Back catalogue: Studio Equipment

Notes: ***B-STOCK: Box damaged, product in perfect working order***


Great value from this compact eight-channel mixer featuring built-in Alesis effects. Bluetooth and USB in/out give added versatility, allowing you to mix just about any sound source.

Supplier's Notes:
Easy-to-Use Analogue Audio Mixing with Built-in Effects from Alesis

The Alto Professional TrueMix 800 FX is a portable audio mixer with built-in DSP effects that delivers all the essential features you need for home recording, livestreaming, podcasting, or performing. The TrueMix 800 FX features 16 effects including chorus, flange and an assortment of high-quality delays and reverbs. There's also a convenient Bluetooth channel for easily streaming from your personal devices. A unique feature to the TrueMix Series, the Bluetooth channel also supports feedback-free phone pairing by utilizing mix-minus technology. There are eight analogue inputs with high-headroom circuitry for minimal noise and clipping in your signal. The four Mic Input Channels offer XLR inputs that are great for connecting dynamic mics or condenser mics with 48v phantom power. These channels also have balanced 14" line inputs for connecting instruments and other line-level signals. There are also two Stereo Input Channels, each with dual balanced 14" TRS inputs. These inputs are perfect for your line level audio sources. All channels feature a two-band EQ with colour coded knobs that make it easy to dial in your perfect sound while operating in low-light situations. There are even extra knob caps included so you can fully customize the look of your TrueMix 800 FX. Connecting the TrueMix 800 FX to your computer is also lightning fast, with plug and play connectivity on Windows and macOS. The TrueMix 800 FX is a feature-packed compact audio mixer that's perfect for using on-the-go.

Flexible Output Routing

Whether you're recording a podcast, livestreaming online, or making music at home, being able to hear yourself and easily route audio is essential. The TrueMix 800 FX features a variety of output and routing options to handle any scenario. There are four headphone outputs, each with their own volume control knob. If you need to send your audio signals to another destination like an external monitor or effects unit, each channel is equipped with a send knob so you can always dial in the perfect mix. For recording, the USB output sends a copy of the main outputs to your computer, or you can connect the 2-Track in/out to an external recorder which can also be sent directly to the headphones. The TrueMix 800 FX delivers everything you need to take full control of your audio routing in any situation.

Product Features:

TrueMix 800 FX Features
USB I/O for audio playback and stereo recording
Dedicated bluetooth channel with mix-minus return for feedback-free phone pairing
Four headphone outputs with independent volume control
16 built-in Alesis multi-fx with dedicated return channel
1/4" Main, Tape, and AUX outputs
Four mic input channels with phantom power and balanced line inputs
Two stereo input channels with balanced 1/4" TRS jacks
Two-band EQ on all channels
2-track inputs w/ assignable routing: main mix or headphone out
Eight-segment LED VU meter for precise level monitoring
Extra knob caps included in the box for added customization

Technical Specifications

Frequency Response All inputs: 20 Hz - 22 kHz (i1 dB)

THD+N (Total Harmonic Distortion)
All inputs: < 0.005% (@ 4 dBu, 1 kHz)

Gain Range Mic inputs (Channels 1-2): 0 - 50 dB Line inputs (Channels 1-2): 15 dBu - 35 dBu Line inputs (Channels 3-6): -20 dBu - +20 dBu

Max Voltage Gain
70 dB (MIC INPUT to MAIN MIX OUTPUT)
80 dB (MIC INPUT to CTRL ROOM / PHONES OUPTUT)
60 dB (MIC INPUT to MON SEND)

SNR (Signal-to-Noise ratio)
All inputs: > 110 dBu

Crossover Frequency
Adjacent inputs: < -80 dB @ 1 kHz
Inputs to outputs: < -75 dB @ 1 kHz (stereo L/R, Channels 1-2, panned hard left or right)

Phantom Power: +45 ~ +49V with switch control

Impedance
Mic inputs: 3.9 kO
All other inputs: > 10 kO
Aux outputs: 1 kO
All outputs: 120 O

Equalization High:
+/-15 dB @ 12 kHz
Low: +/-15 dB @ 80 Hz

Bluetooth
Profile: A2DP
Module: Bluetooth 5.0
Operating Frequency: 2402 MHz - 2480 MHz
Range: 100 ft. / 30.5 m

Connectors
(6) 1/4" (6.35 mm) TRS outputs
(6) 1/4" (6.35 mm) TRS stereo L/R inputs
(4) 1/4" (6.35 mm) TRS headphone outputs
(4) 1/4" (6.35 mm) TRS mono inputs
(1) Standard RCA L/R input
(1) Standard RCA L/R output
(4) XLR inputs
(1) USB type-B input
(1) DC power input

Controls
(1) Power switch
(15) volume control knobs (1 per input, 1 return, 1 EFX return, 1 2-track/USB in, 4 headphone outs, 1 Bluetooth, 1 main)
(6) Stereo pan control knobs (1 per input)

(6) Mon volume control knobs (1 per input)
(6) EQ Low control knobs (1 per input)
(6) EQ Hi control knobs (1 per input)
(6) Gain control knobs (1 per input)
(4) Buttons (1-EFX mute, 1 Bluetooth, 2 Source Select)
(1) Horizontal sliding switch

Indicators
(1) Power LE
(6) Peak LEDs
(1) Phantom LED
(16) Main Out Meter LEDs
(1) Bluetooth LED

Power Connection: DC Voltage: 18V, 1.2A Consumption: 18W

Notes: ***B-STOCK: Box damaged with tears on packaging, but product is in excellent condition and in perfect working order***


The Headliner 3-Tier Desktop Synth Stand was designed to improve your workflow and help you stay organized while fitting more gear on your production desk. It fits three compact devices like synthesizers, controllers, drum machines, and effects modules. The angled design makes it easier to reach knobs and view LCD screens.

The Headliner 3-Tier Desktop Synth Stand is adjustable in width from 7.3" to 11.5" and fits a variety of devices from Roland, Korg, Elektron, and more (partial list below). It is made from solid steel and includes non-slip rubber strips for added stability.

Features
Improve your workflow and stay organized while fitting more gear on your production desk.
Fits three devices such as synthesizers, controllers, drum machines, and effects modules.
Angled stand makes it easier to reach knobs and view LCD screens.
Solid steel construction with non-slip rubber strips keep stand and equipment in place.
Width adjustable from 7.25" to 11.5". Best fits devices from 8" to 14" in width.
The lower tier has a depth of 7". The middle and upper tiers have a depth of 5.25".
Overall dimensions of stand (WxDxH): 7.25"-11.5" x 17" x 17.5".
Includes non-slip rubber strips.

Fits*: Akai Fire, Alesis SR-16, Arturia SparkLE, Behringer Crave, Behringer TD-3, Behringer RD-6, Elektron Digitone, Native Instruments Maschine Mikro MK3, PreSonus ATOM SQ, Akai LPD8, Akai MPX8, Dreadbox Typhon, Korg nanoPAD2, Korg SQ-1, Korg Volca Bass, Korg Volca Beats, Korg Volca Drum, Korg Volca Kick, Korg Volca NuBass, Korg Volca Sample 2, Roland Boutique Series, Roland MC-101, Roland TB-3 Touch Bassline, Roland TR-6S
*Some devices may not fit on all tiers.

Notes: ***B-STOCK: Box opened, product in perfect working order***


Updated version of IK's MTM monitors offer even better performance in the same compact package. Available here as a pair bundled with ARC measurement microphone for precise calibration.

Supplier's notes:

IK Multimedia iLoud MTM MKII Active Studio Monitor (single)
Deeper. Louder. More accurate.

iLoud MTM MKII offers sonic perfection and volume levels previously unavailable in this class of reference monitors. Maintaining its iconic form, MTM MKII sports more efficient drivers and twice the processing power under the hood to turn any space into the ideal mixing and mastering setup.

Enjoy clear, neutral sound with the deep, controlled low end you'd expect from a speaker twice the size and linear phase response that rivals speakers twice the price. Its MTM design and precise time alignment make hours of fatigue-free listening possible while minimizing acoustic interactions, which is ideal for desktop use.

With advanced ARC auto-calibration, MTM MKII guarantees improved acoustic performance in any space in seconds. Connected to a computer, award-winning X-MONITOR software adds deep customization and breathtaking emulations of 20+ top studio monitors and other playback systems to A / B your mixes instantly for the perfect translation.

MTM MKII is like having an entire suite of precision-tuned monitoring tools.

Ultra-nearfield monitors for critical mixing

iLoud MTM MKII features a pair of 3.5" high-performance woofers and one 1" high-definition, back-chamber loaded tweeter with improved speaker drivers for superior volume and low end, plus improved clarity and articulation in the midrange. The Midrange-Tweeter-Midrange symmetrical design (D'Appolito configuration) provides ultra-precise, defined, point-source sound that can't be achieved by traditional 2-way systems at close distances, meaning you'll mix better and with less ear fatigue.

Designed to work faster in more situations

In addition to improved speaker drivers, iLoud MTM MKII maintains tight vertical dispersion, minimizing the acoustic impact of desktop placement and ceiling and floor reflections to ensure the most accurate possible sound. MTM MKII offers a wider horizontal dispersion, creating a broader sweet spot for easier mixing than other MTM designs while maintaining the smoothest in-room response. Better power efficiency and extended max SPL mean iLoud MTM MKII also offers superior performance as an FOH mixing monitor, immersive speaker or other volume-dependent tasks.

Next-generation ARC room correction

iLoud MTM MKII adds a deeper, more comprehensive ARC auto-calibration derived from IK's flagship iLoud Precision series. Connected via USB to a Mac / PC with X-MONITOR, this 4-space measurement offers an unmatched definition and reliable translation in virtually any environment, so your mixes will always sound their best. A rapid, single-point measurement option can be done anywhere without a computer. Connect an ARC MEMS microphone (sold separately) to each speaker's mic input, and you'll be up and running in moments.

X-MONITOR integration

Also inherited from IK's flagship iLoud Precisions, iLoud MTM MKII now offers full X-MONITOR integration. This exclusive, award-winning software gives you complete control over every speaker element beyond the rear controls. Also, it allows for precise delay compensation between units for improved stereo imaging.

A single solution to A / B mixes

In addition, X-MONITOR allows you to switch between virtual monitoring voices, emulating the frequency and phase response of other top studio monitors and reference systems. With 4 buttons to quickly recall various voices, X-MONITOR with MTM MKII becomes an entire reference monitoring system in one elegant solution.

Stereo to immersive sound anywhere

IK have packed all this technological sophistication into a compact format that takes up 30% - 50% less space than comparable designs and weighs just 5 pounds. With tilting desktop mounts included, it's the ideal desktop solution for home, project or mobile recording. There's also an included isolation pad for horizontal placement wherever needed.

Bottom mic stand mounts securely position iLoud MTM MKII behind a console for studio or FOH use or even on boom arms to create immersive setups anywhere quickly with no tools required. A custom mounting bracket is also available to easily install MTM MKII as overheads or wall speakers in any studio.

The ideal immersive audio solution

All these amazing features, plus a selectable 80 Hz low-frequency cutoff, also make iLoud MTM MKII the ideal monitor for today's immersive studios. Learn how iLoud MTM MKII is ideal for use with ATMOSr and other multi-channel audio systems!


Specs

iLoud MTM MKII Specifications

Type: 2-Way / 3-speakers bi-amped, digitally controlled studio monitor
LF drivers: 2 x 3.5" composite cellulose fiber, custom-made mid-woofers
HF drivers: 1" low distortion, back chambered silk dome tweeter
Acoustic design: DSP tuned bass reflex
Number of amps per speaker: 2
Amplifiers type: High efficiency Class-D
Total power: 100 W RMS
LF power: 70 W RMS
HF power: 30 W RMS
Crossover type: Digital, linear phase
Crossover frequency: 2.8 kHz
Frequency response: 48 Hz to 28 kHz + / - 2 dB, 36 Hz to 32 kHz @ -10 dB
Phase response: System remains coherent within + / - 15- from 200 Hz to 20 kHz
Sensitivity at +4 dBu: -6 dBu signal generates a 94 dB SPL @ 1 m
Sensitivity at -10 dBV: -17 dBu signal generates a 94 dB SPL @ 1 m
Continuous, long term SPL free field, 1 m distance, one speaker, ANSI-2034 Weigthed Pink Noise: 97 dB
Peak SPL free field, 1 m distance, one speaker, ANSI-2034 Weigthed Pink Noise: 110.5 dB
Peak SPL, half space, 1 m distance, one speaker, ANSI-2034 Weigthed Pink Noise: 112.5 dB
Placement setup: Manual switches for LF Extension, LF trim, HF trim, Desk position
LF extension switch: Sets -3 dB point of the frequency response at 40, 50, 60 or 80 Hz (LFE)
LF switch: Low shelf, +2 dB or -3 dB from 100 Hz down
HF switch: High shelf, +2 dB or -3 dB from 8 kHz up
Desk switch: -4 dB at 160 Hz and +1 dB at 1.8 kHz
Calibration: Fully automatic and built-in digital calibration
Full DSP control
Total Latency (TOF): 2.44 ms
Connectors: 1x combo XLR-1 / 4" TRS balanced input; 1 / 8" TS ARC microphone input, 1 x USB type-B, AC POWER socket
Power requirement: 90 to 240 V AC, auto-ranging, 50 or 60 Hz, 120 W max power consumption

Dimensions

Size: 264 mm / 10.39" x 160 mm / 6.3" x 130 mm / 5.12"
Weight (per speaker): 2, 5 kg / 5.5 lbs (speaker + foot)

Package includes

1 x iLoud MTM MKII monitor
Power cord
Tilting stand
Horizontal support feet
Locking key
1 x ARC Microphone
1 x ARC Microphone clamp
1 x XLR to 1/8" (3.5mm) TS cable for ARC microphone (2.5m/8.2ft)

Notes: ***B-STOCK: Box damaged, product in perfect working order***


A total music production system in a controller:
The iRig Keys I/O series evolves the concept of traditional controllers as the only one available on the market that integrates 25 or 49 full sized keys together with a fully-fledged professional audio interface featuring 24-bit audio up to 96kHz sampling rate, balanced stereo and headphone outputs, plus a combo input jack for line, instrument or mic input (with Phantom power.)

Together with an audio interface, iRig Keys I/O also packs all the controls you would expect from a premium controller including velocity sensitive multicoloured pads and programmable touch-sensitive sliders, buttons and knobs for unique expressiveness and fast workflow.

Both iRig Keys I/O 25 and 49 are also the smallest full sized keys on the market making them the best solution for working in small spaces and ideal when it comes to having a controller for traveling musicians, in addition to the consideration that they are the only truly mobile devices that can also work on AA batteries.

Being certified Apple MFi keyboard controllers ("Made for iPod, iPhone, iPad,") iRig Keys I/O are guaranteed to work out of the box with all iOS devices including the latest generation of iPhone 7, that does not have an audio output, thanks to the on-board audio interface. The included Lighting cable allows for straight plug-and-play with Apple iOS devices, the USB cable connects Mac and PC computers.

Plus with over $/€550 (25) and $/€750 (49) worth of IK full software and apps they include an unmatched selection of everything that is needed to make complete, finished productions out of the box like the full SampleTank 3 sound and groove workstation, Miroslav Philharmonik 2 CE orchestral workstation, Syntronik Pro-V vintage synthesizer, T-RackS Deluxe mix and mastering suite and more, as the ultimate music production station.

The only controller with an audio interface:
Having a professional 24-bit / 96kHz capable complete audio interface built-in with iRig Keys I/O presents many advantages versus regular controllers for today's musicians. The system becomes self-contained taking up minimal space in any situation whether on a small studio desk or when playing live and traveling. The set-up is also kept to a minimum and is as fast and easy as just plug and play. The work environment becomes clean and tidy, without a bunch of extra cables.

In a recording studio, everything can be connected directly to the keyboard ensuring the best possible quality with a Class A preamp for dynamic and condenser mics (including those requiring 48V Phantom power, which works under battery power as well,) to line instruments and even Hi-Z guitars and basses. The built-in headphone output allows for convenient silent playing when studying or practicing. Plus, when used in live performances the balanced stereo output allows for long cable runs directly from the keyboard to the PA or mixer which is useful for performing keyboard players or DJs.

Take control with touch controls:
Despite their ultra-compact dimension, iRIg Keys I/O include all the tactile controls you would expect from a fully-fledged controller and more. Starting with a fast synth-action key bed that improves on all preceding IK keyboards and it's a joy to play. Both the models feature one volume/ data push knob, 4 touch sensitive knobs on 2 banks (acting as 8 total controls) and 8 multicoloured, velocity sensitive pads. Plus, there are 2 fully programmable touch control strips acting by default as Pitch and Mod controls allowing for dramatic performances in any genre and double as fully programmable sliders.

A complete touch sensitive transport and button control section rounds out the controls available. All knobs, sliders and buttons are touch-sensitive using capacitive technology for ultra-fast action and immediate feedback, displaying the related parameter value just with a simple touch.

Perfect for mobile, great with computer:
iRig Keys I/O work universally with all types of devices whether mobile, laptop or regular desktop computer. They are ideal for iPhone and iPad thanks to the included Lighting cable connections and certified MFi compatibility. Additionally, they offer more iOS friendly features that can't be found with any other controller like the included mobile device stand and the possibility to keep the device charged during long playing session using an optional power supply adapter, and of course the included audio interface that makes them perfect when used with the latest generation iPhone 7 that lacks a mini jack audio output.

Notes: ***B-STOCK: Box opened, product in perfect working order***


Sampling meets the internet in the intriguing WoFi, a WiFi-enabled polyphonic instrument based around samples, granular synthesis and the online mywo.fi community platform.

Supplier's Notes:
WoFI is a portable Sampler keyboard that connects to the internet via WiFi, and features an innovative effect module called Texturer that combines elements of shimmer and granular synthesis to create unique and fascinating sounds. Its compact size and intuitive interface make it an ideal tool for musicians and producers who are always on the move. In addition, WoFI comes with a rechargeable battery, allowing you to create music anywhere you go without worrying about power. You can also share your patches and access sound banks from other sound designers through the mywo.fi community platform. Whether you're a beginner or a seasoned professional, WoFI offers endless possibilities for exploring new sonic territories and creating unique sounds.

Features

Player

The Player let you colour your sound with our emulations of classic samplers and their different sample player modes. Make it clean, dirty or anywhere in between.

Enveloppe

Sculpt your sound with the Enveloppe that can be assigned to WoFi's amp, filter or even both.

Manager

With the Manager and its display, get a visual feedback on all your tweakings, manage your sample library, access to mywo.fi content through WiFi and play with the touch strip. Oh, and there is no subscription needed for mywo.fi. Having WoFi gives you free access to community.

Filter

The Filter let you play the WoFi like classic subtractive synthesizers. It's a digital low-pass filter with two different slopes (12dB and 24dB) and a tasty resonance.

Texturer

The Texturer is here to bring you to unexplored sonic territories. Elevate your sound with this effect halfway between a shimmer FX and granular synthesis.

LFO

The LFO let you modulate your creation. With three different wave shapes, assign it to any parameter of the front panel and give motion to the sound.

Sequencer

The Sequencer let you build melodic patterns with the 16 polyphonic steps. It can be used as an arpeggiator. You can have your two hands free to play along the sequence and tweak your sound while it is looping. Oh, and you can also step sequence parameters, which makes it another modulation source in addition of the LFO and the Enveloppe.

Recorder

The Recorder let you either capture a sample from the line in or directly from the built-in microphone. It's easy as pie, pick your audio source with the switch, click on record and voila. Just like with the iconic first keyboard samplers.

Master

The Wofi is made to be played in many contexts, from your couch to the studio, so it has a full connectivity and two stereo audio outputs: one for your headphones and one for a master line-out and the WoFi internal speaker. Set your volumes easily.

Technical details

Player
- 48kHz 16 bits
- Direct streaming from flash, no preloading
- Polyphony 10 voices

Recorder
- 48kHz 16 bits mono
- Line / dynamic microphone / integrated microphone
- Gain adjust -6dB + 22dB
- Eurorack level compliant

Memory
- Flash embedded memory : 100 Mbytes, Flash cartridge memory : 100 Mbytes, Up to 200 User Patches + 50 Presets

100 MB allows storing 18 minutes of audio

Sequencer
- 16 steps track for notes
- 16 keys track for parameters sequencing


DSP
- Real time processing (No Preprocessing)
- Interpolation modes: sample & hold, linear, whittaker-shannon
- Pitch shift
- Time stretch
- Bit crusher
- Texturer
- Machine rendering emulation
- Resonant state variable filter (12dB/o-24dB/o)
- Parameter modulation from different sources : enveloppe, LFO, sequencer automations, external modulation (CV/MIDI), after touch, touch strip
- Texturer: self mixing renderer based on granular sampling - 8 grains - multi tap harmonizer

File servicing
- Direct file system management through USB
- Embedded sample editor

Network
- WIFI connectivity, up to 16 key pass
- Cloud access: Patch / Sample upload and download, sharing or backup.

Connectivity
- Sync clock + start/stop
- CV input, Gate input
- CV output, modulation output, gate output
- MIDI in, out, through DIN+USB
- Line In, Line out, Headphones


Miscellaneous
- USB powered
- Embedded battery - roughly 4h autonomy
- Integrated Microphone
- Integrated Speaker
- Full backup to Cartridge or mywo.fi
- User friendly workflow


- Aluminium / wood body
- Dimensions: 52cm x 23cm x 7cm

Notes: ***B-STOCK: Box damaged, product in perfect working order***


PreSonus Eris-series studio monitors are used worldwide by audio engineers and producers who need to hear every detail of their recordings. Our best-selling studio monitors just got better! Eris 3.5 media reference monitors deliver studio-quality sound in an elegant, compact form factor that makes them ideally suited for bedroom studios, video production, and high-fidelity gaming setups.

With 25 watts per side of onboard power, the Eris 3.5 reference monitors pack a serious punch, while still delivering clear, accurate audio. The weave and nature of the Eris 3.5's 3.5-inch woofer result in tight bass that you can feel, as well as cleaner overall sound. The one-inch silk-dome tweeter produces refined high-frequencies and is designed to radiate sound with a wide pattern, creating a large optimal listening area. Improved speaker voicing over previous designs delivers richer lows and a smoother crossover transition for articulate, accurate transient reproduction throughout the frequency range and a less-fatiguing listening experience.

A convenient front-panel knob sets the level of both the power amp and the loud, clear headphone amplifier, with its front-panel jack. With three types of inputs, it's easy to connect just about any audio source to Eris 3.5 reference monitors. High- and low-frequency controls let you easily adjust the Eris speaker's frequency response to compensate for the acoustics of your space and create the most accurate sonic reproduction possible.

Need a little more low end? Add an Eris Sub8 BT to build a perfectly matched 2.1 sound system that fits almost anywhere.

Features

3.5-inch, woven-composite, low-frequency driver
1-inch, ultra-low mass, silk-dome, high-frequency driver
50W, Class AB dual amplification
80 Hz to 20 kHz frequency response
98 dB SPL (Peak, @ 1 meter)
High- and low-frequency Acoustic Tuning controls
Balanced, 14-inch TRS inputs; unbalanced, 1/8-inch stereo and RCA inputs; and integrated stereo headphone amplifier with front-panel 1/8-inch output
Protection: RF interference, output-current limiting, over-temperature, turn-on/off transient, subsonic filter
Power Saver mode (engages after 40 minutes)
Comes with speaker wire, 1/8-inch TRS to stereo RCA cable, and stereo RCA to stereo TS cable

Versatile connectivity.

PreSonusr Erisr 3.5 reference monitors connect to virtually any line-level audio source, using rear-panel, 14-inch TRS and RCA inputs and a front-panel, 1/8-inch, stereo line input. You also get a convenient (and loud!) front-panel, 1/8-inch, stereo headphone jack; connecting headphones mutes the speakers.

Built to match your room.

Unlike other home audio speakers that hype the bass at the expense of other frequencies, Erisr speakers provide an even response throughout the frequency range, from bass to treble. This means you'll hear your favourite music exactly as artists and engineers intend it to be heard. High and Low Acoustic Tuning controls let you dial in the Eris 3.5s precisely to your environment to further ensure the best sound possible.
Honest. Expressive. Powerful.

Like all PreSonus media reference monitors, the Erisr 3.5 offers consistent, accurate listening. Their stylish design makes them a welcome addition to living rooms, compact home theatre setups, and gaming rigs, and their smooth and even frequency response ensures that your music - and everyone else's - will sound incredible.

Specs

Electronics
Voltage: 220-240V UK
Wattage: 25 Watts (Each Speaker)
Input impedance: 10 kO

Performance
Peak SPL: 98 dB (@ 1 meter)

Speakers
Crossover frequency: 2.8 kHz

Hardware
Cabinet material: Vinyl-Laminated, Medium-Density Fiberboard
Audio controls: Volume High Frequency (+/-6 dB, center 10 kHz, continuously variable) Low Frequency (+/-6 dB, center 100 Hz, continuously variable)
Monitor inputs: Bluetooth 5.0, 1 x Stereo 1/8", 2 x Balanced 1/4" TRS, 2 x Unbalanced RCA
Power amplifier type: Class AB

Measurements
Dimensions: 8.30 x 5.50 x 6.00 in

Depth: 6.5" (16.4 cm)
Height: 8.3" (21.0 cm)
Width: 5.6" (14.1 cm)

Notes: Based on the ADDAC501 Complex Random module, the 511 expands the concept to become an even more powerful random/stochastic voltage generator. Four channels, all capable of being used for envelopes, modulation sources, sequencers and much more.

Supplier's Notes:
This module greatly expands on the principles of the ADDAC501 Complex Random from 2013.

This is a fully fledged 4 channel voltage generator capable of all things random, with quantization, probability, distribution, interpolation, time control, clock, states and a 32 step sequencer.

The module operation relies on its screen for all parameter editing, each button accesses one single page where parameters can be changed allowing a fast and fluid workflow across all settings.

Long presses on all buttons have a secondary function allowing fast Channel selection plus Mute and Hold functions.

The combination of having 2 Encoders with Push buttons allow swift navigation and editing across all pages and their settings.

Tech Specs:
20HP
4.5cm deep
200mA +12V
100mA -12V

Notes: ***B-STOCK: Product with some signs of usage but in perfect working order***


Pico DSP is a small brother of the popular stereo effects processor Black Hole DSP. It contains eight algorithms, in detail four delays, two types of reverb, Leslie speaker emulation and an Overdrive/Bitcrusher. Each effect is editable in two parameters. One of them can be modulated using the CV input. Pico DSP features clear, high-resolution sound. Alongside the established standards, it is also possible to generate lots of freaky special effects.

Notes: NANO modules are excited to introduce you to OCTA, the upcoming 4-channel Analog Drum module, inspired by the iconic TR-808 and redesigned with a modern twist.

OCTA delivers punchy and dynamic analogue drums, with individual outputs, mute switches, CV control over Drive, and a built-in Tilt EQ and Compressor for creative shaping. Nano stayed faithful to the original circuits, but added key controls to give each voice more range and modular versatility.

Notes: Analogue discrete Synthvoice with two VCOs, three SUB-VCOs, Wavefolder, Noise, Ring Modulator, two loopable ADRS, two LFOs/VCOs, MIXER, 24db Lowpass VCF, VCAOur new Eurorack flagship hits stores this summer. Very compact (pre-patched) discrete synth voice module with excellent analogue technology for endless soundscapes at a reasonable price.

Two discrete VCOs with highly stable tracking

Three analogue Suboscillators (3/4-1/2-1/4 with SQUARE, SAW, TRI) + Gravity Mix -Sync

Wavefolder (VCO 1 TRI WAVE)

White Noise

XOR Ringmodulator

Discrete VCA

24dB LP VCF with overdrive

Dual analogue LFO (one also usable as VCO) with incredible range and keytracking -Two superfast and punchy analog ADSR sections with LOOP function and four TRG outputs (End of ATT, End of DEC)

Mixer section with Master level -Glide presets and huge Patchfield to communicate with other Eurorack Modules.

Screwed metal shaft potentiometer

Rackspace: 36TE
Depth: 25mm

Notes: The 2OSC R2 is a dual 1V/octave oscillator module. Another successor of a classic AE module, the 2OSC/d. The 2OSC is a dual oscillator module, digitally based, with a great feature set:

Oscillator 1:

- Sawtooth
- Multi-Sawtooth, detuned
- Pulse Wave
- Triangle waveform with wavefolder
- Sinewave
- Suboscillator output
- Mix output (primary wave plus suboscillator)


Oscillator 2 , Noise:

This oscillator is focused on square waves; additionally to a pulse width controlled and CV-controllable square wave, it offers also a "synced square wave" (sounds really nasty!) and synced to oscillator 1. A separate suboscillator out is here available too. Additionally, a separate noise output is included, whose sound depends of the frequency setting of oscilaltor 2. The octave range switches are the same like in 2OSC/d. On top of the usual 1V/octave pitch control, the module can be controlled also via IMDI, the internal, patchable MIDI! Oscillators 1 and 2 are separate via different MIDI channels.

Notes: The FADRMIX JACKOUT is an extension for the FADRMIX6 with two 1/4" (6.5mm) jack sockets for master left/right output and 4 stereo minijack sockets for the FX send and returns.

The module is connected via a small internal connection cable to the right of the FADRMIX6.

Notes: The FADRMIX6 module is a performance mixer for your AE system; if offers the following features:

6 mono input channels with two sockets per channel; these two inputs are mixed at equal level, so FADRMIX6 is in fact a 12-chnnel mixer (somehow)!

Click-free mute buttons per channels

Per channel: fader for level, knobs for pan and two FX-send channels

2 FX send-return sections (send mono, return stereo) to connect FX modules

FX sends can be individually configured as pre-fader / post-fader (switches on the back of the module)

FX returns can be switched mono/stereo

Master level faders; stereo minijack socket master out

Stereo headphone output as stereo minijack socket with separate level control.

An internal connector allows the extension of input channels and output / FX sends as jack sockets by the FADRMIX JACKOUT module

Module size: 6 units

Notes: FMOS R2 is a FM oscillator, and the successor of the discontinued FMOS module with a lot of new features!

FMOS R2 is basically a 2-operator FM synthesis sound generator, with the classic parameters MULTIPLIER for the modulating operator and MOD DEPTH for controlling the amount of FMing of the carrier operator.

Beyond this basic functionality, FMOS R2 offers following extra features:

- Additionally to the basic sinewave operator waveform, FMOS R2 has five additional waveform combinations for the carrier/modulator waveform, resulting in a more rich overtone spectrum

- The FEEDBACK control adds feedback the carrier/modulator chain, adding more variety to the sound spectrum

- The modulator can optionally be set to fixed frequency, especially useful for synthesizing metallic, inharmonic sounds

- A sub-oscillator output provides a square wave one octave lower

- The MIX output provides a mix between the FM sound and the sub-oscillator.

- Pitch is either controlled by a 1V/octave CV or IMDI, the "modular MIDI" introduced by tangible waves

- Modulation depth can be modulated by CV

- All parameters can also be controlled via IMDI, with a number of MIDI controllers.

All this with a nice portion of 8-bit charm!

Notes: This module is best if you want a classic, analogue oscillator and prefer fully analogue sound generation. It offers:

- two CV inputs 1V/octave

- Modulation input with Level-knob, switchable to frequency or pulsewidth

- PWM input

- Coarse / Fine knob for frequency

- Pulsewidth knob for square wave

- Square / Triangle / Sawtooth output

The VCO R2 supersedes the VCO module which was part of the AE modular Kickstarter campaign in 2017; with the overall development of AE modular, the old one doesn't really meet the current quality level of AE any more. So Tangible Waves are happy to offer this completely redesigned module, that offers a really good volt/octave tracking over 5-6 octaves (using both CV inputs) and an amazing temperature stability.
