Notes: For podcasters, videographers, bloggers, journalists and more, the F2 is the perfect audio solution for creators on the move.

The F2 is incredibly small, but its audio quality will amaze you.

The F2 features 32-bit float recording technology, allowing you to record the loudest audio signals without worrying about clipping. It will also record the quietest signals in beautiful detail. And the best part is you don't have to worry about setting the gain. Just plug in the lav and hit record.

Once you start your recording, use the F2's HOLD switch to ensure you don't accidentally stop recording.

Screw-lock connectors keep your lav plugged-in securely no matter the situation.

With the F2 actors can record and playback their lines to perfect their delivery.

The F2 Editor for PC and Mac allows you to adjust settings, format SD cards and more. Simply connect your F2 or F2-BT via a USB cable and launch the editor. The USB connection also makes it easy to transfer files to your computer. See the F2 Editor features here.

Whether a stroll through your garden, or the whispers and shouts of a dramatic reading, the F2 provides crystal clear recordings.

The F2 can record up to 15 hours (14 hours on the F2-BT) with two AAA batteries.

Record on microSD, microSDHC, and microSDXC cards up to 512GB.

The LMF-2 omnidirectional lavalier microphone has a low-profiled design, captures high-quality audio, and includes a windscreen and lapel mic clip.

The F2 Field Recorder gives you the option to choose the recording format that works best for your projects. Choose from 44.1 kHz/32-bit float or 48 kHz/32-bit float mono WAV files.

The F2 Is Perfect For Recording Interviews Anywhere.

Input
Connector: 3,5 mm stereo mini (with screw lock) Supports plug-in power (2.5 V)
Input impedance: 2 kO or more
Maximum input level: -5,5 dBu
Output
Connector: 3,5 mm stereo mini (with screw lock)
Maximum output level: 20 mW + 20 mW (into 32 ? load)
Recording media
Cards compatible with microSD/microSDHC/microSDXC specifications (Class 4 or higher, 512 GB maximum)
Recording formats
WAV, 44.1kHz/32-bit float, 48kHz/32-bit float Mono, BWF format supported WAV
USB
USB Typ-C
Note: Use a USB cable that supports data transfer. USB bus power is supported.
Mass storage operation: USB 2.0 High Speed
PC app operation: USB 2.0 High Speed
Power
2 AAA batteries (alkaline, lithium or rechargeable NiMH batteries)
AC adaptor
Bluetooth
Bluetooth Ver4.2 (F2-BT only)

External dimensions: 57,5 mm (w) x 46,4 mm (D) x 22,4 mm (H)
Weight (main unit only): 32 g

Notes: The new lightweight stereo in-camera recorder that records in 32-bit float to ensure perfectly modulated audio on every recording. The M3 has a line output to send audio directly to the camera input and has a selectable mono/90-/120- recording pattern.

Stereo shotgun microphone with stereo recorder
High level stability (133dB SPL)
Support for mid-side (M/S) raw recording
Shock mount for camera included
REC/ PLAY button and mono/90/120
2xAA battery operation (up to 12 hours)
Perfect sound with every picture. In one take.

The M3 MicTrak offers filmmakers the ability to enhance their content with pristine sound quality. Designed to be mounted on a camera, the stereo microphone with built-in recorder records every sonic nuance with 32-bit float technology.

32-bit float recording

The M3 records clipping-free audio at all times. Thanks to 32-bit float recording, no equalisation is necessary. Whether it's dialogue, sound effects or ambience in outdoor recordings, you'll always get a perfect recording.

Absolutely ready at all times

The specially designed elastic mount keeps weight to a minimum and ensures minimal transmission of handheld noise.

Mono and stereo modes

Switch easily between mono and stereo modes. Mono mode is ideal for dialogue recording. 90O provides accurate, transparent stereo recording. 120O stands for a generous stereo pick-up, which is especially recommended for atmosphere or sound effects.

More flexibility in post-production

The M3 saves a backup file in mid-side RAW format at any time, giving you the flexibility to adjust the stereo width of the recording in post-production.

Backup for your recordings

Use the 3.5mm stereo output to connect the M3 to your camera and record a backup there. This is especially useful for synchronising audio to a video.

Effectiveness in post-production

With the M3 Edit and Play software, you can adjust the stereo width of your recordings and normalise your files to prepare them for dubbing and post-production.

USB Mic

Connect the USB-C port to a PC or Mac to use the M3 as a USB microphone for streaming or recording.

Monitoring

Listen to your recordings via the 3.5mm headphone output.

Power supply

Power the M3 on long production days with up to 12 hours of recording from two Type AA batteries.

Storage

Record onto SDXC cards with a capacity of up to 1 TB.

Tech specs
USB-C connector (2.0)
USB bus power supported
Recording media
4GB-32GB microSDHC cards
64GB-1TB microSDXC cards
Headphone jack
12 hours battery life
Recording format: 44.1/48kHz, 32-bit float (48kHz in audio interface mode), mono/stereo BWF and iXML

Whats in the box

Quick Guide
Windscreen
3.5 mm mini-jack coiled cable
Elastic microphone holder

Notes: The Zoom G2 Four is a compact, easy-to-use multi-effects processor that offers a huge range of sounds with new amp modelling, multi-layer IR technology and over 100 effects:

Features

22 amp/cabinet models with newly developed multi-layer IR technology
79 guitar effects including boutique pedal modelling
Use of up to 7 effects simultaneously
250 preloaded patches with sounds that recreate guitar sounds from the 50s to today
300 patch memories in total
Additional effects/patches can be installed, edited and saved via the Handy Guitar Lab app for iOS and Android.
An external expression pedal can be used to control effects such as volume, pitch and wah in real time
Lightweight and compact design that fits in the pocket of your guitar case
80-second looper function
68 rhythm patterns that can be played in sync with the looper
Output EQ for quick adjustment of the overall sound to the playing environment
AUX IN jack for connecting a music player, etc.
Autosave function that automatically saves effect settings
Tuner function that supports open tuning and drop tuning
USB connection for Handy Guitar Lab, 2-in/2-out audio interface and firmware updates
Can be powered via USB bus (computer or power bank) or via the supplied AC adapter (AD-16)

Sounds without end

Using all-new amp modelling and innovative IR technologies, the Zoom G2 Four gives guitarists more sound variations to choose from than ever before. You can create amazing sounds right out of the box.

Comprehensive amp models

Zoom G2 Four takes amp modelling to the next level. Carefully recreated emulations of classic amps are combined with speaker simulations using our new multi-layer IR technology. As a result, guitarists benefit from great sounds and always have the feeling of being on the "big stage", regardless of the environment.

Multi-layer IR

Each amp model is based on Zoom's innovative Multi-Layer IRs, which capture the sound characteristics as well as the feel of classic amps and speaker cabinets. These IRs have been sampled at three volume levels through legendary cabinets and can be crossfaded and activated depending on the volume of your guitar.

Historic guitar sounds

Preloaded in the form of 250 presets, these patches were designed to document the sonic evolution of guitar sound. Each patch recreates the sound of a legendary song from the 1950s to the present day.

Brimming with effects

The internal patches include over 100 effects, recreating a wide range of traditional and boutique sounds, from classic spring reverbs to extreme distortion and modulation effects to wah-wah and more. Mix and match up to 7 effects to create your own patches.

Controls

Zoom's new cross-key navigation concept helps you control the pedal with just your feet and make adjustments on the fly. In addition, four endless knobs allow you to quickly adjust effect parameters as well as output settings.

Programming

The redesigned control surface makes it even easier to edit effect parameters, rearrange effect chains, and access the looper and tuner.

The perfect addition to your pedalboard
The G2 Four's compact design and diverse effects selection make it a powerful addition to any existing pedalboard.

Optimised for amps, monitor speakers and headphones
The G2 Four is designed to connect to guitar amps, studio monitors, PAs and headphones. After switching on, you set up the G2 Four perfectly for your setup by selecting between LINE and AMP.

Looper

Use the built-in 80-second looper for songwriting or enhance your performance with additional sound layers.

Play to the beat

Play along to any of the 68 beats on the built-in rhythm machine. This rhythm section is the perfect accompaniment when practising, whether it's metal, blues or any other genre.

Audio interface

Record at home or in the studio with your favourite effects and amp models by connecting the G2 Four to your computer via USB-C.

Guitar lab

Thanks to the ever-growing library of patches and effects, every guitarist can expand their sound selection via the Guitar Lab app (for iOS / Android).

Notes: The Zoom G2x Four is a compact, easy-to-use multi-effects processor that offers a huge range of sounds with new amp modelling, multi-layer IR technology and over 100 effects:

Features

22 amp/cabinet models with newly developed multi-layer IR technology
79 guitar effects including boutique pedal modelling
Use of up to 7 effects simultaneously
250 preloaded patches with sounds that recreate guitar sounds from the 50s to today
300 patch memories in total
Additional effects/patches can be installed, edited and saved via the Handy Guitar Lab app for iOS and Android.
Expression pedal lets you control effects such as volume, pitch and wah in real time
Lightweight and compact design that fits in the pocket of your guitar case
80-second looper function
68 rhythm patterns that can be played in sync with the looper
Output EQ for quick adjustment of the overall sound to the playing environment
AUX IN jack for connecting a music player, etc.
Autosave function that automatically saves effect settings
Tuner function that supports open tuning and drop tuning
USB connection for Handy Guitar Lab, 2-in/2-out audio interface and firmware updates
Can be powered via USB bus (computer or power bank) or via the supplied AC adapter (AD-16)

Sounds without end

Using all-new amp modelling and innovative IR technologies, the Zoom G2X Four gives guitarists more sound variations to choose from than ever before. You can create amazing sounds right out of the box.

Comprehensive amp models

The G2X Four takes amp modelling to the next level. Carefully recreated emulations of classic amps are combined with speaker simulations using our new multi-layer IR technology. As a result, guitarists benefit from great sounds and always have the feeling of being on the "big stage", regardless of the environment.

Multi-layer IR

Each amp model is based on Zoom's innovative Multi-Layer IRs, which capture the sound characteristics as well as the feel of classic amps and speaker cabinets. These IRs have been miked at three volume levels through legendary cabinets and can be crossfaded and activated depending on the volume of your guitar.

Historical guitar sounds

Preloaded in the form of 250 presets, these patches were designed to document the sonic evolution of guitar sound. Each patch recreates the sound of a legendary song from the 1950s to the present day.

Brimming with effects

The internal patches include over 100 effects, recreating a wide range of traditional and boutique sounds, from classic spring reverbs to extreme distortion and modulation effects to wah-wah and more. Mix and match up to 7 effects to create your own patches.

Controls

Zoom's new cross-key navigation concept helps you control the pedal with just your feet and make adjustments on the fly. In addition, four endless knobs allow you to quickly adjust effect parameters as well as output settings.

Programming

The redesigned control surface makes it even easier to edit effect parameters, rearrange effect chains, and access the looper and tuner.

The perfect addition to your pedalboard
The G2X Four's compact design and diverse effects selection make it a powerful addition to any existing pedalboard.

Optimised for amps, monitor speakers and headphones

The G2X Four is designed to connect to guitar amps, studio monitors, PAs and headphones. After switching on, set up the G2X Four perfectly for your setup by selecting between LINE and AMP.

Looper

Use the built-in 80-second looper for songwriting or enhance your performance with additional sound layers.

Play to the beat

Play along to any of the 68 beats on the built-in rhythm machine. This rhythm section is the perfect accompaniment when practising, whether it's metal, blues or any other genre.

Express yourself

The G2X Four features an expression pedal for controlling volume, wah-wah and more.

Audio interface

Record at home or in the studio with your favourite effects and amp models by connecting the G2X Four to your computer via USB-C.

Guitar lab

Thanks to the ever-growing library of patches and effects, every guitarist can expand their sound selection via the Guitar Lab app (for iOS / Android).

Notes: Great value little 4-in/4-out interface, designed for portability when making music or streaming. Dual headphone outputs and four XLR/TRS combo inputs with pre-amps give you plenty of versatility.

Supplier's Notes:
AMS-44 For One or More Musicians

AMS-44 | 4-In, 4-Out

Whether you're recording or streaming, the AMS-44 keeps your setup simple. It features four XLR/TRS combo inputs along with Zoom's high-performance, low-noise preamps. The interface also includes two headphone outputs and two TRS outputs for external monitors.

Quick control

With their onboard hardware switches, the AMS-24 and AMS-44 are designed to simplify common streaming challenges without the need for additional software.

Little switch, big Streams

Toggle from recording to livestreaming with the Music / Streaming Switch. When in Music mode, each input acts independently with individual gain control. It also sends separate mixes to each headphone output.

When in Streaming mode all inputs are combined into one signal to work seamlessly with your streaming software.

Onboard monitoring

Use the Direct Monitor Switch to send the input signal directly to your headphones while routing the same signal to your DAW or streaming software.

Loop it back

The Loopback Switch combines the input audio with playback from your computer and routes it to your streaming software. This is perfect for adding background music to your stream or singing live with an instrumental track.

Mic/line guitar

Switch Input 1 from mic or line level to guitar level (Hi-Z).

Stereo link

Links two inputs for stereo recording or streaming and allows you to control both inputs with one gain knob.

Phantom power

Provides +48V phantom power for condenser microphones.

Power options

All three AMS interfaces can be powered from your PC or Mac via USB-C. Use external power when working from a tablet or mobile phone.

Additionally, the AMS-24 and AMS-44 can also use two AA batteries.

Plug it in...

Use the AMS Series on any device thanks to its support for Mac and PC, along with iOS and Android devices.

...And perform

The AMS Series is designed to integrate seamlessly with commonly used software, apps and platforms.

In Streaming mode, connect with your audience by streaming to popular platforms like YouTube, Facebook, Twitch, Instagram and Patreon.

In Music mode, record with software like Adobe Audition, Pro Tools, Cubase and GarageBand.

What's in the box

AMS-44 USB Audio Interface
USB-C Cable
Quick Tour

Technical Specification

Input and Output Channels
Number of input channels: Mono (MIC/LINE): 4
Number of output channels: Stereo (TRS): 1
Stereo (PHONES): 2

Connectors

INPUT 1-4 - Type: XLR/TRS combo jacks
(XLR: 2 HOT, TRS: TIP HOT) Input gain: -8 - +58 dB / -8 - +50 dB (when set to GUITAR)
Input impedance: XLR: 2.7 kO
TRS: 18 kO / 330 kO (when set to GUITAR)
Maximum input level: XLR: +6 dBu
TRS: +22 dBu / +8.5 dBu (when set to GUITAR)
Phantom power: +48 V
OUTPUT A (standard phone jacks)
Type: TRS phone jacks (impedance balanced)
Maximum output level: +10 dBu (at 0 dBFS)
Output impedance: 100 O
OUTPUT A-B (headphone jacks): Type: 3.5mm stereo mini jacks - 30 mW + 30 mW (32 O load)
Output impedance: 10 O
USB: USB Type-C (audio interface function)
Use a USB cable that supports data transfer. USB bus power is supported.
DC 5V: USB Type-C (for power supply)
Frequency Response: 44.1 kHz: 1 dB (20 Hz - 20 kHz) - 96 kHz: 1.5 dB (20 Hz - 40 kHz)
Equivalent input noise: -120 dBu or less (IHF-A) at +58 dB/150O input

Audio interface

Input and output channels: Recording: 4 channels
Playback: 4 channels
Sampling frequencies: 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz
Bit depth: 24-bit
Interface: USB 2.0
Class: USB Audio Class 2.0

Power

2 AA batteries (alkaline, lithium, or rechargeable NiMH), AC adapter (ZOOM AD-17): DC 5 V/1 A -USB bus power is supported.
Rated Current
USB/AC adapter (5 V): 350 mA
Batteries (2.4 V): 560 mA
Estimated continuous operation time using batteries
44.1 kHz, 48 V off, with 32O headphone load
Alkaline batteries: about 3 hours
NiMH batteries (1900 mAh): about 4.5 hours
Lithium batteries: about 8.5 hours
The above values are approximate. Continuous battery operation times were determined using in-house testing methods. They could vary greatly according to use conditions.
Power Consumption: 5 W maximum

Dimensions: 129.0 mm (W) × 74.0 mm (D) × 46.0 mm (H)
Weight (unit only): 177 g
Weight (including batteries): 223 g

Notes: The H2essential is the only Handy Recorder with three internal microphones. With the ability to select different mic patterns, it gives creators more options than ever before. With two cardioid mics facing front and rear and a bi-directional mic facing side to side, the H2essential allows you to choose the perfect pick-up pattern for every recording.

Set your pickup pattern to 90O or 120O stereo, or choose mono for a hyper directional pickup, reducing background noise. Then choose to record from the front, rear, or activate both sides for surround sound pickup. Record in 32-bit float up to 96kHz ensuring high-quality audio without ever having to set gain.

When connected to a PC, Mac, iOS, or Android device using the USB-C port, the H2essential can be used as a USB microphone while simultaneously recording to the SD card. Connect the H2essential to your mobile device via USB and record professional audio directly onto your phone's video. Perfect for video podcasts and live streams.

Record in MS Raw and adjust the width of the stereo image in post production. This is helpful when you want to control ambient noise. The H2essential has advanced features such as a low cut filter, pre-record, auto record, and playback speed adjustment.

Using the BTA-1* Bluetooth Adapter, pair one or more H2essentials with your iOS device to remotely hit record and sync timecode. The H2essential is designed with Accessibility for the blind and visually impaired. Navigate the menu with audible descriptions through the built-in speaker or headphones. Creators can choose English, Spanish, French, Japanese, German, Italian or Chinese.

The specially designed windscreen for the H2essential provides wind protection when recording outdoors. The custom fit gives access to controls while the windscreen is attached. The 3.5mm input can accommodate audio players, keyboards, and lav mics with plug-in power. You can record with the front mic and the 3.5mm input simultaneously.

Use the mixer to easily adjust each track's audio level. The color LCD screen makes it easy to navigate through the H2essential's simple interface.The real-time waveform display lets you see your audio as it records.

Use the 3.5mm headphone output for headphones or connect directly to a camera. The onboard speaker allows you to listen to your recordings for quick reference as well as utilize the Accessibility functions. The H2essential supports SDXC cards up to 1TB.

The H2essential has a dedicated Marker button to instantly set reference points while recording. The H2essential can be powered by two AA batteries or via the USB-C port. This includes bus-power as well as external USB battery pa

Notes: Portable recording made with musicians in mind, the R4 records up to four tracks in 32-bit float resolution, with on-board EQ and effects, amp simulation and the option to bounce recordings down then overdub.

Supplier's Notes:
The Little Recorder For Big Ideas

Introducing the Zoom R4 MultiTrak

Designed By Musicians

All of our engineers are musicians and they designed the R4 to empower musicians to explore big ideas. With a unique dedicated 'bounce track' and 32-bit float recording, the R4 is perfect for capturing your most ambitious compositions.

Record. Bounce. Repeat.

With the R4, you can record up to four tracks, mix and then bounce them to the dedicated 'bounce track.' This lets you free up additional tracks to keep adding layers.

You can choose to do a 'quick' bounce or mix and bounce in real time.

The R4 also allows you to 'undo' your last bounce, if you're not satisfied with the results.

32-Bit Float Recording

The R4 captures perfect audio with every take, without the need to set gain.

Combo Inputs

The R4 has 2 XLR/TS combo inputs with legendary Zoom preamps. You can plug in microphones, instruments, keyboards, and more.

Track Effects

Each track features a 3-band EQ, pan, echo, and reverb to refine your mix.

Input Effects

Apply effects to input A such as amp simulations, delays, distortions and more.

Built-In Microphone

The R4 features a high-quality built-in microphone, perfect for acoustic guitars, vocals, or capturing a quick reference recording.

Much More Than A Metronome

The R4 has a rhythm section preloaded with over 80 different drum patterns to play along with featuring genres such as rock, hip hop, funk, heavy metal, and more.

Every Take Is Saved

Tracks that you record are automatically saved individually, even after they have been bounced.

32-Bit Float Audio Interface

The R4 is also a powerful 2-in/ 2-out USB audio interface with 32-bit float technology. Connect it to either your computer or smartphone.

Control and Create

With a fader for each track and dedicated hardware buttons for the most used functions, you won't need to menu dive to record your music.

Powered For Your Ideas

The R4 can be powered by 4 AA Batteries, or through its USB-C port.

Specs

Inputs/outputs
Inputs: Built-in mic (mono): 1
XLR/TS inputs (mono): 2
Output: Headphones: 1

Inputs
XLR/TRS inputs:
Connectors: 2 XLR/TRS combo jacks (Balanced, XLR: 2 HOT)
Input gain: No adjustment required (dual A/D converter circuit used)
Input impedance XLR: 2.3 kO; TS: 1 MO
Maximum input level: XLR: +4 dBu, TS: +10 dBu
Phantom power: +48 V (switchable separately for INPUTS A and B)
Equivalent input noise: XLR: -120 dBu or less (IHF-A); TS: -107 dBu or less (IHF-A)
Frequency response: XLR: -0.5 /+0.0 dB : 20 Hz - 20 kHz; TS: -0.2 /+0.0 dB : 20 Hz - 20 kHz

Built-in mic input
Directionality: Omnidirectional
Input gain: No adjustment required (dual A/D converter circuit used)
Maximum sound pressure input:
115 dB SPL
Output

Headphone

Connector: 1 stereo 3.5mm mini jack
Output impedance: 10 O
Maximum output level: 20 mW + 20 mW (into 32O load)

Recorder

Maximum simultaneous recording tracks: 2
Recording format: WAV: 48kHz, 32-bit float, mono
Recording media: Cards compatible with microSDHC specifications 4 GB - 32 GB; Cards compatible with microSDXC specifications 64 GB - 1 TB

Display: 2" full-colour LCD (240 × 320)

USB

Connector: USB Type-C
Note: Use a USB cable that supports data transfer. USB bus power is supported.
Audio interface function
Class: USB 2.0 High Speed
Sampling frequency: 48 kHz
Bit rate: 24-bit/32-bit float
Input / output channels: 2 in/2 out
Mass storage function: USB2.0 High Speed

Power supply

Batteries: 4 AA (alkaline, lithium, or rechargeable NiMH)
AC adapter: ZOOM AD-17 (5V/1.0A)
* USB bus power is supported.
Estimated continuous operation time using batteries

Alkaline batteries: about 7 hours
NiMH batteries (1900 mAh): about 6 hours
Lithium batteries: about 14 hours
* Use conditions: Recording 1 track, playing 1 track, phantom power off, headphones into 32O load, power saving on
* The above values are approximate. * Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.

Power consumption: 5 W
External dimensions: 74 mm (W) × 138 mm (D) × 36 mm (H)
Weight (including batteries): 287 g
Note: 0 dBu = 0.775 Vrms

Notes: Updated version of the hugely popular MSP3, now with Yamaha's Twisted Flare Port technology for improved low-end response. Small design with big sound thanks to 4-inch woofer and precise dome tweeter.

Supplier's Notes:
MSP3A powered monitor speaker provides faithful sound reproduction in a compact form

The MSP3, a compact reference monitor speaker loved for many years, has been renewed as the MSP3A. This new reference monitor is the first in this series to include our Twisted Flare Port technology and provides an even clearer and tighter low-end while also realizing faithful sound reproduction.

The built-in 22W power amplifier is optimized for the speaker unit, which comprises a 10 cm (4") woofer and a 2.2 cm (.87") tweeter, to achieve a clear and natural reference sound.

The cabinet features a refined, simple design and weighs a mere 3.6 kilograms (7.9 pounds), making it easy to reposition and carry to different locations. Just like its predecessor, this monitor has multiple input connectors and controls, and is compatible with a variety of optional brackets, making it useful for a wide range of uses. These include serious audio and music monitoring in settings from small-scale studios to broadcast and post-production suites, as well as monitoring audio from digital musical instruments and ICT devices, and surround sound playback.

Twisted Flare Port technology, which is included in the MSP3A for the first time in this series, is an aerodynamic sound control technology that we at Yamaha have created by leveraging our extensive subwoofer development experience. Using it, we apply aerodynamic sound analysis and flow visualization measurement technologies to pinpoint and control noise generation mechanisms. Noise-generating air flow turbulence at both ends of the port is suppressed by changing how the port widens from input to output and adding a twist to it. Suppressing turbulence reduces bothersome muddiness in the sound and lowers the amount of noise generated at the port ends. This strengthens the connection between the sound and main speaker and delivers clear, tight low frequencies along with pitch and rhythm.

Compared to the air turbulence generated by the "ordinary port" shown in pink on the left, turbulence is reduced and air flows smoothly through the Twisted Flare Port shown in blue on the right.

Featuring a 22-watt built-in amplifier and Twisted Flare Port for clearer bass, the MSP3A reference monitor produces sound that is faithful to the original. With a variety of inputs, controls and optional support brackets, the MSP3A is ideal for small studios, post-production, monitoring electronic instruments and surround reproduction.

General specifications:

Speaker type: 2-way powered speaker, Bass-reflex type (Twisted Flare Port)
Frequency response: (-10dB) 67Hz - 22kHz
Components- LF: 4" (10 cm) Cone, HF: 0.8" (2.2 cm) Dome
Crossover: 4kHz
Output power: 22W
Maximum Output Level (Measured peak, IEC noise@1m): 99dB SPL
Input sensitivity- LINE 1 : -10 dBu, 10kO (RCA), LINE 2 : +4.0 dBu, 10kO (Combo)
I/O connectors- LINE 1 : RCA, LINE 2 : Combo (XLR/TRS phone)
Indicators: Power ON (Green LED)
Power requirements (May vary depending on region): 120V 50/60Hz, 110 - 120V 50/60Hz, 230V 50/60Hz, 220 - 230V 50/60Hz, 220V 50Hz, 240V 50Hz
Power consumption: 30W
Others: Level control (LINE1, LINE2); Tone control (LOW = Center, REF = 100Hz : MIN -3.0 i 2.0 dB, MAX +3.0 i 2.0 dB; HIGH = Center, REF = 10kHz : MIN -3.0 i 2.0 dB, MAX +3.0 i 2.0 dB)
Dimensions: W- 144mm (5-5/8"), H- 236mm (9-1/4"), D- 166mm (6-5/8")
Net weight: 3.6kg (7.9 lbs.)
Accessories: Power cord, Owner's manual
Packaging: Single
Flying and mounting hardware: 2 x M5 (Depth 15)
Options: Mic stand adaptor BMS-10A, Free-angle clamp BAS-10, Wall mounting bracket BWS20-120 / BWS20-190, Ceiling bracket BCS20-150 / BCS20-210

Notes: The Yamaha HS5 is a new addition to Yamaha's HS series of active monitors, influenced by the critically acclaimed and highly sought after NS-10 studio monitor speakers.

The Yamaha HS5 Active Studio Monitor features biamped full range 2 way speakers rated at 45W and 25W and has been developed by Yamaha to offer an exceptionally flat and accurate frequency response for use in music production and composition as well as home project studios. The HS5 monitors' design has been informed by the tradition of the legendary NS10M monitors.

Yamaha HS5 speakers feature a low resonance bass reflex enclosure which improves the rigidity of the overall speaker, and less cabinet resonance means that the signal remains clear and uncoloured. This is very important in getting an accurate mix which translates across all systems.

Port noise has also been audibly reduced by up to 6dB using the new Yamaha proprietary technology in the HS5 studio monitors, which also helps to deliver a clean and precise signal. The HS5 is equipped with XLR and TRS jack connectors as well as room control and hi trim response controls.

Notes: Configuring a streaming setup from scratch can be a daunting task, particularly for users with little or no music production experience. The minimalist design of the AG01 takes this into account by combining a high-quality condenser microphone with DSP effects, a LOOPBACK function, flexible input connectivity, and a simple, intuitive mixer for stress-free streaming operation.

Simply connect to your computer or iOS/Android device along with the headphones of your choice, then set your levels and you've got a fully operational streaming station that can be up and running within minutes. If you're an aspiring live streamer that requires a compact yet comprehensive, high quality all-in-one solution, the AG01 is ready when you are.

In most streaming applications your microphone is likely to feature prominently onscreen so it is important for it to complement your overall vision. With a unique and iconic design that blends classic and contemporary aesthetics, the AG01 looks as good as it sounds, offering both black and white-based models to suit your preference.

In addition to the condenser microphone audio input, the AG01 is equipped with a mini stereo line input jack, and an upgraded 4-pole mini jack (TRRS) for smartphones that allows input and output. You can also add audio from devices connected via USB in LOOPBACK mode. Combined with these features, this microphone-type model can cover a wide variety of streaming styles that could not be achieved in the past without a separate mixing device.

The AG01's high-performance condenser microphone utilizes a cardioid polar pattern that captures your voice or musical instrument performance precisely, and converts it into high resolution audio (192kHz, 24bit) while blocking out unwanted ambient noise from the rear or sides.

The AG01 features high-quality DSP effects, allowing you to easily add COMP/EQ and REVERB to color and hone your audio and get the best sound possible to broadcast to your audience. What's more, these tools are processed by the internal DSP chip so there is no delay, making the AG01 particularly valuable for live streaming, when real-time accuracy is required.

You can also turn these effects off completely to capture pure, raw recordings of the AG01's condenser microphone for music/audio production that will be edited by an engineer later.

There are many situations in live streaming where you may need to make audio adjustments on the fly. The carefully configured physical controls of the AG01 respond to these needs providing a simple operating experience that won't detract from your live content or performances.

AG Controller offers two modes, "Simple" and "Detail," which allow users with varying degrees of audio engineering experience to easily and precisely check and adjust the AG's DSP processing from any Windows/Mac or iOS device connected via USB.

The AG01 can be easily placed on a desk or any flat surface with its dedicated stand, or mounted on a desk arm, making it adaptable to almost any environment.

It can also be used in combination with a mobile battery allowing you to take your fully functioning streaming station anywhere you like.

*For stable operation of the AG01, a power supply of DC 5V 900mA or more is required.

AG01 comes bundled with Cubase AI music production software, as well as WaveLab Cast for audio production and editing. The AG01 is also compatible with Rec'n'Share and Cubasis LE applications for iOS devices which are available free of charge from Yamaha and Steinberg to support and inspire your audio content creation.

Specifications

Microphone Unit: Back electret condenser type
Polar Pattern: Cardioid
Adress Type: Side
Frequency Response: 30 Hz - 20 kHz
Max Input SPL: 110 dB (THD - 1.0% at 1 kHz)
Sensitivity: -34 dB i 3 dB (0 dB=1 V/Pa, at 1 kHz)
Connector: USB Type-C

Input Channels
Microphone: 1 (Mono condenser microphone)
AUX: 1 - Stereo mini
Smartphone: 1 - 4-pole mini input/output (TRRS)
USB: 1

Output Channels
PHONES: 1 - Stereo mini
Smartphone: 1 - 4-pole mini input/output (TRRS)
USB: 1
Bus: 1 Stereo
Functions: MIC GAIN (HIGH / MID / LOW), MUTE button x 1, STREAMING OUT (MIC / INPUT MIX / LOOPBACK), MIX MINUS MIC (ON / OFF)

On-board processors
DSP: COMP/EQ, REVERB (SPX Reverb) *Detail is Controlled on AG Controller
USB Audio: 2 IN / 2 OUT, USB Audio Class 2.0 Compliant, Sampling Frequency: Max. 192 kHz, Bit Depth: 24-bit, Type-C
USB DC Power Input: 1 - Type-C, 5 V DC, 900 mA

General specifications
Power requirements 5 V DC, 900 mA
Power consumption Max. 4.5W
Dimensions: W: 116 mm (4.6") H: 281 mm (11.1") D: 118 mm (4.6")
Net weight: 1.2 kg (2.6 lbs)
Included accessories: USB 2.0 Cable (1.5 m), Quick Guide, Safety Guide, Wavelab Cast Download Information, Cubase AI Download Information
Others: Operating Temperature: 0 to + 40C

Notes: Express Yourself with Yamaha

By incorporating decades of expertise in developing musical technologies, the YDM Series of dynamic microphones provides an exciting new addition to the Yamaha audio line-up that spans the entire input to output signal chain.

Custom-designed Capsule

Encased in a sleek metal body, the YDM Series microphones feature custom-designed capsules that flawlessly capture your sound so you hear crystal-clear audio on the other end.

The YDM707 is equipped with a super-cardioid capsule that captures a wider frequency range and rejects unwanted background sounds even more efficiently.

Insulator that Reduces Handling Noise

YDM Series microphones are equipped with an advanced insulator Yamaha's proprietary materials that reduce vibrations from handling noise and other external sources, allowing you to concentrate on your performance.

A Refined Grip that's Instrumental

Taking cues from our experts in musical instrument design, the YDM Series microphones follow a refined design that incorporates the flowing curves of a wind instrument. The top and bottom of the grip are accented with silver rings, giving it a distinctive design.
The grip is not only beautifully designed; it has also been optimized through repeated prototype tests to ensure a comfortable fit.

YDM Series Grille

For some performers, mic drop moments are unavoidable. Whether from epic monologues or mishaps, replacement grilles are sold separately so you can keep your microphone looking like new.

Accessories

In addition to the microphone holder, a 5/8" to 3/8" inch threaded adapter and a microphone pouch are also included.

Microphone Unit: Dynamic
Polar Pattern: Super Cardioid
Frequency Response: 60 Hz - 18 kHz
Sensitivity: 1.8 mV/Pa (-54 dB)
Output Impedance: 300 Ohm
Connector: XLR
Dimensions (Microphone Only): 51 x 184 mm
Weight (Microphone Only): 285 g
Included Accessories: Microphone Holder, 5/8" to 3/8" threaded adapter, Microphone pouch

Notes: ***B-STOCK: Box opened, product in perfect working order***


The smallest speaker in Yamaha's range, the compact MS101-4 sits happily on even the most cramped desktop or attaches to a mic stand for versatile monitoring anywhere.

Supplier's Notes:
The industry standard in compact monitors

Yamaha MS101-4: The de facto standard for compact monitoring in a simple form

The standard model in Yamaha's range of desktop utiility powered monitors, the MS101-4 offers portability in a simple, compact design, with comprehensive functions for outstanding usability. The MS101-4 comes with a 3/8-16 threaded female mounting for direct attachment to a Euro microphone stand. Optional accessories can also be added for use in a wide range of applications.

A compact, convenient approach to high-quality monitoring anywhere

Compatible with both line and mic inputs, the MS101-4 offers the flexibility needed for temporary or permanent use in applications requiring simple, compact monitors.

Simple, portable, durable design

Yamaha Powered Monitor Speaker MS101-4: front and rear

With the controls (power switch, volume and tone controls) and the combo jack input on the lower front panel, you'll find the MS101-4 is easy to operate. The sturdy metal grill offers complete protection for the four-inch cone driver, while the rear panel is equipped with one stereo mini and a TRS Phone input connector, along with an output jack. An AC inlet for a removeable power cord provides excellent portability. The bass reflex port is also located on the rear surface, resulting in a more compact chassis.

MS101-4 Powered Monitor Speaker

The standard model in our range of desktop utiility powered monitors, the MS101-4 offers portability in a simple, compact design, with comprehensive functions for outstanding usability.

30W of amplifier power provides clean, high output sound
Redesigned enclosure for an even lower profile
Combo Input jack accepts both XLR and 1/4" connectors
Directly mountable on Euro microphone stands (optional mic stand adaptor BMS-10A is available for adjusting tilt angle)

General specifications

Speaker type: Full range Powered Speaker, Bass-reflex Type
Frequency range (-10dB): 77 Hz-20 kHz
Maximum output level (1m; on axis): 115 dB SPL *1
Components: LF-HF 4" Cone, 1" Voice coil, Ferrite magnet
Dimensions: W: 142 mm, H: 196 mm, D: 187 mm
Net weight: 2.1 kg (4.6 lbs)
Flying and mounting hardware Screw threads (bottom): 2 x M5 depth 11 mm pitch 60 mm (for 2, M5 x 6-10 mm screws), 1 x 3/8" depth 12 mm (for 1 x 3/8" x 9-11 mm screw)
Amplifier class: Class-D
Power rating: Dynamic: 30 W
Continuous: 20 W
Cooling: Natural cooling (no fan)
I/O Connectors: Mic Input: [Front] INPUT: Combo, [Rear] INPUT LINE 1: Stereo Mini, INPUT LINE 2: Phone (TRS)
Line Out: 1 x Phone (TRS)
AC: 1 x AC inlet
Input impedance: [Front] INPUT: LINE=5.4 kO / MIC= 5.4 kO, [Rear] INPUT LINE 1,2: 10 kO
Input sensitivity: [Front] INPUT: LINE=-10 dBu / MIC=-40 dBu, [Rear] INPUT LINE 1, 2: -10 dBu (VOLUME: Maximum)
Input Level: [Front] INPUT: LINE=+5 dBu / MIC=-25 dBu, [Rear] INPUT LINE 1, 2: +5 dBu (Nominal Input Level / VOLUME: Center), [Front] INPUT: LINE=+20 dBu / MIC=-10 dBu, [Rear] INPUT LINE 1, 2: +20 dBu (Maximum Input Level)
Others: Controls: 1 x VOLUME, 1 x LOW CONTROL, 1 x HIGH CONTROL, POWER
Indicators POWER (Green LED)
Power consumption: 1/8 Power Consumption: 10 W, Idle Power Consumption: 3 W
Power requirements: 100 V - 240 V, 50/60 Hz
Options: Mic stand adaptor BMS-10A, Free-angle clamp BAS-10, Wall mounting bracket BWS20-190, Ceiling bracket BCS20-150 / BCS20-210

Notes: Part of Xaoc's Leibniz subsystem, which processes signals and voltages by manipulating binary 8-bit numbers, the Poczdam allows switching between two data sources.

Supplier's Notes:
Poczdam is a binary data routing solution for the Xaoc Leibniz Subsystem. It facilitates manual and remote switching between two Leibniz data sources, modifying individual bits of the data stream, and re-clocking the data with its onboard voltage-controlled wideband oscillator or any external clock signal. Poczdam is particularly useful within complex Leibniz setups where the user needs to reconfigure the data flow between multiple modules. However, it can also be employed in small creative patches, e.g., for waveform splicing, disrupting rhythmic loops, or generating digital chaos.
To better understand the device and avoid common pitfalls, it is strongly advised to read through the entire user manual before use.

Component of the Leibniz Binary Subsystem
Routing Leibniz data
Reclocking Leibniz data
Additional CV clock generator (up to 2MHz)

6hp, 30mm deep
Current draw: +20mA/-10mA
Reverse power protection

The high quality Coal Mine black panels are available for all Xaoc Devices modules. Sold separately. Ask your favourite retailer.

Drezno is the input/output front-end of the system, consisting of an analogue-to-digital converter (ADC) and a digital-to-analogue converter (DAC), that alone can be used for manipulating analogue signals and voltages based on their binary representation.

Lipsk is a binary logic processing expander module that can flip (invert) individual bits of the digital signal representation. There are more Leibniz Binary Subsystem elements coming, with specialized and advanced sets of features.

Jena is a digital module that may be used as a flexible waveshaper for CV and audio signals, a wavetable oscillator, a Walsh function generator, or a rhythm generator.

Erfurt is a bi-directional digital counter, frequency divider. It has multiple applications: the output of the counter may be used as a phase source driving a digital wavetable, connected to other Leibniz modules it may scan waveshapes in Jena, produce stepped voltages useful for making interesting glissandi with Drezno and any VCO, generate gate patterns animating the spectrum of Odessa harmonic banks, spawn pseudo-chaotic sequences when fed back to Lipsk, etc.

Notes: Gera is a component of the Leibniz subsystem that allows masking individual bits of the digital data by the use of logical AND operation.

It features 8 individual gate inputs that affect the individual bits of data, as well as 8 illuminated tact switches for manual inverting of each control input. When connected to Drezno that is processing a waveform or voltage, masking of individual bits yields various forms of quantization. However, Gera can function on its own. The AND operation is a basic building block for sequence automation, chaos and rhythm generation, and various computer-like modular patches.

Bit processing logic in Gera is hardware based, hence there is virtually no latency, and the binary signals may change at extreme rates.

Main features:

Logical AND operation on Leibniz data
Masking of individual bits controlled manually and by gate signals
Visual indication by illuminated buttons
6HP
30 mm depth (including ribbon cable brackets)
- +12V: +45mA / -12V: 0mA / +5V: 0mA

Notes: Add external feedback loops, tilt filters and more to the Timiszoara effects module with this versatile expander. A must-have for Timiszoara owners.

Supplier's Notes:
Deva is an expander for Xaoc Devices' Timiszoara multi-fx module designed for creative exploration of the dirty/nasty side of signal processing. Deva opens up the Timiszoara programs you've come to love with some unexpected twists and turns along the way. The analog side features two external feedback loops (for the left and right channel) with tilt filters adjustable via sliders with two additional switches for choosing positive or negative feedback (for each channel). The third slider controls the DAC clock - from overclocking by a factor of two down to 16-times slower, so you can go from chipmunk to hardcore teeth gnashing of underclocked goodness. A switch allows for turning the clock control off for normal/regular operation. All features have inputs for external CV.

Technical details

Eurorack synth compatible
8hp, skiff friendly
Power drawn from Timiszoara: +60mA/ -50mA
Reverse power protection

Notes: Tallin is a dual voltage controlled amplifier (VCA) with overdrive, offering some unusual control features and a range of attractive tonal characteristics. Each of the two identical channels offers two simultaneously available inputs for voltage control over signal attenuation or gain, with linear and exponential response to CV. Volume control knobs offer manual gain settings ranging from fully closed (-80dB) up to +18dB. A colour LED indicator displays output signal levels. A soft-clip circuit avoids harsh clipping distortion, while a switchable overdrive circuit offers two carefully crafted distortion responses, simulating the sound of classic tube amplifiers.

Since both CV inputs are simultaneously active, they can be jointly exploited within patches featuring more complex volume control that otherwise would require using two traditional VCAs in series. As the signal path is DC-coupled, Tallin can also be used for handling the control voltages.

Notes: User-friendly mid/side processing module. Tweak the stereo image or split a stereo signal into mid and side elements then route out to other modules for further processing before summing back together. Powerful.

Supplier's Notes:
Minsk is a stereo image processor. It is a hybrid tool that combines digital and analog processing to facilitate advanced mid/side (M/S) manipulation of a stereo signal pair. It allows for separate treatment of the mid and side components, which affects the depth and width of the auditory scene. Minsk offers both manual and voltage control of the stereo width, as well as two dimension effects for enhancing the existing stereo image or creating a faux stereo image based on the stereo or mono input source. Minsk is especially handy during the preparation of a vinyl release or before a club concert, because it can eliminate out-of-phase low-end frequencies (high pass filter at 300Hz with the filter slope 12dB/oct, 50Hz with the filter slope 24dB/oct).

Dimensions:
6 HP

Current Draw:
140 mA +12V
40 mA -12V
0 mA 5V

Notes: Lipsk facilitates the inversion of the individual bits produced by Drezno (or any other module connected to its input header at the back), and delivers the resulting code to its output header. Bit inversion can be manually controlled by pressing any of combination of its eight illuminated buttons, or it can be automated by patching gate signals into its gate input sockets. An active (5V) gate flips the state of the respective bit. If the button is active (bit already flipped), then the gate flips the bit again yielding double inversion (no inversion). The corresponding LEDs show the combined effect of both manual and gate actions. The bit processing logic is hardware-based, so there is virtually no latency, allowing the binary signals to be manipulated at extreme rates.

Review: Shinichiro Yokota's legendary discography finally arrives on vinyl with The Pitstop Box, featuring 24 essential and exclusive tracks. Originally available only in Japan via Far East Recording, this long-awaited collection highlights Yokota's signature blend of funk, hip-hop, electronic and Japanese influences. It features house classics like 'Right Here Right Now' and 'Night Drive', plus a cover of Haruomi Hosono's 'Simoon' and a collaboration with Soichi Terada that is packed with signature melodic sugariness. Inspired by his love for sports cars, The Pitstop Box is a brilliant overview of one of house music's finest talents..

Notes: The tiny but mighty Eurorack power supply with all the bells and whistles

Micronova is a miniature power supply with a big soul. It can provide up to 18W of power for your modules and multiple units can be easily daisy chained to power larger systems.

This bundle includes:

an assembled Micronova
an assembled Micronova busboard
a Micronova front entry kit

Please note that the front entry requires assembly. It's a delightfully easy kit, but make sure you know what you're getting into!

A suitable AC-DC power adapter is required. We have adapters available for domestic customers. International customers please take a look at the manual for guidance and recommendations.

Check out the manual to get to know Micronova and all of the delightful ways you can integrate it into your case.

100 mm x 30 mm x 13 mm
15-20V, 1.5A
+12V @ 1A
-12V @ 300mA
+5V @ 500mA
Daisy chainable
Busboard included
Front entry kit included

Notes: DASSBRUM is a powerful kick module capable of producing a wide variety of sounds, ranging from classic kick tones to complex folded timbres. It features an analogue core processed through a digitally controlled matrix of analogue wave folders and envelopes, offering deep sonic flexibility in a compact 8HP form factor. A built-in sweet spot mode ensures optimal pitch envelope relationships for consistently punchy and dynamic kicks.

Consumption: 120mA +12V /30mA -12V
Width: 8HP
Depth: 29mm

Inputs maximum ratings
Fold type (rear switch): 0/5V
Trigger IN: 5V (>0.5V)
Other inputs: -5/10V

Notes: EME (Eloquencer MIDI Expansion) is the perfect companion for the Eloquencer, adding capabilities to sync with MIDI devices, control most of the eloquencer parameters with MIDI interfaces, generating MIDI voices from the eloquencer tracks, and converting MIDI signals to the eurorack world.

Description:
MAIN FEATURES
IN / OUT
DIN-5 MIDI Input, DIN-5 MIDI Output, USB Host.

BUTTONS
4 freely assignable buttons. They can be assigned to:

Next/previous pattern
Next/previous part
Direct access to Pattern mode, Play parts, Duplicate, Project, Gate REC, CV Key REC, MIDI key REC, Free Play...
Save current project
Random 1 to 3 layers of selected track
Reset LFO of selected track
On/Off LFO of selected track
Freeze
Revert
Fill A to H or selected track
Mute A to H or selected track
DJ Nudge FWD/BCK fine/coarse

MIDI CLOCK
Eloquencer can receive 24ppqn sync from MIDI device from its DIN-5 MIDI Input, and can send 24ppqn MIDI clock through its DIN-5 MIDI out.
When working as 'internal' it will send the internal clock to the MIDI output.
When working as 'external' will send the eurorack incoming clock to the MIDI output transformed into 24ppqn.

MIDI OUT
The Eloquencer tracks can be independently assigned to:
- Voice events (note on/off, velocity, ch pressure...) For example Track A can be assigned to Channel 1 Note on/off and Track B can be assigned to Channel 1 Velocity, so track A gates and CV control Channel 1 notes and pitch, and track B controls Channel 1 Velocity.
- Control Change (CC)
- Program Change (PC)

The gate and CV output will work as usual when a MIDI OUTPUT is assigned, so voices can be doubled using the modular and an external synth.

There's a particular execution order for MIDI out events, so the first to be launched is the Program Change, followed by the CC and then the voice events. This way, we can launch program changes before the note on message is received allowing preset changes for each step.

MIDI IN
Both, the DIN-5 MIDI in and the USB can be used to change eloquencer parameters using controllers or to introduce notes in REC MODE using a keyboard.

There are 3 different groups of controls associated to MIDI channels:
- Channel : 8 MIDI channels to control parameters of specific tracks from A to H
- Global : 1 MIDI channel to control Global parameters.
- Focus: 1 MIDI channel to control the parameters of the currently selected track (track in focus). That means that if Track A is selected and we send CC 38, we will be shifting track A, but if we select track B and we send the same CC 38, we will be shifting track B.

When using the USB host input, the EME can send feedback information in case the controller that is being used has LEDs to be updated.

There is a big amount of eloquencer parameters that can be controlled using an external MIDI interface / controller. For example:

Non-destructive track parameters addition/subtraction (CV, CVP, CVR, GL GLP, R...)
Track length
Step mode / Step mode DIV / Step mode REP
Track shift
LFO on/off / Type / Length / amplitude.
Fill
Mute
Random
CV Gate link
Scale group and root
Tempo
DJ Nudge
Shuffle
Clock out
Play / Stop
Direct access to modes (Pattern, Project, Live REC...)
MIDI INTERFACE

A MIDI Channel can be assigned to an Eloquencer Track, so the gate and CV outputs will stop listening to what is sequenced and start listening all note on/off messages coming from the chosen MIDI channel.

Review: Green Day's American Idiot is the much-loved band's seminal 2004 album, capturing the perennial angst and disillusionment of a generation, currently enjoying its 20th birthday although its politically charged punk rock remaining as relevant as ever. This anniversary edition enriches the original with unreleased demos, live performances, and alternate takes to offer a deeper insight into the album's creation. Tracks like 'Holiday' and 'Boulevard of Broken Dreams' still resonate, while the added material highlights the band's creative process.

Review: Second time around for Madonna's Finally Enough Love box set, which celebrates the iconic artist's unique achievement of notching up no less than 50 number ones on the Billboard Dance chart - the first artist in history to do so. In effect, it's a celebration of her Madgesty's links with dance music culture, showcasing 40 years of popular reworks of her biggest hits, presented in a 'rainbow edition' box set where each of the six slabs of wax is pressed onto different coloured vinyl. So, alongside classic early hits and reworks from 1987 remix album You Can Dance, we get revisions by everyone from Junior Jasquez, Jellybean, Shep Pettinone and Pet Shop Boys, to William Orbit, Aviici, Felx De Housecat, Jacques Lu Cont and Tracey Young. Madonna-ologists assemble!

Review: American Idiot marked a pivotal moment in Green Day's career, propelling them to new heights both commercially and creatively. The album, released in 2004, combines punk energy with a bold narrative, delivering a politically charged rock opera that resonated with a generation. Its mix of rebellious spirit and introspective lyrics touched on themes of disillusionment, suburban angst, and the search for identity. Tracks like the explosive title song and 'Holiday' channel raw defiance, while 'Boulevard of Broken Dreams' and 'Wake Me Up When September Ends' showcase the band's ability to craft emotional ballads with wide appeal. The ambitious multi-part suites 'Jesus of Suburbia' and 'Homecoming' are daring, theatrical pieces that added depth to the album's story arc. Billie Joe Armstrong's sharp songwriting and the band's tight, dynamic sound made American Idiot a modern classic. Its balance of punk rebellion and mainstream accessibility cemented Green Day's place as one of the defining rock bands of the 2000s.

Notes: Varia Instruments' turntable weights feature a smart mechanism: The 7" adapter inside the weight is moveable, as soon as you put the weight on a 7", the adapter will fall down through the big hole of the vinyl. Your record is now centered and stabilized by the TTW10. If you place the kit on a 12" record, the adapter will remain in the rear position and stabilizes your warped records. A sticky rubber mat on the bottom side protects your vinyl and allows you to control the record in a very direct way. The difference to the classic TTW10 is the material used for the outer part: The heavy weight edition is machined out of high-grade stainless steel which results in a final weight of 808g/1.78lbs. The TTW10H comes in a neat printed box with a linen bag to take it out to your gigs.

Notes: UDG Ultimate Flight Case Multi Format Turntable Black MK2 not only transport your complete set up easily & securely, but also facilitates devices to be setup within minutes. With these premium features incoporated, the UDG Ultimate Flight cases provide premium professional quality in a very stylish modern black colored combination.
Fits: Technics SL-1200MK7, Reloop RP-8000MK2, Denon DJ VL12 Prime, Pioneer PLX-1000, Audio Technica LP120XUSB, or similar size turntables.

We, at UDG have further fined-tuned already a great design concept of our flight case into one specially for the most discerning DJ/producer. Constructed from solid 9mm thick plywood, the outside is laminated in a black finished honeycomb/hexagonal "Stage Grip" pattern. The inner sides are protected with high density diamond embossed EVA foam protective padding. This extremely robust padding protects the equipment against scratches, dust or other damages, creating a unique stylish & practical finish.

Extra wide black finished aluminum profile & massive UDG logo embossed ball corners are incorporated to ensures longevity & maintaining a permanently attractive, professional design. The UDG Ultimate Flight Case Multi Format Turntable Black MK2 also features heavy duty spring loaded handles for a secured lift & load.

UDG Ultimate Flight Case Multi Format Turntable Black MK2 not only transport your complete set up easily & securely, but also facilitates devices to be setup within minutes. With these premium features incoporated, the UDG Ultimate Flight cases provide premium professional quality in a very stylish modern black colored combination.

Specification
Color Black
Weight 7,80 kg / 17.16 lbs
Outer Dimensions (W x H x D) 51.1 x 42.6 x 23 cm | 20.1 x 16.7 x 9.1 inch
Inner Dimensions (W x H x D) 45.1 x 38.6 x 7.8 cm | 17.7 x 15.2 x 3.1 inch
Material Heavy duty construction of 9 mm thick plywood
Protection Extra-wide black solid aluminum profiles
Secure stacking due to stackable ball corners
Sturdy construction
Full padded interior keeps controller well-protected
High density diamond embossed EVA foam protective padding
Extra's Laminated in a black finish with a honeycomb/hexagonal "Stage Grip" pattern
Fits Technics SL-1200MK7, SL-1200GR, SL-1200GAE, SL-1210GR
Pioneer PLX-1000
Denon DJ VL12 Prime
Reloop RP-8000MK2, RP-7000MK2, RP-4000MK2, RP-2000MK2, RP-1000MK2
Stanton ST-150, STR8.150, T.52, T.55 USB, T.62, T.92 USB
Vestax PDX-3000
Numark TTX
Audio Technica LP120-USB, LP1240-USB, LP120XUSB, LP1240-USBXP, LP140XP, LP3, LP5, LP7, LPW40WN
American Audio Power Drive 2.2
Mixars LTA, STA
or similar size turntables
And accessories

Notes: UDG presents the Urbanite Series, cutting edge bags for today's on-the-go DJ's / Producer's. Each design not only makes you feel good, they make you look great. The Controller Backpack lets you take a wide variety of your essential gear for your digital set up from one gig to the next. It lets you safely store your digital controller (Pioneer DDJ-SX3, Native Instruments S8) in the main compartment while in the side entry laptop compartment you can store up to 19" laptop. It has enough space in the two front pockets to store all your other necessities; hard drives, headphone, cables & accessories and is fully padded in all the right places for the ultimate in protection. The backpack has a 4-method carrying system. The UDG Controller Backpack is available in 2 sizes: Medium & Large skillfully designed to fit many different models of equipment safely during transport.

Specifications

Colour: Black
Weight: 3,95 kg / 8.69 lbs
Outer Dimensions (W x H x D): 73.0 x 43.0 x 22.5 cm | 28.7 x 16.9 x 8.9 inch
Inner Dimensions (W x H x D): 70.0 x 40.0 x 10.0 cm | 27.6 x 15.7 x 3.9 inch
Material: Water repellent laminated 600D Polyester exterior
Protection: Adjustable foam inserts to customize main compartment to your gear

Extras
4 compartments: main: for controller, side: for laptop up to 19", front: 2x for headphone, hard drives, cables & accessories
4-method carrying system
Easy grip zipper pulls
Convenient carry handle & padded shoulder strap

Fits:
Up to 19" laptop
Pioneer DJ DDJ-FLX6, DDJ-1000SRT, DDJ-800, DDJ-1000, DDJ-RX, DDJ-SX3, DDJ-SX2, DDJ-SX, DDJ-RR, DDJ-SR, DDJ-S1, DDJ-T1
Pioneer DJ XDJ-RR, XDJ-R1, XDJ-Aero
NI Traktor S8
Denon DJ Prime 2, MC7000
Numark NS4FX, NS6II, NS6, 4Trak, N4, Mixdeck Quad
Rane One,
Reloop Mixon 8 Pro, Mixon 4, Touch
Roland DJ 505
or similar size controllers

Notes: Inspired by the legendary UDG ProducerBag, the UDG Ultimate ProducerBag Large has been created to cater for those electronic musicians who crave more space for their performance equipment.

Fits: Pioneer DJM-S5, Toraiz SP-16, Denon DJ Prime Go, Novation AFX, Akai MPC Live II, Reloop Elite, Rane Seventy, Seventy-Two, NI Maschine Jam, and various pedalboards

The UDG ProducerBag Large offers increased space for performers using laptops up to 18.4" and larger MIDI Controllers. Constructed from high quality fabrics, the backpack style UDG ProducerBag Large features padded walls with an adjustable divider to create an internal partition to suit your own requirements. Available in black, the bag offers both comfortable transportation and padded protection for your valuable items.

Specifications

Colour: Black, Orange inside
Weight: 3,25 kg / 7.15 lbs
Outer Dimensions (W x H x D): 56.0 x 45.0 x 18.0 cm | 22.0 x 17.0 x 7.1 inch
Inner Dimensions (W x H x D): 46.5 x 32.0 x 15.0 cm | 18.3 x 12.6 x 5.9 inch
Material: Water Resistant Nylon 420D
Protection: Padded MIDI Controller compartment
Bottom guards fabrics protect from scuffing and abration.

Extras

6 pockets for Accessories and smaller gears
Top carry handles
Ergonomic detachable shoulder strap
Integrated combination lock.

Fits:

Up to 18.4" laptop
Pioneer DJM-S5, Toraiz SP-16, DJS-1000, DJM-750MK2
NI Traktor Kontrol S2 MK2, Maschine Jam/ MK3/ MK2, Traktor Z2
Denon DJ Prime Go, MC6000 MK2, MC3000
Numark iDJ Live II, Mixtrack II / Pro II
Rane Seventy, Seventy-Two
Akai MPC Live II, APC 40 MK2, MPD232, MPD26, MPD32
Reloop Elite, Beatpad/2, Beatmix, Digital Jockey-3, Jockey 3 Remix, Terminal Mix 2
Novation AFX, 25SL MK2, Launchkey 25, Nocturn 25
Hercules DJConsole RMX2, DJControl Jogvision, DJ Control Air+ S
M-Audio Oxygen 25, Trigger Finger Pro, Xponent
Stanton SCS.4DJ, DJC.4
Livid OHM 64
Vestax VCI-380/400/400DJ,
Arturia Drumbrute, Keylab 25
Various pedalboards

Notes: Ultimate DIGI Backpack specially designed for the laptop DJ. Constructed from high quality water resistant Nylon, it contains a cleverly designed side entry compartment for a laptop up to 15.4" without having the hassle of going through the main body of the bag. The bag main compartment can hold an extra laptop and it can also hold a Native Instruments MASCHINE MK2 size MIDI controller. There is a detachable interface pouch and on top of the bag there is a padded, quick access headphone pocket. There are 5 zipped compartments to securely store USB sticks, SD cards, wires and cables, AC power adapters, compact camera's, MP3 player, and other accessories.

Colour: Black Camo/ Orange Inside
Weight: 2,10 kg / 4.62 lbs
Outer Dimensions (W x H x D) cm: 33.5 x 48 x 27 | inch: 13.2 x 18.9 x 10.6
Inner Dimensions (W x H x D) cm: 30 x 42 x 13 | inch: 11.8 x 16.5 x 5.1
Material Water Resistant Nylon 450D
Protection: Various padding used

Extras

Front compartment with organization panel and detachable pouch for audio interface
5 exterior pockets for personal essentials, including one with earbud pass-through for Mp3 players
S-curved shoulder straps for ultimate comfort.

Fits:

up to 15.4" laptop, LP's,
Pioneer DDJ-XP2, DDJ-200, DDJ-XP1, DDJ-SP1, DDJ-WeGO 3/ 4, Toraiz Squid,
NI Maschine MK3/ Jam/ MK2,
Denon DJ MC2000, SC2000,
Akai MPC Live/ II, MPD226, MPD232, MPD32, MPD26, MPK Mini MK II, MPC Element, MPC 500, APC 20, APC Key 25,
Ableton Push/ 2,
Allen & Heath Xone 23/ C, Xone 43C,
Novation Launch Control XL, LaunchPad Pro, Circuit, Twitch,
Numark Scratch, Omni Control, Stealth Control, Party Mix, iDJ Live II, Mixtrack Edge,
Reloop Beatmix, Digital Jockey III/ II, Mixage IE, Neon,
Roland Aira MX-1, TR-707, MC-202, TR-8, TR-8S,
Korg MicroKey 25,
M-Audio Oxygen 25, Trigger Finger Pro,
Arturia Drumbrute,
Gemini FirstMix Pro, Slate2, Slate4, CDJ-700,
Hercules P32 DJ Controller, Universal DJ, DJ Consule 4-MX, DJ Control Air S, DJ Control Wave, DJ Control Instinct,
Livid CNTRL:R,
Stanton DJC.4,
Vestax Spin 2, VCI-300/MK2, VCI-100/MK2,
Audio interface or MP3/MP4 player, books and magazines,

Notes: UDG have further finetuned what was already a great design concept of a flight case into one especially for the most discerning DJ/ producer. Constructed from solid 9mm thick plywood, the outside is laminated in a black finished honeycomb/ hexagonal "Stage Grip" pattern. The inner sides are protected with high density diamond embossed EVA foam protective padding. This extremely robust padding protects the equipment against scratches, dust or other damage, creating a unique stylish & practical finish.

Extra wide black finished aluminium profile & massive UDG logo embossed ball corners are incorporated to ensures longevity & maintaining a permanently attractive, professional design. The UDG Ultimate Flight Case Denon DJ SC LIVE 2 Black Plus (Wheels) also features roller wheels with high quality in-line skate bearings for convenient transport and heavy-duty, spring-loaded handles for a secured lift & load.

UDG Ultimate Flight Case Denon DJ SC LIVE 2 Black Plus (Wheels) not only transports your complete set up easily & securely, but also facilitates devices to be setup within minutes. With these premium features incorporated, the UDG Ultimate Flight cases provide premium professional quality in a very stylish modern black coloured combination.

Specifications:

Colour: Black
Weight: 14,50 kg / 31.9 lbs
Outer Dimensions (W x H x D): 72.4 x 47.3 x 23.3 cm | 28.5 x 18.6 x 9.2 inch
Inner Dimensions (W x H x D): 65.4 x 33.5 x 14.2 cm | 25.8 x 13.2 x 5.6 inch
Material: Heavy duty construction of 9 mm thick plywood
Protection: Improved powder coated and anodized hardware
High density diamond embossed EVA foam & carpeted protective padding
Dual anchor rivets with included washer
Extra-wide silver solid aluminium profiles
Secure stacking due to stackable ball corner

Extras

Convenient 80 mm space at rear for connections & PSU storage
Cable access hole with removable UDG emblem cover
Removable front access panel
Roller wheels with high quality in-line skate bearings for convenient transport
Fits: Denon DJ SC LIVE 2

Notes: UDG have further fine-tuned what was already a great design concept of a flight case into one especially for the most discerning DJ/producer. This flight case is constructed from aluminium, thus providing an extremely stable structure with a lighter weight compared to traditional flight cases. The inner sides are protected with pick & pluck foam that consists of two separate layers, each allowing the user to create individualised adapted compartments. The pick & pluck foam allows you to pluck out any desired shape you require for various-sized DJ-controllers and providing the additional option of creating another slot underneath the controller for a laptop or cable storage. This pick & pluck foam creates an easy, do-it-yourself customised system of case interiors.

The UDG Ultimate Pick Foam Flight Cases are designed to keep your gear protected from accidental damage when you transport it to and from gigs. They're compact and lightweight, yet tough enough to keep your gear safe.

New Features:

- Increased product dimension
- Three rear cable access hole with cover
- Four solid metal hinges

Colour: Black
Weight: 6,65 kg / 14.63 lbs
Outer Dimensions (W x H x D): 82.1 x 53.6 x 19.8 cm | 32.3 x 21.1 x 7.8 inch
Inner Dimensions (W x H x D): 80.1 x 51.6 x 17.6 cm | 31.5 x 20.3 x 6.9 inch
Material: Aluminium

Protection

Corrosion resistant aluminium profiles with strong rounded corners
Fully-lined with high density foam protective padding & egg-crate foam on lid
2 side strong butterfly lock & 4 solid metal hinges
Rubber feet at the bottom for support in standing

Extras

Lighter weight than traditional flight cases
Black Diamond finishing surface
Ergonomic & sturdy carry handle
Pick & pluck foam with two separate layers
Replacement pick & pluck foam is available to purchase
3 rear cable access holes

Fits:

Pioneer DDJ-REV5, DDJ-FLX10, DDJ-REV7, DDJ-FLX6, DDJ-1000/ SRT, XDJ-RX3, XDJ-RX2,
Denon DJ MCX8000
Rane One, Four
Roland Gaia SH-01
Akai Advance 49, MPK249
Arturia Keylab 49, Keylab Essential 49
Korg MicroStation, Taktile 49
M-Audio Oxygen 49
Novation Launchkey 49
Numark NS7 III
Or similar sized equipment

Notes: Classy DJ luggage from the ever-reliable UDG. 12-inch design permitted as hand luggage by all airlines. Sleek black nylon body with strong wheels, front pocket and sturdy handle.

Supplier notes:
The UDG Trolley To Go is specially designed to cater to the growing demand of the Airlines. The Trolley is a lightweight, compact version of the UDG Trolley 256 CD and is permitted as hand luggage in every airplane.

Notes: ***B-STOCK: Box opened, product in perfect working order***


The player is being released to promote the reissue of the vinyl version of "Memory of Creamy Mami" originally released in 1986, for which there have been many requests for a rerelease. The cover of the player is a special version that can be replaced with a magnet illustration of Mami and Yu.

Of course, the new player is also a collaboration with the famous ANABAS "GP-N3R". The body part will be pink, the surface will be light gray, and the parts will be pastel blue. The package (cosmetic box) will also be a special specification only available this time.

It will be released on July 10 2024 together with the vinyl edition of "Memory of Creamy Mami"!
