAs.

The signal inputs are able to process levels up to 10Vpp without clipping. Each CV input is equipped with a trimming potentiometer that is used to adjust the sensitivity of the CV input in question. In the factory the module is adjusted for the CV range 1...+5V but can be re-adjusted by the user for other control voltage ranges (e.g. 0...+10V).

The amplification range for each single VCA is 0...1. The signals of the sum outputs have a lower amplification to avoid distortion.

The VCAs and mixers are fully DC coupled, i.e. the module can be used for the processing of both audio and control voltage signals. The control voltage and signal inputs can be normalled by means of small solder pads (e.g. 1 > 2 > 3 > 4 and so on, or 1 > 5, 2 > 6, 3 > 7, 4 > 8 for the stereo application mentioned below).

Typical applications:

Any kind of VCA application (e.g. voltage controlled attenuation of audio or control voltage signals)
Two voltage controlled mixers with four channels each
Voltage controlled stereo mixer with four channels each, for this the control voltage inputs have to be correspondingly patched or internally normalled: CV1=CV5 / CV2=CV6 / CV3=CV7 / CV4=CV8
Voltage controlled mixer with eight channels
Add-on for the planned Joystick module A-174-4

Dimensions
6 HP
40 mm deep

Current Draw
50 mA +12V
50 mA -12V
0 mA 5V
Read more
 1 in stock $124.86
Click for better price!
or call +44 20 7424 1960
quote 852796
AJH Synth MiniMod Muting Mixer & VCA Audio Mixer Module (black)
Cat: 852985 Rel: 23 Feb 22

A dedicated audio mixer for the MiniMod range.
Notes: Five-channel mixer with mutes, built-in VCA, switchable overdrive and LED level meter. Simple, straightforward, high-quality stuff from AJH.

Supplier's Notes:
The MiniMod Muting Mixer & VCA is a 10HP wide, five channel audio mixer with many useful features. It is available with either a black (Dark Edition), or a silver front panel.

The mixer section has five input channels, and each channel includes a bi-colour tactile LED switch that can instantly mute or un-mute the channel, replicating the oscillator on/off switches on the original Model D synthesiser. This arrangement is more convenient than regular switches as each illuminated switch shows the on/off status of the associated channel and multiple buttons can be pressed at once, making it very useful for live performance.

AJH have also included a four segment LED level meter so that the overall level can be seen at a glance and adjusted to prevent the output from getting too "hot" and causing distortion in other modules further downstream.

It also features a VCA that is integrated into the output section, and this can be switched from linear to exponential response - this allows it to be used as a voltage controlled sub mixer or as a stand alone VCA with five inputs.

Lastly, AJH added a wonderfully soft and warm sounding overdrive circuit that can be switched in to add smooth, tube like distortion. This works in a similar fashion to a master volume guitar amplifier, so the amount of overdrive can be varied widely with different settings of channel and master output levels.

Module Width: 10hp
Module Depth: 26mm (Including power lead)
Current Usage: 55mA Positive, 25mA Negative
Read more
 1 in stock $246.50
Click for better price!
or call +44 20 7424 1960
quote 852985
Molten Modular Motion MTR CV & Audio Utility/Real Time Visualiser Module
Molten Modular Motion MTR CV & Audio Utility/Real Time Visualiser Module (mixer/attenuator/polarizer/utility synth module)
Cat: 907132 Rel: 18 Nov 22

Motion MTR allows you to mix, attenuate and invert signals while having clear visual feedback of their levels.
Notes: Motion MTR allow you to mix, attenuate and invert signals while having clear visual feedback of their levels.

Each channel can function as:

Audio level control with VU meter
CV attenuator with voltage meter
CV inverter with voltage meter
Each input is normalled to 10v, so you can
use each of them to generate fixed voltages.
Also, the outputs of channels 1 and 2 are summed into Out 3 to be used as a mixer.
Patch it wildly to make it work as an attenuverter with offset, as a mixer, a VU meter or a combination of them all!
This module is our first collaboration with Robin Vincent from Molten modular.

Specs

Current Draw: +12v: 110 mA -12v: 43 mA
Width: 6HP
Depth: 30mm including power connector
Aluminium, heat-treated front panel.
Designed and assembled in Barcelona.
Idea by Robin Vincent
Read more
MRP:$138.86 SAVE 15%
 1 in stock $118.40
Erica Synths Black Mixer/Splitter v2 Audio/CV Mixer & Multiple Module
Cat: 826616 Rel: 17 Jun 21

Input mixer/output signal splitter module - 4HP
Notes: Introducing a four independently buffered input mixer and a buffered output signal splitter, in one module!

Erica Synths Black Mixer/Splitter V2 is an advanced replacement for stackable patchcables.

Everyone who knows a bit more about electronics will point out that stackable patchcables are not a really wise choice for such sensitive things as musical instruments because they mechanically connect electrical signals that at best can cause undesired modulations or even damage the modules.

Erica Black series are high-end modules with unique functionality. Only the highest quality components are used and all inputs and outputs are protected against undesired overvoltage. When designing the Black Series, design and usability were prioritised first. Big knobs are assigned to functions that make difference in sound. Together the Erica Black series are a range of modules that make an entire synthesizer.

Technical specifications:

Input signal level: -10V - +10V
Power consumption: +25mA, -25mA
Module width: 4HP
Module depth: 25mm
Read more
 1 in stock $69.43
Click for better price!
or call +44 20 7424 1960
quote 826616
Verbos Electronics Control Voltage Processor Module (silver)
Verbos Electronics Control Voltage Processor Module (silver) (attenuator/CV modulation/mixer/slew limiter/envelope generator/function generator/utility/VCA synth module)
Cat: 725952 Rel: 25 Mar 19

Two flexible mixers & function generator in one module - 18HP
Notes: The Control Voltage Processor from Verbos Electronics GmbH is a suite of control voltage processing possibilities divided into 3 sections in a slim 18HP package. The lower 2 sections are DC coupled mixers that allow mixing, inverting, offsetting, scaling, multiplying, dividing, crossfading or a combination of these functions. The top section is a voltage controlled slewing processor with independent control of Positive and Negative slew rate, with some unique tricks. The Positive and Negative slew, or Rise and Fall rates if you like, have reversing attenuators. The slopes can be blended from linear to RC curves (starting all slides fast and ending slow, like a proper "East Coast" Portamento) without a change in speed. It can be triggered like an AD envelope and has a Gate out that goes high when the CV out is below 100mV. Of course it can loop by patching the Gate out to the Trigger in. The Bounce control adds a unique flare of overshoot to CV changes, a bit like the effect of stopping a tape reel from turning and then letting it go. The combination of multiple voltage processors offers the user the functions of analogue computer.
Read more
MRP:$547.90 SAVE 12%
 1 in stock $483.30
Make Noise DXG Dual Stereo Low Pass Gate & Mixer Module
Make Noise DXG Dual Stereo Low Pass Gate & Mixer Module (dual/strereo/low pass gate/mixer module)
Cat: 992443 Rel: 29 Jan 24

Dual stereo low pass gate & mixer module - 8HP
Notes: The Dual Stereo Gate (DXG) music synthesizer module is a Dual Stereo Low Pass Gate and Mixer. It follows in the footsteps of the QMMG, Optomix, RxMx, DynaMix, and LxD. Unlike its predecessors, the DXG is specifically oriented around mixing stereo signals, making it an important addition to any system containing modules like XPO, QPAS, Morphagene, Mimeophon, and other stereo modules by Make Noise or others.

Unique to the DXG is a new low pass gate circuit that does not use vactrols. This circuit is 100% analogue and its response was arrived at after many months tailoring it to meet or exceed the expectations that have been set by all the vactrol low pass gates that Make Noise has created over the years.

In the past, Make Noise produced the Dynamix module and Dynamics circuit in the 0-COAST, both of which are vactrolless LPGs; however, the DXG is a completely new approach which better implements the gentle single pole filtering of a low pass gate, while also emulating the slow decay and memory of the vactrol based low pass gate. This new circuit makes possible the consistency of response necessary for versatile stereo use, while also keeping the module small and affordable so that it can be a key part of just about any modular system.

As on all of Make Noise's low pass gates, the DXG's Control parameter is used to set both the amplitude and the frequency content of the sound that passes through it. The control parameter tends to open faster than it closes, imparting a subtle decay phase onto any envelope shape that is used to modulate it.

Unlike previous low pass gates made by Make Noise, all the DXG's inputs and outputs are stereo. Each set of inputs is normalled so that the left input can be used for a mono signal, sending a copy to both left and right outputs. The Auxiliary inputs are also a stereo pair with mono normalization. These normalizations allow for the DXG to be used as a simple three channel stereo mixer, with one or two of the channels additionally being used for dynamics control and note event generation. The Aux inputs can be used to chain together larger decentralized mixes using additional DXG modules, or X-PAN, Optomix, modDemix etc.

Features

- Make Noise's first Stereo Low Pass Gate

- Vactrol-free design for classic Low Pass Gate sounds, but with the balance and consistency needed for true Stereo

- Fully Stereo i/o for easy integration into a Stereo-equipped modular synthesizer

- All Left inputs normalled for easy use with Mono signals

- STRIKE Input allows use of Gate signal to trigger Low Pass Gate circuit, creating "plucking" or "pinging" sound from any Gate

- Summing stage with Stereo AUXiliary IN allows for chaining of multiple units, creating larger mixes

- Part of a decentralized mix console integrated throughout the system along with X-PAN, Optomix, XOH, etc.

- Pairs well with XPO, QPAS, Morphagene, Mimeophon, Spectraphon etc.

Width: 8hp
Power:
74mA @ +12V
86mA @ -12V
Module Depth (incl power cable): 43mm
Read more
 More than 10 in stock $214.20
Click for better price!
or call +44 20 7424 1960
quote 992443
Artículos del 1 al 50 de 119 en la página 1 de 3
1  2  3  »
Cart subtotal:
